Summary of Contents for Antaeus AT 75 B

  • Page 1 2021 Side Grip Vibro Hammer Operation Manual...
  • Page 2 Certified by ISO9001 and CE Antaeus Foundation Equipment LLC Phone: 206-495-7030 Email: jwhite@antaeusfoundationequipment.com Website: www.antaeusfoundationequipmnt.com 250 South Webster Ave Seattle, Washington 98108 Mailing Address: PO Box 809 Seahurst, Washington 98062...
  • Page 3 • Thank you for choosing Antaeus hydraulic side grip vibro hammer! • The Antaeus side grip hammer is a new generation of pile drivers suitable for different geological conditions and different pile types. • We regularly update this Operation Manual for you to have a comprehensive understanding of this product.
  • Page 4 Warning Sign legend Warning！ Subject to constant improvement and engineering progress, we reserve the right to make changes to specification without notice. Notice！ Attention Notice！ To ensure safe operation, be sure to check before any operating of this product. It is necessary to inspect regularly..

  • Page 5: Table Of Contents

    Content Chapter 1 Product profile ............4 1.1 General ................4 1.2 Features ................6 1.3 Main components .............7 1.4 Specification ..............10 1.5 Model selection reference..........11 1.6 Working principle and application ......12 1.7 Security points ..............14 Charpter 2 Installation Instruction ........15 Chapter 3 Commissioning ...........18 Chapter 4 Piling operation ...........19 4.1 Check before operation ..........19 4.2 Driving piles and extracting..........20...

  • Page 6: Chapter 1 Product Profile

    Chapter 1 Product profile 1.1 General 1.1.1 About Antaeus Machinery The name Antaeus” comes from the ancient Greek god of the earth. We use this name because our company’s core proposition is to design, rent, sell, and service deep foundation construction equipment.
  • Page 7 The Antaeus Hydraulic Excavator Vibro hammer is powered by the excavator hydraulic power system, without the need of another power unit. The Antaeus Hydraulic Excavator Vibro hammer works with high frequency vibration from 2800 to 3000 RPM and provides 30 tons to 50 tons force to break the soil adhesive power.

  • Page 8: Features

    1.2 Features • Functions: Vibrating, clamping, and rotating. Each action is individually controlled. • Two-settings of vibration power output, which can meet with all kinds of construction conditions. The second setting vibration output is more powerful and could be applied for the hard soil layer . •...

  • Page 9: Main Components

    1.3 Main Components 1. Rotation gear box: the latest gear built-in design to prevent dirt and impact, replaceable gears, run smoothly and durable. 2. Gear box: the core component and power source of this machine. 3.Bracket: High-performance elastomers, stable quality, long use life. 4.
  • Page 11 1.4 Specification 1.4.1 Product Dimensions： 50.23 inches 51.49 inches...

  • Page 12: Specification

    1.4.2 Specification Model 5.5 kg-m 6.5 kg-m 7.5 kg-m Eccentric Moment kg-m Eccentric Moment In-lbs 477 in-lbs 564 in-lbs 650 in-lbs 320 kN 451 kN 378 kN Centrifugal force（kN) 36 US tons 42 US tons 51 US tons Centrifugal force US Tons 545 kN 645 kN 767 kN...

  • Page 13: Model Selection Reference

    1.5 Model selection reference pile length 6m Model pile length 20ft 30ft 40ft 50ft 62ft The max pile pile length when the soil is soft The max pile pile length in common soil conditions...

  • Page 14: Working Principle And Application

    (2) Eccentric force is in proportion to the eccentric moment and the square of the speed of vibrations measured as vpm. Antaeus eccentrics are have been in constant development over 30 years resulting in an efficient and durable unique design.

  • Page 16: Security Points

    1.7 Saftey points: • The operator should have professional knowledge and related certificates required to operate this machinery. • Strictly follow all security regulations. • Use of this machine for lifting operation is not allowed. • Use this piling machine as impact hammer (loosening the clamp pressure and impacting) is not allowed.

  • Page 17: Charpter 2 Installation Instruction

    Chapter 2 Installation Instructions Antaeus piling machine is attached to excavator. Before installation, make sure that the excavator power system matches the piling machine. If any problems please call the nearest Antaeus service branch. 2.1 Choose an empty, flat and clean ground for installation, anyone who is not related to installation should keep keep some distance.
  • Page 18 After installation, lift the machine and make the gear box and Clamp vertical to the ground.
  • Page 19 2.5 Before installation, make sure all the hydraulic connection parts are clean with no pollutants inside the hose. 2.6 Equip one electric control box for the piling machine, install it in the cab, fix the wire on the vice arm with film, do not expose it to the elements 2.7 For installation details, please contact our services people.

  • Page 20: Chapter 3 Commissioning

    Chapter 3 Commissioning • Clean the ground and tools before commissioning, check all oil hoses, electric wires, bolts, connection shafts, safe steel wires, clamp, make sure all are firm and safe. Anyone who is not related to commissioning should keep away. •Operator starts excavator, check the excavator as following （1）Lift up the long boom and short arm, operate to move the shaft, check if the movement of vice arm and the main hammer is stable or...

  • Page 21: Chapter 4 Piling Operation

    Chapter 4 Piling operation and place 4.1 Check before operation： Check all connection parts, bolts, and oil hose. Check if there is any damage in the machine, pay close attention to the screws between the vice arm and adapter, make sure they are tight. Check if there is any wearing of clamp jaw and make sure the bolt on the fixed size jaw is tight.

  • Page 22: Driving Piles And Extracting

    4.2 Driving piles and extracting: Be familiar with the jobsite, sheet pile arrangement, try to reduce the the need to move the excavator as much as possible. Start the excavator, adjust the excavator and side grip vibro. Move the pile to the suitable piling position. （3）Clamping: After side rotating, vibrate a few seconds, let down pile close to the clamp bottom, operate jaw open and close.
  • Page 23 （4）Lifting the PIle: Close the clamps and lift the boom slowly until the height where an assistant can bind the pile. Fix a wire rope with pile. (Binding the pile is a safety measure to avoid dropping a pile if the clamps fail. It is important to always have a saftey rope no matter piling or extracting.
  • Page 24 （6）Extracting: Move the hammer to the extracting position, clamp the pile, start vibration, adjust the boom and arm, bucket cylinder, put the machine in the horizontal position. Driving the pile down for 10 minutes, then pull it up. When the pile reaches the binding rope position, stop vibration, fix the binding rope.

  • Page 25: Safety Notification

    It is not safe to vibrate the hammer while the pile is not in the ground (as in the figure ). After extraction, put the pile back to a destinated position. 4.3 Safety notification: (2) While in operation, no personnel should stand under or near the machine.

  • Page 26: Chapter 5 Safety Rules

    5.1 General description ●Please do not modify this machine. If you need to modify it, please contact Antaeus. Antaeus shall not be liable for any accident or failure caused by operation or modification other than the specified in this manual.

  • Page 27: Safety Notification

    ●The operator should have following qualifications: 1.Graduated from the technical training class of vehicle system construction machinery (for basic engineering). Those who have passed the examination and approval of construction machinery technology stipulated by the construction industry agency law. 2. Person in charge of the operation of pile driver: the person who is qualified in special education for the construction machinery of vehicle system.
  • Page 29 7. Remove the accumulated soil at the pile head regularly. If the pile head is deformed, please repair it. 8. When installing or removing the hydraulic hoses and connectors, please turn off the engine of the excavator and wait until the hydraulic system internal pressure has gone down to safe levels.
  • Page 30 5.2.2 Precautions High frequency hydraulic vibratory pile drivers should be carried by the certified and skilled driver. The starting of the pile driver should be sped up from low gear to high gear. Pay close attention to the indication of current and voltage on the control box while working, in case of any abnormality, the machine shall be stopped immediately for inspection.
  • Page 31 13. While driving or pulling the pile, the operation should equalize the elastomers evenly, at the same time, ensure the pile is vertical. Don't side load the elastomers or they will get hot and crack. 14. It is dangerous to move the excavator arm while driving piles. 15.
  • Page 32 Movable jaw Fix jaw Movable jaw Movable jaw Sheet pile 19. While driving or pulling piles, if you need to rotate the pile driver, please take care not to twist the hydraulic oil hoses. 20. When driving or pulling piles, please use the hanging wire rope for saftey.
  • Page 33 5.2.3 Precautions at the end of work 1. At the end of operation, please lift the rotating arm to make the motor park at the upper position. As shown in the figure below: 2. After operation, the hammer shall be covered with a tarp to keep the pile driver free from wind and rain.

  • Page 34: Emergency Handling

    5.3 Emergency handling A. In case of the following emergency: When the hydraulic power unit fails during operation: The pressure of the clamp may drop, which may cause the risk of the pile to fall. In order to prevent the pile from falling, it is necessary to use an auxiliary wire saftey rope during work.

  • Page 35: Chapter 6. Operation Specification

    Chapter 6. Operation specifications 6.1.1 Preparation before operation Check whether the vibrator has been installed on the vice arm arm as required. Check whether the hoses are damaged and whether there is any visual oil leakage. Check whether the controller switch is okay and whether the wire harness is exposed.
  • Page 36 5.The driver can adjust the vibration times of the pile driver according to the actual needs of the site work to improve the centrifugal force. 6.The first stage of vibration force: Applicable to muddy soil, soft sand ground, silt ground, etc. Normal load can reduce the fuel consumption of excavator.
  • Page 37 Rotation operation： 6.1.4 (1) By turning the left-hand and right-hand rotary switches, the pile driver can turn left and right. (2) Please be careful not to pull the external oil hose when rotating the machine, it may break. (3) The rotation speed has been set at the time of handover, about 10 rpm.

  • Page 38: Operation Steps And Skills

    6.2 Operation steps and skills (steel sheet pile) 1.Start 2. Clamp pile Start the excavator, adjust the clamp the sheet pile tightly, lift it and excavator and pile driver; place vibrate a bit to clear the soil above. the pile to some position that the clamp can grab it.
  • Page 39 5. Vibration 6. Boom pressurization Ensure sheet pile has been When it is felt that the soil tightly clamped,, press the under the sheet pile is loose, vibration button to start the pile operate the boom to press driving. Never move the downward.
  • Page 40 Note: Please note that the average drive time of driving a pile is about minutes. Pay attention to how long the hammer is under vibration. Long vibration time will shorten the life of bearings, oil seals, and hydraulic motor. Warning: if a pile is at refusal, do not overburden the machine to force a pile in the ground beyond the above stated recommendations for machine usage.

  • Page 41: Chapter 7 Inspection And Maintenance

    Chapter 7 Inspection and maintenance 7.1 Inspection and maintenance 7.1.1 Adapter (1) Different brands and models of excavators have different size connectors and oil circuits. Each excavator is different. (2) Please completely clean the dirt and dust on the connectors and fittings of hydraulic hoses and fittings before connecting or disconnecting.
  • Page 42 Grease port Grease Port Reducer Elastomer Motor tilt cylinder Please check bearing covers and side covers  of gear box for any oil leaks. The first gear oil to be done after 200 hours  Weekly inspection and monthly replacement ...
  • Page 43 7.1.3 Clamp Confirm whether the bolts of the clamp are tight. The hydraulic cylinder should not leak any oil. Please check jaws for tooth wear. If less than 0.157 inches (4mm) then replace jaws. when less than 4mm replacement (3) Clear and clean any sand and soil off the clamp jaws. (4) Check the rings at the end of the axle pins have come loose, When the fixing ring come loose, the axle pin may drop.
  • Page 44 Make sure each hydraulic connection is tight. Replaces hoses when needed, careful not to over tighten hydraulic fittings, over tightening can cause damage. The hydraulic relief valves and settings have been pre-set by the factor, do not adjust them without approval from an Antaeus service person.

  • Page 45: Check Items And Check Time Table

    7.2 Items to Check 7.2.1 Time table and check sheet list Check period daily weekly monthly 3month 6month yearly Check item The loosening of bolt, screw √ or cracked parts. Cracking and wear of pins √ and axles √ gearbox oil level √...
  • Page 46 √ Wear of the clamp jaws. √ Jaw position and fastening bolt √ hydrauil hose integrity √ hydraulic oil pressure light √ hydraulic manifold oil leaks √ broken wire ropes √ Abnormal sound from the gear box √ Lack of lubricant lube of pins and spin axis √...

  • Page 47: Self-Inspection Measure

    7.3 Self-inspection measure Checking main parts are shown as diagram below: Check whether the pin bolts are loose Check whether the reducer bolts are loose Check whether the shaft bolts are loose Check whether Check whether the elastomer bolts motor is leaking are broken check whether the elastomers are...
  • Page 48 clamp plate should be tight check the oil level of gear box. Oil level should be in center of sight glass.

  • Page 49: Chapter 8 Fault And Troubleshooting

    Chapter 8 Fault and Troubleshooting Items Inspection Checking points Normal Troubleshooting For bolts and screw visual inspection Not lose or Tighten or and check with broken replace The loosening of wrench bolt, screw or cracked parts Visual inspection of Weld repair or No crack a crack replacement...
  • Page 50 Visual inspection No broken Circuit wire Repair or damaged, Check with cut or short replacement Check with multimeter No short Lubricate the pin Visual inspection Grease Grease the rotation bearing Visual inspection Not dirty the hole and clean Gear box oil, dirt Add and clean hydraulic motor displacement...

  • Page 51: Chapter 9 Electric Diagram

    Chapter 9 Electrical Diagram electric resource left tilt right tilt clamp open clamp close left rotation right rotation vibration vibration clamp close indadicate clamp close clamp open left tilt right tilt left rotation right rotation...

  • Page 52: Chapter 10 Hydraulic Diagram

    Chapter 10 Hydraulic Diagram...

  • Page 53: Warranty

    Antaeus or any change or repair made by others in the judgment of Antaeus, will have a material and adverse effect on the Product and will invalidated this Warranty.
