- Page 1 EVERKITCH USER’S MANUAL Range Hoods EVK1901...
-
Page 2: Table Of Contents
Content 1…………………………………..………………………………Safety instructions 2 …………………………………..………………………………Installation 3 …………………………………..……………………………… Technical Parameters 4 …………………………………..……………………………… Switch Operation 5 …………………………………..……………………………… Maintenance 6 …………………………………..……………………………… Caution 7…………………………………..……………………………… Troubleshooting... -
Page 3: Safety Instructions
1. SAFETY INSTRUCTIONS This manual explains the proper installation and use of your cooker hood, please read it carefully before using even if you are familiar with the product. The manual should be keptin a safe place for future reference. Never to do: Always to do: ●... - Page 4 2. Installation Instruction...
- Page 5 2.1 Mounting Ways 2.1.1 Wall mounted 1. Step 1. Fix the two pieces of hangings by using the screws where are already screwed on the two sides of the range hood. 2. Step 2. Drill 2 holes on the wall, use two iron expansions to fix the range hood onto the wall.
- Page 6 2.2 Venting 2.2.1 Rear venting Step 1. Remove the covering plate at the rear side of the range hood to leave a hole for venting. Step 2. Use screws to install the rear square air outlet onto the rear venting hole 2.2.2 Top venting Step 1.
- Page 7 Step 2. According to your kitchen venting way, choose either square or round air outlet, which are both available, to install on the top the range hood, and screw to fix it. 2.3 Installation guidance Notice: this installation guide is for reference only, please consult licensed electrician for professional installation instruction before proceeding.
- Page 8 4) For under cabinet installation, measure the position of your existing under cabinet hole and compare it with your range hood exhaustion hole. If they do not match, you need to alter your under cabinet exhaustion hole position to match your range hood exhaustion hole position. 5) Mark the position of the screw holes on top of range hood, which need to be drilled or screwed on in order to mount the range hood.
-
Page 9: Technical Parameters
3. Technical Parameters ITEM unit parameter Rated Voltage Rated frequency Lamp power ≤2X1.5 Air volume Air pressure >160 Noise level dB(A) <68 Air output diameter 4. Switch Operation ② ③ ④ ⑤ ①：Turn off ②：Low speed setting ③：Medium speed setting ④：High speed setting ⑤：Turn on/off the lamp... -
Page 10: Maintenance
5.Maintenance 1. For your safety, please make sure to pull out range hood electric plug and shut off power before maintenance. 2. Clean the inside and outside of the range hood with warm water containing neutral detergent, and dry the surface with a piece of dry cloth. To avoid potential damages to the surface, DO NOT scrub the surface with rough materials, such as cleansing ball. -
Page 11: Caution
6.Caution 1. DO NOT attempt to install this range hood by yourself without appropriate electrical and technical background. 2. The minimum distance between the surface of GAS stove/range and the lowest part of the range hood should be at least 27.6 inch (70cm). If installation instructions of the gas stove specify a greater distance, please take that distance into account. -
Page 12: Troubleshooting
7.Troubleshooting Fault Possible Cause Solution Fan switch turned off Select a fan switch position. Light on, but motor Fan switch failed Contact service center. does not work Motor failed Contact service center. House fuses blown Reset/Replace fuses. Light does not work, Refit mains power cable to power Mains power cable is loose or motor does not work...
