evoralight Roam RGB 44 Series Installation

Product Specification Sheet
Project:

Product Features

Voltage 24V DC Input
LEDs/ft 18 LEDs/ft (60 LEDs/m)
Beam Angle 120° Beam Angle
Ambient Temp -4°F to +104°F (-20°C to 40°C)
LED pitch 3/4" (17 mm)
Cutting Points 4" (100 mm)
Max Run Length in Series 32'10" ft (10 m)
LED Size 5050
Adhesive Type 3M VHB 4930 tape (IP20)
Dimmable Yes
Spool Size 16.4 ft (5 m) or 100 ft (31 m)

Component Ordering Process

01
LED Tape Light
Product Specifications
Product
Luminous Efficacy
SKU
RM44-RGB-24V
01 EVORALIGHT.COM
Roam™ RGB 44 Series LED Tape Light
Type:
02
AC
Driver Options
Watts /ft (Meter)
33.6 lm/W 4.4 W/ft (14.4W/m)
Quote/Ref:
Description
Explore millions of colors with the Roam™ RGB 44 Series as you
tap into your creativity. With 300 LEDs per 16.4 ft reel, every
shade you choose will appear vibrantly bold and vividly bright.
Pair this tape light with an RGB controller to take full advantage
of its lighting capabilities. The Roam™ RGB 44 Series is fully
dimmable and can change colors in different styles, such as
fading, flashing, and more. Create playful settings for events,
themes, and moods in residential or commercial spaces.
SKU Builder
Series: Roam™ 44
-
RM44
Dimensions
5/8" 16 mm
03
DC
Connector Options
Lumen / Foot (Meter)
R: 49 lm/ft (161 lm/m)
G: 87 lm/ft (284 lm/m)
B: 20 lm/ft (66 lm/m)
ALL Channels:
151 lm/ft (496 lm/m)
(Click to select your Length)
Color Temp. Voltage
-
RGB 24V
Ex: RM44-RGB-24V-16FT
4" 100 mm
1/16" 2 mm
04
Channel Options
Color Wave Lengths Max Run Length
R: 617-627 nm
G: 515-525 nm 32' 10" (10 meters)
B: 464-474 nm
844.964.1600
15 Year
Warranty
Length
-
Length
16FT - 16.4 ft
100FT - 100 ft
3/8" 10 mm
