Confoot CF Instruction Manual

Model:
ConFoot CF set
Inlcuded:
4x CF-legs
Model:
ConFoot CFL set
Inlcuded:
4x CFL-legs
Model:
ConFoot CFP set
Inlcuded:
2x CF/CFL-legs + 2x CFP-legs
Figure 1:
Extended position
Max. height position
Figure 2:
Top down truck view
CF 1
ISO
Container
CF 3
CAUTION: All sets must be used in accordance with the instructions found in this manual.
CF/CFL-legs
1 Magnetic clamp
2 Locking pin
3 Height adjustment handle
4 Retainer ring & position bolts
5 Branched legs
Figure 3:
CF 2
CF 4
Further information can be found at www.confoot.fi
CF/CFL/CFP SET INSTRUCTION MANUAL
Container type:
40 ft. or less, ISO
Max weight:
30,000 kg
Container type:
Compatible 45 ft. container, ISO
Max weight:
30,000 kg
Container type:
CF or CFL-leg dependent
Max weight:
30,000 kg
Min. height position
Folded position
5 Branched legs
4 Retainer ring &
position bolts
3 Height adjustment
handle
OY ConFoot LTD
Contents:
EN
Max wind:
22.5 m/s
FI
DE
Max wind:
NL
22.5 m/s
FR
SE
Max wind:
PL
22.5 m/s
CFP-legs
6 Lever locking
system
7 Height adjust-
ment handle
8 Retainer ring
Min. height position Max. height position
