Battery Part Number: DSE-LFP51.2V50A-16sLFP36115185-50A-PB50-MC-CO07-M21A
Prepared by
QE/210128
Customer Code/Name:
Customer Approval
Rev No.
Revision Description
M20A
Initial release
M21A
Update drawings
Product Specification
LiFePO4 Battery
Checked by
/
CO07
Stamp
Product Revision History
Approved by
A/210128
Modify
Approval
QE
QE
Date
201217
210128
Advertisement
Table of Contents
Related Manuals for MOTOMA LFP51.2V50Ah
Summary of Contents for MOTOMA LFP51.2V50Ah
- Page 1 Product Specification LiFePO4 Battery Battery Part Number: DSE-LFP51.2V50A-16sLFP36115185-50A-PB50-MC-CO07-M21A Prepared by Checked by Approved by QE/210128 A/210128 Customer Code/Name: CO07 Customer Approval Stamp Product Revision History Rev No. Revision Description Modify Approval Date M20A Initial release 201217 M21A Update drawings 210128...
-
Page 2: Table Of Contents
MOTOMA POWER CO., LTD Http: // www.motoma.cn E-mail: info@motoma.cn Content 1 When Using battery ..................................4 2 While Charging ....................................5 3 When Discharging the Battery ............................5 4 Parameters of Battery ................................6 4-1.Cell Type and Model ................................ 6 4-2.Cell Performance ................................ - Page 3 MOTOMA POWER CO., LTD Http: // www.motoma.cn E-mail: info@motoma.cn Figure 1 Battery Block Diagram ..........................13 Figure 2 Real-time Monitoring ............................ 19 Figure 3 Display record ..............................20 Figure 4 Storage record ..............................21 Figure 5 Parameter Settings ............................21 Figure 6 System Configuration ............................
-
Page 4: When Using Battery
MOTOMA POWER CO., LTD Http: // www.motoma.cn E-mail: info@motoma.cn Please comply with all warnings and operating instructions in this manual strictly. Save this manual properly and read carefully the following instructions before installing the unit. Do not operate this unit before reading through all safety information and operating instructions carefully. -
Page 5: While Charging
MOTOMA POWER CO., LTD Http: // www.motoma.cn E-mail: info@motoma.cn n is prohibited. DC short circuit dangerous： Power system provides dc regulated power supply. Dc short circuit could cause fata l damage to the equipment. 2 While Charging CAUTION The temperature range over which the battery can be charged is 0°C to 45°C. Charging the battery at temperatures outside of this range may cause the battery to become hot or to break. -
Page 6: Parameters Of Battery
MOTOMA POWER CO., LTD Http: // www.motoma.cn E-mail: info@motoma.cn 4 Parameters of Battery 4-1.Cell Type and Model 4-1-1 Cell Type: LiFePO4 rechargeable battery 4-1-2 Cell Model: LFP36115185 4-1-3 Out dimension/cell :36mm(T)×115mm(W)×185mm(L) 4-1-3 Weight:<1.5kg 4-1-4 Shell Material: Aluminium 4-1-5 Internal resistance (Ac.1Khz) ≤3mΩ... - Page 7 MOTOMA POWER CO., LTD Http: // www.motoma.cn E-mail: info@motoma.cn Cut-off voltage of charging monomer 3.60V Standard discharging current Maximum continuous discharging current Cut-off voltage of discharging monomer 2.5V Charging temperature range 0°C～45°C Discharging temperature range -20°C～60°C Dimension (W×D×H) 432*450*134mm Weight...
-
Page 8: Technical Parameters Of Battery Management System (Bms)
MOTOMA POWER CO., LTD Http: // www.motoma.cn E-mail: info@motoma.cn 4-4 Technical Parameters of Battery Management System (BMS) Function name Item list Set value Setting range Alarm value of monomer Overvoltage alarm voltage 3,750±20mV undervoltage to 4,500mV Cell voltage alarm 1,000mV to Alarm value of Undervoltage alarm voltage 2,600±50mV... - Page 9 MOTOMA POWER CO., LTD Http: // www.motoma.cn E-mail: info@motoma.cn Recovery value of total voltage undervoltage to Overvoltage recovery 54.40±0.5V voltage Protection value of total voltage overvoltage 1. When the total voltage is lower than the recovery point, automatically recover charging.
- Page 10 MOTOMA POWER CO., LTD Http: // www.motoma.cn E-mail: info@motoma.cn protection Recovery value of charging low temperature Protection value of charging low temperature Charging low temperature -1±3°C recovery To Recovery value of charging high temperature Recovery value of Discharging high 65±3°C...
- Page 11 MOTOMA POWER CO., LTD Http: // www.motoma.cn E-mail: info@motoma.cn Recovery value of high High ambient temperature 70±3°C ambient temperature To protection 90°C Recovery value of low ambient temperature High ambient temperature 50±3°C recovery To Protection value of high Ambient ambient temperature temperature -40°C to...
- Page 12 MOTOMA POWER CO., LTD Http: // www.motoma.cn E-mail: info@motoma.cn Automatic recovery of 1 S to 60S over current Sustainable 100V(DC) voltage The over current event with the time interval of no more than 5min is called Continuous continuous over current.
-
Page 13: Basic Block Diagram
MOTOMA POWER CO., LTD Http: // www.motoma.cn E-mail: info@motoma.cn up for reset. BMS power Maximum standby time: 4h (The AC does not discharge, without valid discharging consumption current). management Power consumption of <30 mA normal running Static total power Max150uA... -
Page 14: Installation And Operation
MOTOMA POWER CO., LTD Http: // www.motoma.cn E-mail: info@motoma.cn 6 Installation and Operation 6-1.Unpacking and Inspection Unpack the package and check the package contents. The shipping package contains: ● One Battery ● A small bag of screws and nuts NOTE: Before installation, please inspect the unit. Be sure that nothing inside the package is damaged during transportation. -
Page 15: Single Battery Installation
MOTOMA POWER CO., LTD Http: // www.motoma.cn E-mail: info@motoma.cn RS232 connection port-C RS232 RS232 to PC RS485 connection port-A RS485 RS485 communication interface CAN connection port-B CAN CAN communication interface RS485 connection port-D RS485 RS485 communication interface Dry contact Reset key 6-3. - Page 16 MOTOMA POWER CO., LTD Http: // www.motoma.cn E-mail: info@motoma.cn alarm (which is resulted from non-use of the battery for a long time). Such case may be removed after the battery is charged for 30min; if the alarm may not be removed, please press the reset key RST for 10S, until all LEDs light up for reset, execute the battery reset operation and confirm whether the alarm is removed.
-
Page 17: Connection Schematic Diagram
MOTOMA POWER CO., LTD Http: // www.motoma.cn E-mail: info@motoma.cn 6-6. Connection schematic diagram Manufacturer reserves the right to alter or amend the design, model and specification without prior notice. 17 / 27... -
Page 18: Monitor Software Interface
MOTOMA POWER CO., LTD Http: // www.motoma.cn E-mail: info@motoma.cn 6-7. Monitor Software interface 6-8 Upper machine instructions A. Software source file： Name of software source file：BmsTools.exe, BmsTools.exe.config, Language.xml, LogParams.xml, MultiLanguage.dll, ParamSetting.xml six documents in total. B. Software running envirement： The software running on the PC and its compatible computer, using WINDOWS operation system. - Page 19 MOTOMA POWER CO., LTD Http: // www.motoma.cn E-mail: info@motoma.cn RS232 PC software Figure 2 Real-time Monitoring 2) Open the main interface（As shown in figure A） ，the software automatically search serial port，and automatically open，real-time read battery voltage, power, temperature, and protection of the state of battery parameters.
- Page 20 MOTOMA POWER CO., LTD Http: // www.motoma.cn E-mail: info@motoma.cn Check the display option, can real-time display the various parameters of the battery. Check the automatic storage option, can automatically storage the parametersof the battery in the excel table. The file in the software under the current file path of the data folder, storage file name named after pack number and time.For example packNo1_20150306145010.xls.
- Page 21 MOTOMA POWER CO., LTD Http: // www.motoma.cn E-mail: info@motoma.cn Figure 4 Storage record 5) In the parameter settings TAB(As shown figure D),the TAB for the battery parameters. Read the parameter I：Read all the parameters of the battery Write in parameter : Write all the parameters of the battery Restore default：Restore the default parameters for battery...
-
Page 22: Communication Function
MOTOMA POWER CO., LTD Http: // www.motoma.cn E-mail: info@motoma.cn Figure 6 System Configuration 6-9 Communication Function RS232 RS485-1 RS485-2 RS485-2 Figure 7 Communication Port Interface RS232 Terminal Port Definition Pin3 BMS Transmit, PC Receive Pin4 BMS Receive, PC Transmit Pin2,5... - Page 23 MOTOMA POWER CO., LTD Http: // www.motoma.cn E-mail: info@motoma.cn CAN Terminal Port Definition Pin1,5 CAN_L Pin2,7 CGND Pin3,6 Pin4 CAN_H CAN Communication Port Definition RS485-1 Terminal Port Definition Pin1,4 RS485_B Pin2,5 RS485_A Pin3,6 RS485-GND Pin7,8 RS485-1 Communication Port Definition RS485-2 Terminal Port...
-
Page 24: Operations
MOTOMA POWER CO., LTD Http: // www.motoma.cn E-mail: info@motoma.cn 7 Operations 7-1. LED Indicators LED Indicators: There are 6 LEDs on front panel to show the battery working status: Figure 8 LED Operating Status Flash Flash1 0.25Sec 3.75Sec Flash2 0.5Sec 0.5Sec... -
Page 25: Reset Key Function
MOTOMA POWER CO., LTD Http: // www.motoma.cn E-mail: info@motoma.cn Protection Buzzing 0.25S per 2Sec(expect for over-charge protection) Alarm Buzzing 0.25S per 3Sec(expect for over-charge alarm) NOTE: Buzzer function can be set by monitor software, the default if off. 7-3. Reset key function... -
Page 26: Storage And Maintenance
MOTOMA POWER CO., LTD Http: // www.motoma.cn E-mail: info@motoma.cn 9 Storage and Maintenance 9-1. Storage Before storing, charge the battery at least 7 hours. Store the Battery covered and upright in a cool, dry location. Recommend long-term storage temperature is 15°C -25°C . During storage,... -
Page 27: Product Responsibilities And Consulting
MOTOMA POWER CO., LTD Http: // www.motoma.cn E-mail: info@motoma.cn When replace the parallel batteries, make sure the new battery is full charged. Do not open or destroy batteries. Escaping electrolyte can cause injury to the skin and eyes. It may be toxic.
