- Page 1 350 SERIES OPERATIONS MANUAL 350 SERIES MODEL For parts and service, call: (877) 227-8811 Broce Manufacturing 1460 S. 2nd Street | Dodge City, KS 67801...
- Page 2 Discount-Equipment.com is your online resource for quality parts & equipment. Florida: 561-964-4949 Outside Florida TOLL FREE: 877-690-3101 Need parts? Click on this link: http://www.discount-equipment.com/category/5443-parts/ choose one of the options to help get the right parts and equipment you are looking for.
- Page 3 Dealership. I hereby acknowledge acceptance of above and conditions in the Warranty Policy. Purchaser/Owner: Dealer Representative: 350 SERIES MODEL For parts and service, call: (877) 227-8811 Broce Manufacturing 1460 S. 2nd Street | Dodge City, KS 67801...
- Page 4 We make no other express warranty. This warranty cannot be extended, broad- ened, or changed except in writing by an authorized officer of Broce Manufacturing. 350 SERIES MODEL For parts and service, call: (877) 227-8811...
- Page 5 We include this sign off sheet for your convenience and personal recordkeeping. Date Employer’s Signature Employee’s Signature 350 SERIES MODEL For parts and service, call: (877) 227-8811 Broce Manufacturing 1460 S. 2nd Street | Dodge City, KS 67801...
-
Page 6: Table Of Contents
Radiator & Heat Exchanger Lubrication Brakes Core Drive Engine Tires Storage Air Conditioning Maintenance Broom Wafer Replacement SCHEMATICS Wiring Diagrams Hydraulics Diagrams 350 SERIES MODEL For parts and service, call: (877) 227-8811 Broce Manufacturing 1460 S. 2nd Street | Dodge City, KS 67801... -
Page 7: Safety Precautions
OPERATING THIS MACHINE WARNING OPERATOR MUST BE SEATED WITH SAFETY BELT ADJUSTED PROPERLY & SECURE WHEN ENGINE IS RUNNING. 350 SERIES MODEL For parts and service, call: (877) 227-8811 Broce Manufacturing 1460 S. 2nd Street | Dodge City, KS 67801... - Page 8 The belt should fit snug over the operator’s hips. WARNING TRAVEL SPEED MUST BE GOVERNED BY GOOD JUDGMENT. DO NOT OVERSPEED! Although a high travel speed is available with the Broce Broom, we caution all operators to use good judgment, especially on rough terrain. WARNING DO NOT OPERATE CORE UNLESS CHAIN GUARD IS INSTALLED.
-
Page 9: Machine Specifications
MAX Pressure Setting (Priority) 345 BAR (5000 PSI) MAX Pressure Setting *(Secondary) *Relief valve in the broom rotation valve. 350 SERIES MODEL For parts and service, call: (877) 227-8811 Broce Manufacturing 1460 S. 2nd Street | Dodge City, KS 67801... -
Page 10: Fluid Capacities
Cummins = 2.0 lb 10.0 oz (1.191 kg) Ester Oil Charge: Compressor = 8.0 oz System = 4.0 oz 350 SERIES MODEL For parts and service, call: (877) 227-8811 Broce Manufacturing 1460 S. 2nd Street | Dodge City, KS 67801... -
Page 11: Machine Operation
MACHINE OPERATION The Broce Broom is hydrostatically driven. The directional control is achieved through the use of a control pedal, located near the operator’s foot. Toe down on the pedal directs the machine forward. Heel down shifts the travel to reverse. Rate of travel is governed by the distance the pedal is de- pressed and the throttle position. -
Page 12: Daily Inspection
4. After gear selection, raise engine RPM to about half throttle. Release parking brake. Slowly depress control pedal in the desired direction. Engine speed may be adjusted to obtain desired travel speed. 350 SERIES MODEL For parts and service, call: (877) 227-8811... - Page 13 Do not propel this machine with the parking brake engaged. This will damage the rear brake assemblies. 5. Do not over speed! Although a high rate of travel is available with the Broce Broom, we cau- tion all operators to use good judgment, especially on rough terrain.
-
Page 14: Sweeping Core
Release the handle when the desired angle is achieved. BROOM ON/OFF The Broom Core motor is activated when the handle is moved to the “BROOM ON” position. 350 SERIES MODEL For parts and service, call: (877) 227-8811 Broce Manufacturing 1460 S. 2nd Street | Dodge City, KS 67801... - Page 15 5. Ensure that the operator of the machine is properly trained and follows all safety procedures described in this manual. 350 SERIES MODEL For parts and service, call: (877) 227-8811 Broce Manufacturing 1460 S. 2nd Street | Dodge City, KS 67801...
-
Page 16: Towing
MACHINE OPERATION TOWING The Broce Broom may be towed without removing the drive shaft, but it is critical to ensure that the gearbox is in neutral to prevent serious damage. Use caution while towing since the broom does not have a suspension system to absorb the bumps. -
Page 17: Hydraulic System Details
1600 psi. The steering unit is an orbital type metering valve that supplies oil to the steering cylinder and also has power beyond capabilities that are used to control the brush functions. 350 SERIES MODEL For parts and service, call: (877) 227-8811 Broce Manufacturing 1460 S. -
Page 18: Brush Control
On machines equipped with an external drive, a-port on the rotation valve flows to the front port on the core drive motor, the rear port flows back to the return manifold, is filtered, and returned to the tank. B-port on the rotation valve is plugged. 350 SERIES MODEL For parts and service, call: (877) 227-8811... -
Page 19: System Description
CAUTION Make sure all three valves are in the “OPEN” position before starting the engine. If the return valve is closed, the return filter housing will be destroyed. 350 SERIES MODEL For parts and service, call: (877) 227-8811 Broce Manufacturing 1460 S. 2nd Street | Dodge City, KS 67801... - Page 20 Note: Spool #1 is the spool closest to valve inlet. A-port is the closest port to the control handle. Eliminating the positive down pressure feature will have no other effect on the rest of the operating capabilities of the system. 350 SERIES MODEL For parts and service, call: (877) 227-8811...
-
Page 21: Test Procedures
2. Remove the –10 Boss O-ring plug in the face of the brush rotation valve, in line with the relief valve. Turn the brush on and repeat above procedure. 3. Tee into A-port on the rotation valve and repeat the test procedure above. 350 SERIES MODEL For parts and service, call: (877) 227-8811... -
Page 22: Maintenance & Service
MAINTENANCE The manufacturer has endeavored to build the Broce Broom as maintenance free as possible. The service points are easily accessible and are similar to those on many types of construction equip- ment. This section will cover many of these points in some detail and will briefly mention those which should be standard on all equipment. -
Page 23: Hydraulic System
Again, cleanliness must be stressed during this type of maintenance. Contamination of this system will cause pump and/or motor failure. Avoid servicing hydraulic system components in the field where cleanliness of the environment cannot be controlled. 350 SERIES MODEL For parts and service, call: (877) 227-8811... -
Page 24: Radiator & Heat Exchanger
Both the front suspension and the drive shaft should be serviced every time the engine is serviced. More frequent servicing of these components will extend their life. Lube 350 SERIES MODEL For parts and service, call: (877) 227-8811 Broce Manufacturing 1460 S. 2nd Street | Dodge City, KS 67801... - Page 25 Seals are often destroyed by over-greasing sealed bearings. ENGINE LUBRICATION Refer to the Engine Manufacturer’s manual (included) for recommendation and procedures for servicing the engine. 350 SERIES MODEL For parts and service, call: (877) 227-8811 Broce Manufacturing 1460 S. 2nd Street | Dodge City, KS 67801...
-
Page 26: Brakes
ENGINE Broce Broom Lubrication Chart Initial (Hours) Thereafter (Hours) Item Remarks 25 50 100 100 500 1000 Engine Oil Change Oil Two-speed gear box Change Oil Check Differential Change Oil Check Hydraulic Disposable Filter Replace Hydraulic Oil Replace GREASE ZERKS... -
Page 27: Core Drive
After alignment, tighten both set-screws and jam nuts as well as the lock collar on the pillow block bearing at the other end of the broom core. 350 SERIES MODEL For parts and service, call: (877) 227-8811... -
Page 28: Engine
IMPORTANT Due to the dusty conditions that the Broce Broom operates in, it is recommended that the engine fan inspection and replacement be done every 300 – 400 hours. The dusty operating environment will cause quicker than normal erosion or the fan blades. The fan will need to be replaced when the blades deteriorate to the point that they do not provide enough air-move- ment or they become operationally unsafe. -
Page 29: Air Conditioning Maintenance
¼ turn. Broce thanks you for purchasing our unit/s. It is our endeavor to provide you with a quality A/C unit with trouble-free service. 350 SERIES MODEL For parts and service, call: (877) 227-8811 Broce Manufacturing 1460 S. 2nd Street | Dodge City, KS 67801... - Page 30 Cummins = 2.0 lb 10.0 oz (1.191 kg) Ester Oil Charge: Compressor = 8.0 oz System = 4.0 oz 350 SERIES MODEL For parts and service, call: (877) 227-8811 Broce Manufacturing 1460 S. 2nd Street | Dodge City, KS 67801...
- Page 31 Cab temperature: ______________________________ Broom S/N: ___________________________________ Hr: ______________________ Date: ____________________ Company or facility who made repairs: ______________________________________ Technical initials: ____________ 350 SERIES MODEL For parts and service, call: (877) 227-8811 Broce Manufacturing 1460 S. 2nd Street | Dodge City, KS 67801...
-
Page 32: Broom Wafer Replacement
MAINTENANCE BROOM WAFER REPLACEMENT The standard Broce Broom core uses 10” x 32” flat wafers and metal spacers. Two different lengths of cores are available. The standard eight-foot core requires approximately 54 wafers and 53 metal spacers (this will vary by wafer manufacturer and type of end-caps ordered on broom). The ten foot core requires 68 wafers and 66 spacers. - Page 33 To ensure proper core balance, rotate this tab 90°from the previous wafer. This will ensure even weight distribution on all four sides of the core. 350 SERIES MODEL For parts and service, call: (877) 227-8811...
- Page 34 (620) 227-8811. Core Service Ring and Stand 350 SERIES MODEL For parts and service, call: (877) 227-8811 Broce Manufacturing 1460 S. 2nd Street | Dodge City, KS 67801...
- Page 35 Most lifting is done when the sweep has been completed and the sweep- er is ready to be repositioned. The brush is normally turned off at this time. 350 SERIES MODEL For parts and service, call: (877) 227-8811 Broce Manufacturing 1460 S.
- Page 36 • Core misaligned whennecessary. • Replace motor. Re-align motor mount. Refer to Maintenance sec- tion for procedures. 350 SERIES MODEL For parts and service, call: (877) 227-8811 Broce Manufacturing 1460 S. 2nd Street | Dodge City, KS 67801...
- Page 37 • Refer to hydrostatic trouble power pump shooting section in Sauer- Dan- including steer- foss Manual. and hydrostatic drive. 350 SERIES MODEL For parts and service, call: (877) 227-8811 Broce Manufacturing 1460 S. 2nd Street | Dodge City, KS 67801...
- Page 62 Discount-Equipment.com is your online resource for quality parts & equipment. Florida: 561-964-4949 Outside Florida TOLL FREE: 877-690-3101 Need parts? Click on this link: http://www.discount-equipment.com/category/5443-parts/ choose one of the options to help get the right parts and equipment you are looking for.
