- Page 1 EMERGENCY RESPONDERS GUIDE...
-
Page 3: Table Of Contents
Important Safety Instructions Inspection Recommendations About This Guide What to Inspect For About Vehicle References After Inspection Symbols Glossary IDENTIFYING THE SOLO MOVING THE VEHICLE Exterior Moving O the Road Interior Transporting the Vehicle Vehicle Identification Number (VIN) IMMOBILIZING & STABILIZING THE VEHICLE 7... -
Page 4: Safety Information
Follow the procedures to help ensure a safe and successful first response operation. ABOUT THIS GUIDE This guide covers the SOLO vehicle for models manufactured in 2021 or newer. This manual may be periodically updated. If you are not viewing this manual on the o cial ElectraMeccanica web site, go to electrameccanica.com/firstresponders or electrameccanica.com to ensure you have the most recent version. -
Page 5: Symbols Glossary
SAFETY INFORMATION SYMBOLS GLOSSARY The following symbols used within this manual call your attention to specific types of hazards and what to do to avoid or reduce them. DANGER Indicates a hazard with a high level of risk which will result in serious injury or death WARNING Indicates a hazard that could result in injury or death CAUTION... -
Page 6: Identifying The Solo
IDENTIFYING THE SOLO EXTERIOR The SOLO is a three-wheeled, single-passenger vehicle. The exterior can be distinguished by its unique badging. PG. 4... -
Page 7: Interior
IDENTIFYING THE SOLO INTERIOR MIRROR The SOLO can be identified from the interior by its unique dashboard layout and instrument cluster display screen. Both the seat and the rocker panels in the door frames have SOLO badging. PG. 5... -
Page 8: Vehicle Identification Number Vin
IDENTIFYING THE SOLO VEHICLE IDENTIFICATION NUMBER VIN This legal identifier is in the front corner of the instrument panel. It can be viewed from outside the vehicle. The VIN is also printed on the Tire and Loading Information Label (see “Vehicle Weight Information”, page 33). -
Page 9: Immobilizing & Stabilizing The Vehicle
IMMOBILIZING & STABILIZING THE VEHICLE SHIFTING INTO NEUTRAL The Drive Mode Selector is a three-position dial on the dash. When the key switch is ON, the Drive Mode Selector can be used to set the desired direction of the vehicle: - Reverse - Neutral (Use when starting, parking, or transporting the vehicle) - Drive... -
Page 10: Applying The Electronic Parking Brake Epb
IMMOBILIZING & STABILIZING THE VEHICLE APPLYING THE ELECTRONIC PARKING BRAKE EPB The EPB has both manual and automatic functions. It is manually controlled by a rocker switch on the dash, to the right of the steering wheel. When the EPB is engaged either manually or automatically, the EPB indicator will illuminate on the instrument cluster display. - Page 11 IMMOBILIZING & STABILIZING THE VEHICLE EPB MAINTENANCE MODE WARNING Use caution when disengaging the EPB, as the vehicle will be free-rolling. Be aware that the vehicle could roll if it is not on a level surface. CAUTION Pushing the vehicle with wheels on the ground should only be done for very short distances, as prolonged rolling (e.g.
-
Page 12: Chocking The Wheels
IMMOBILIZING & STABILIZING THE VEHICLE CHOCKING THE WHEELS To help prevent the vehicle from moving, always chock all three wheels before attempting extraction procedures. • Electric vehicles run and drive silently, so never assume they are powered o . • When the Drive Mode is in D (Drive) or R (Reverse), this vehicle will creep forward or backward while the drive system is powered on and the brakes are not engaged. -
Page 13: Electrical System Information
ELECTRICAL SYSTEM INFORMATION HIGH VOLTAGE COMPONENTS A/C compressor DC/DC converter High-voltage batteries Drive motor On-board charger High-voltage distribution box Powertrain controller Cabin heater Charging port Battery heater Charging cable PG. 11... -
Page 14: High-Voltage Warning Labels
ELECTRICAL SYSTEM INFORMATION HIGH VOLTAGE WARNING LABELS WARNING Not all high-voltage components are labeled. Always wear appropriate PPE when cutting the vehicle. Failure to do so can result in death or serious injury. DANGER WARNING High Voltage! High Voltage Service by Authorized Follow Lockout Procedure Personnel Only Before Removing The Cover... -
Page 15: High-Voltage Batteries
ELECTRICAL SYSTEM INFORMATION HIGH VOLTAGE BATTERIES Li-ion Li-ion Li-ion The 144V lithium-ion batteries are encased and mounted under the vehicle floor.When using lifting or rescue tools, use caution and never breach a high-voltage battery case. For proper lifting procedures, see “Lifting the Vehicle”, page 27. -
Page 16: 12-Volt Battery
ELECTRICAL SYSTEM INFORMATION 12 VOLT BATTERY The 12V battery is located at the right front of the chassis, to the right of the accelerator pedal. This battery powers all of the standard low-voltage electronics in the vehicle. It also powers the high-voltage distribution box, which controls high-voltage current within the high-voltage components (e.g. -
Page 17: High-Voltage Cables
ELECTRICAL SYSTEM INFORMATION HIGH VOLTAGE CABLES High-voltage cables are colored orange for easy identification. PG. 15... -
Page 18: Drive Motor
ELECTRICAL SYSTEM INFORMATION DRIVE MOTOR The drive motor (1) is located near the rear wheels of the vehicle. This component receives 3-phase alternating current (AC) and converts it into propelling energy (torque), used to power the wheels. PG. 16... -
Page 19: Opening The Vehicle
OPENING THE VEHICLE HOOD 1. Pull the handle (1) located on the side panel under the lower left corner of the dash. 2. Lift the secondary catch release lever (2) under the front lip of the cover and raise the hood. TRUNK Pushing the trunk release button on the dash will open the trunk. - Page 20 OPENING THE VEHICLE EMERGENCY TRUNK RELEASE If the vehicle has no power, the trunk can be opened manually from the inside: 1. Remove the cover at the base of the trunk latch. 2. Pull the emergency release handle to unlatch the trunk. PG.
-
Page 21: Power Windows
OPENING THE VEHICLE POWER WINDOWS The power window switches are located on each of the side door panels, and each switch controls its own window. To operate a window: ON position. See “Using the Key Switch”, page 22. • Ensure that the key switch is in the •... -
Page 22: Remote Transmitter
OPENING THE VEHICLE REMOTE TRANSMITTER Key Release Button: Press to flip out the key blade. Lock Button: Press once to lock both doors. Note: Locking the vehicle with the transmitter will disable the trunk release button on the dash until the vehicle is unlocked by the transmitter. -
Page 23: Disabling The Power
DISABLING THE POWER REQUIRED EQUIPMENT PERSONAL PROTECTIVE EQUIPMENT PPE SPECIFICATION PURPOSE Insulated Gloves Class 0 (up to 1,000V) For protection from high-voltage electric shock Insulated Shoes/Boots Safety Shield Full-face To protect the face from debris Leather Gloves Must be able to fasten tightly To protect insulated gloves around the wrist (worn over insulated gloves) -
Page 24: Using The Key Switch
DISABLING THE POWER USING THE KEY SWITCH The key switch is a four-position switch that is located on the right of the steering column and is operated by inserting the key. The switch positions are as follows: 1. OFF: Turns the vehicle systems o . Note: The steering column will lock when the key is in the OFF position, and will not be able to be turned. -
Page 25: Disconnecting The Charge Cable
DISABLING THE POWER DISCONNECTING THE CHARGE CABLE WARNING In cases of vehicle fire or submersion, if the vehicle is plugged into an external power source (e.g. charging station or wall outlet) via the charge cable, disable the power source BEFORE attempting to disconnect the cable. Failure to do so could result in serious injury or death. -
Page 26: Disabling The 12-Volt System
DISABLING THE POWER DISABLING THE 12 VOLT SYSTEM Always use appropriate tools and wear appropriate PPE when cutting the 12V ground WARNING cable. Failure to follow these instructions can result in serious injury or death. Cutting the 12V ground cable DOES NOT completely disable the high-voltage system. WARNING Continue to treat the high-voltage components as energized even after disabling the 12V system. -
Page 27: Disabling The High-Voltage System
DISABLING THE POWER DISABLING THE HIGH VOLTAGE SYSTEM Always wear appropriate PPE when handling the high-voltage cables. Failure to follow WARNING these instructions can result in serious injury or death. Regardless of the disabling procedure you use, ALWAYS ASSUME THAT ALL WARNING HIGH-VOLTAGE COMPONENTS ARE ENERGIZED! Cutting, crushing, or touching high-voltage components can result in serious injury or death. -
Page 28: Rescue Operations
RESCUE OPERATIONS CUTTING THE VEHICLE Always use appropriate tools (such as a hydraulic cutter) and always wear appropriate WARNING PPE when cutting the vehicle. Failure to follow these instructions can result in serious injury or death. Regardless of the disabling procedure you use, ALWAYS ASSUME THAT ALL WARNING HIGH-VOLTAGE COMPONENTS ARE ENERGIZED! Cutting, crushing, or touching high-voltage components can result in serious injury or death. -
Page 29: Lifting The Vehicle
RESCUE OPERATIONS LIFTING THE VEHICLE Never raise the vehicle when the charge cable is connected, even if charging is not in WARNING progress. Always disconnect the charge cable before raising the vehicle. See The illustrated lifting points are the only approved lifting points for the vehicle. Using WARNING any other lifting points may cause the vehicle to fall, resulting in death or injury to anyone working beneath it. -
Page 30: Vehicle Fires
RESCUE OPERATIONS VEHICLE FIRES In cases of fire, the entire vehicle should be considered as energized. Toxic vapors can be WARNING released from a heated or burning battery. To prevent personal injury, responders should always wear full PPE, including a SCBA. Use proper measures to protect anyone downwind of the incident. -
Page 31: Post Incident Vehicle Inspection
POST INCIDENT VEHICLE INSPECTION INSPECTION RECOMMENDATIONS WARNING Alwavys wear full PPE when inspecting a potentially damaged vehicle. It is necessary to inspect the vehicle post-incident to ensure that the high-voltage system has properly shut down and the battery system has not been damaged. It is strongly recommended to inspect the vehicle twice: once at the incident scene, and again after the vehicle has been stored o -site. -
Page 32: After Inspection
POST INCIDENT VEHICLE INSPECTION Loss of High-Voltage System Integrity • Inspect the cabling and components of the high-voltage system for damage. • Visible electric arcing or carbon traces are evidence of electrical isolation loss. Fluid Leaks • The high-voltage battery contains lithium-ion cells. Only a small amount of clear battery fluid can leak from damaged cells. -
Page 33: Moving The Vehicle
MOVING THE VEHICLE MOVING OFF THE ROAD Deactivating the Electronic Parking Brake (EPB) requires pressing the brake pedal. WARNING Once the vehicle is in N (Neutral), the EPB is deactivated, and the brake pedal is released, the vehicle will be free-rolling. Be aware that the vehicle could roll at this point if it is not on a level surface. -
Page 34: Transporting The Vehicle
MOVING THE VEHICLE TRANSPORTING THE VEHICLE Towing the vehicle with the wheels on the ground, or on a suspended lift, may cause CAUTION serious damage to the vehicle and could generate high voltages in the vehicle’s electrical components. CAUTION Do not use the recovery eye to strap the vehicle down. If for any reason the vehicle can not be driven, the only approved method of recovering or transporting it is by using a flatbed trailer or transporter that has an approved load rating greater than the actual weight of the vehicle, including after-market accessories and cargo. - Page 35 MOVING THE VEHICLE VEHICLE WEIGHT INFORMATION The Tire and Loading Information label (visible when the right door is open) lists the Gross Vehicle Weight Rating (GVWR) of the vehicle. MFD BY: CHONQING ZONGSHEN AUTOMOBILE INDUSTRY CO. LTD. DATE OF MFG: GVWR: 933 KG FOR: ELECTRAMECCANICA VEHICLES CORP.
- Page 36 MOVING THE VEHICLE USING THE RECOVERY EYE CAUTION Before pulling the vehicle, always ensure that the recovery eye bolt is fastened securely. In the event that the vehicle needs to be pulled onto a flatbed trailer or transporter, a recovery eye assembly is supplied for this purpose.
- Page 37 MOVING THE VEHICLE The recovery eye has a limited range in which it can be pulled from, as seen in the CAUTION illustration below. Do not pull the vehicle from an angle outside of this range. 10° MAX 10° MAX 10°...
-
Page 38: Storage And Isolation
STORAGE AND ISOLATION STORING DAMAGED VEHICLES • Until it has been properly inspected, do not store a vehicle with any evident or possible damage to the high-voltage system inside a structure. See “Post-Incident Vehicle Inspection”, page 29. • If possible, open both windows and doors while the vehicle is in storage to encourage ventilation. This can prevent build-up of toxic and/or flammable gases released from a damaged battery. - Page 40 EMV Automotive USA Inc. 11647 Ventura Boulevard Studio City, CA 91604 +1 888 457 7656 info@electrameccanica.com electrameccanica.com...
