- Page 1 SMART METER 2.0 The latest-generation electronic meter for more efficiently managing your energy consumption three-phase meter INSTRUCTION MANUAL...
- Page 3 The new electronic meter makes it possible to check the consumption of your home at any time and know how much power your electronic equipment is absorbing. How Does my new meter work? DISPLAY Information about the electricity supply can be seen on the display at the centre of the meter.
- Page 4 BUTTON The display’s contents can be controlled by pressing the button: • with single quick presses, the various messages provided are displayed; by pressing the button for longer, • the explanation of the symbols regarding the meter’s functions is displayed; if the button is not pressed for 15 •...
- Page 5 wHat appears on tHe DispLay? By pressing the display’s right button in sequence, the following information is displayed. IT0123E00021122 POD NUMBER is the alphanumerical code that identifies the supply. Fascia in uso F3 TIME BAND IN USE indicates the time band that is applied at the time of reading the display (F1, F2, F3).
-
Page 6: Instantaneous Power
Pot.Istant=003,1 INSTANTANEOUS POWER shows the kW absorbed at the time of reading. LETTURA-POTENZA READING THE CONSUMPTION AND THE POWER POWER-READING indicates the start of a sequence of information on consumption and the absorbed power. CURRENT PERIOD corresponds to the data recorded up to the time the display is read. -
Page 7: Available Power
Data 01/01/2020 Ora 16:03:04 DATE AND TIME the date and time when the meter is read. 800 933 301 NUMBER FOR REPORTING FAULTS Unareti’s Emergency Number for reporting faults or anomalies of the electricity network and hazardous situations regarding electrical installations. - Page 8 The electronic meter continuously measures the power absorbed by the customer’s system and compares it with the available power. wHat Happens if I exceeD tHe avaiLaBLe power? If the available power is exceeded, the meter automatically checks at set intervals (2, 92 and 182 minutes) and displays the following information: REDUCE LOAD POWER EXCEEDED BY MORE THAN XX%...
- Page 9 ENFORCED DISCONNECTION POWER EXCEEDED BY MORE THAN XX% disconnection due to exceeding the available power takes place in the following cases: if the absorbed power, measured • during a period of time of 2 minutes, was more than 27% of the available power;...
- Page 10 For more information unareti.it To report faults or anomalies in the electricity network and hazardous situations regarding electrical installations 800 933 301...
- Page 11 Certifications The CE marking and the supplementary metrology marking (indicated by the letter capital M and the last two numbers of the year the marking was affixed, inscribed in a rectangle) confirm the meter’s compliance with the European Community Directive (MID). Certification of the meters, in compliance with the MID directive, was carried out by a notified body, accredited at the European level in compliance...
-
Page 12: Declaration Of Conformity
Pagine/Contatore-La-Qualita.aspx The radio module is for the exclusive use of Unareti S.p.A., which uses it in addition to or as a replacement for the main transmission module. The meter’s certified software version can be found directly within the information on the meter’s display.
