Summary of Contents for RaxGo RGFSBR4
- Page 1 FREE-STANDING BIKE RACK User Guide Sku: RGFSBR4...
- Page 2 BIKE RACK User Guide Sku: RGFSBR4 Thank you for purchasing the RaxGo™ Free-Standing Bike Rack. This User Guide is intended to provide you with guidelines to ensure that operation of this product is safe and does not pose risk to the user. Any use that does not conform to the guidelines described in this User Guide may void the limited warranty.
-
Page 3: Safety Precautions
SAFETY PRECAUTIONS This rack is intended for use with bicycles only. Do not attempt to mount other objects/persons on the rack. The maximum carrying capacity of this rack is 45 lbs. (20 kg) per bike, with a maximum of four (4) bikes permitted, totaling 180 lbs. -
Page 4: Parts List
PARTS LIST PARTS LIST... - Page 5 PARTS LIST Base Legs Base Screw-In Feet Lower Support Columns 2 PCS 6 PCS 2 PCS Lower Crossbar with Angular Support Braces 3″ Bolts and Washers 2 PCS 1 PC 4 PCS Threaded Holes Mounting Arms w/ Locking 1/2″ Bolts and Washers Upper Support Column 4 PCS 1 PC...
- Page 6 ASSEMBLY INSTRUCTIONS REQUIRED TOOLS: 10 mm or adjustable wrench 1. Connect the base leg (Part A) to the lower support column (Part C) and the lower crossbar (Part E) using the 3″ bolts and washers (Part F). Repeat on the other side with the remaining base leg (Part A) and lower support column (Part C).
- Page 7 2. Attach the angular support braces (Part D) using the 1/2″ bolts and washers (Part G) as shown. 3. Screw the base feet (Part B) into the designated spots on the base legs (Part A) ASSEMBLY INSTRUCTIONS...
- Page 8 4. Connect the upper support column (Part H) to the assembled base. 5. Hold the mounting arms (I) sideways, slide them on to the upper support column (H) and rotate them 90° so the angled arms are flat against the support column as shown.
- Page 9 6. Tighten the locking knobs on the end so that the mounting arms are secure. NOTE: Mounting arms may be positioned at varying heights to accommodate the frame of your specific bicycle. INSTALLING TENSION BAR...
- Page 10 1-833-722-0121 RAXGO is a trademark of C&A IP Holdings, LLC in the US. All other products, brand names, company names, and logos are trademarks of their respective owners, used merely to identify their respective products, and are not meant to connote any sponsorship, endorsement or approval.
