For Serial Numbers 304263 -304334 BB250 Self Propelled Multi Purpose Sweeper SERVICE -MAINTENANCE & PARTS MANUAL THIS VEHICLE DOES NOT CONFORM TO ALL SAFETY AND EMISSIONS STANDARDS APPLICABLE TO ON-ROAD VEHICLES IN THE UNITED STATES.
Page 2
Discount-Equipment.com is your online resource for quality parts & equipment. Florida: 561-964-4949 Outside Florida TOLL FREE: 877-690-3101 Need parts? Click on this link: http://www.discount-equipment.com/category/5443-parts/ choose one of the options to help get the right parts and equipment you are looking for.
Page 3
BB-250 Series Brooms Broce Manufacturing Company, Inc. WARRANTY REGISTRATION Purchased From (Dealership) Company: ___________________________________________________ Address: ___________________________________________________ City: _________________________ State: ____ ZIP: ________ Delivery Date to Dealer: ___ / ___ / ___ Unit Hours: _______________ Model Number: _BB-250-___ Serial Number: ____________...
Page 4
BROCE MANUFACTURING COMPANY BROCE BROOM LIMITED TWELVE MONTH WARRANTY For a period of twelve (12) months or 1,000 hours whichever comes first, from the date of delivery of product to the original user, Broce Manufacturing of Dodge City, Kansas warrants each product to be free from manufacturing defects, subject to the limitations contained in this policy.
TABLE OF CONTENTS DESCRIPTION PAGE # WARRANTY SPECIFICATIONS STANDARD AND OPTIONAL EQUIPMENT START UP AND PROPELLING TOWING PROCEDURES OPERATION OF THE SWEEPING CORE SWEEPING TIPS EXTENDING BRUSH LIFE MACHINE OPERATION AND SAFETY MACHINE CONTROL LOCATIONS MACHINE SERVICE AND SAFETY GUIDELINES LUBRICATION AND MAINTENANCE BRAKE INSPECTION AND SERVICE ENGINE...
MODEL BB-250 Specification Sheet Engine Horse Power 37 H.P. Machine Weight 3,000 LB 3,600 LB w/Water System Broom Size 6 3/8” ID X 24” OD Broom Length Full 8 FT Broom Drive Hydraulic Motor Broom Angle Full 40° (both ways) Steering 60°...
Page 8
STANDARD EQUIPMENT ON ALL UNITS SAFETY ORANGE PAINT 8’ STEEL CORE W/6 3/8” X 24” POLY CONVOLUTED WAFERS CERTIFIED ROLL-OVER PROTECTION STRUCTURE & CANOPY SEAT BELTS & REVERSE ALARM POWER STEERING 2-WHEEL HYDRAULIC DRUM BRAKES W/MANUAL PARKING BRAKE ...
START UP & PROPELLING CAUTION: OPERATOR MUST BE SEATED WITH SEAT BELT PROPERLY SECURED WHILE ENGINE IS RUNNING. This model of broom is hydrostatically driven. Motion is achieved by depressing the foot pedal on the floor board to the right of center. Letting the foot pedal up will result in a braking action caused by the hydraulic system.
TOWING PROCEDURES 1. Before towing this machine check the following: A. The tires should be inflated to 32 PSI and be in good condition. B. Any loose items on the machine should be removed or secured. C. Check to see that all the lug nuts/bolts are tight on the wheels and that the wheels are in good condition.
OPERATION OF THE SWEEPING CORE All functions of the sweeping core are hydraulically operated. Two control valve handles are mounted to the right of the operator’s seat for controlling these functions. The Joystick controls the core height up down and the right and left angle of Broom. The handle beside it controls the operation of the core motor.
SWEEPING TIPS If the broom starts to hop or bounce, the propelling speed is too high. Slow the machine down, but maintain high engine speed. This will allow you to do a good job on the first pass and you will not need to go over it again.
EXTENDING BRUSH LIFE BRUSH DOWN PRESSURE Most problems of rapid wear, bristle breakage and loss are attributed to excessive down pressure. If the proper down pressure is used, the sweeping efficiency will improve and bristle life will be extended considerably. More down pressure does not give a result of better sweeping. The broom gets its sweeping action by the flicking action of the bristles.
MACHINE 0PERATION AND SAFETY GUIDELINES Read all decals and manuals before starting and/or operation this machine. Do not operate or make any adjustments or repairs to the machine if parking brake will not hold machine from rolling. If the parking brake will not keep the machine from rolling adjust, repair or replace it before operating, adjusting or repairing the machine.
Page 15
MACHINE 0PERATION AND SAFETY GUIDELINES 15. Do not start, service, operate or make any adjustments to this machine before you have read and fully understood all of this manual. 16. Familiarize yourself with all operation and safety decals before operating this machine. OPERATIONAL AND SAFETY DECALS...
MACHINE OPERATION CONTROLS LOCATION ITEM LOCATION FUNCTION 1. Seat Belt Left and right side of seat. To prevent operator from falling off machine. 2. Parking/Emergency Brake Left of seat and back. To hold machine from rolling when parked and in neutral. To be used for energency stopping of machine.
Page 19
MACHINE OPERATION CONTROLS LOCATION ITEM LOCATION FUNCTION 7. Broom Left to Right Angle Joystick Control When pulled left, right end of Control broom moves toward front, Float-Down Pressure when pushed right, right end of broom moves back. Left Right Raise 8.
MACHINE SERVICE AND SAFETY GUIDELINES Read all decals and manuals before starting and operating this machine. Do not operate or make any adjustments or repairs if the Parking Brake does not hold machine. Repair the Parking Brake first, before making any other repairs or adjustments to this machine. Always set Parking Brake before starting and after stopping engine on this machine.
LUBRICATION AND MAINTENANCE 1. Grease two steering shaft bearings at the front of the machine every day. The front wheel bearings should be cleaned and packed every six months. 3. The tires on the front and rear of the machine should be kept at 32 psi and should be checked on a daily basis.
BRAKE INSPECTION AND SERVICE This machine is equipped with dynamic hydraulic braking, conventional hydraulic brakes and a mechanical Parking Brake. The dynamic hydraulic braking will be in operation any time that the engine is running. When the foot pedal is released, the hydraulic system provides enough braking action that the conventional foot pedal brake should not have to be used.
ENGINE The normal engine operation and maintenance procedures are covered in a separate manual, which is furnished by the engine manufacturer. We do suggest, however, due to the dusty conditions in which these machines operate, that engine fan inspection and replacement should be accomplished more frequently than the engine manufacturer may suggest.
REPAIR PARTS BB250 Self Propelled Multi Purpose Sweeper IMPORTANT! BEFORE ORDERING PARTS PLEASE PROVIDE COMPLETE MODEL AND SERIAL NUMBER WHEN ORDERING PARTS. THIS WILL MAKE FILLING YOUR ORDER EASIER, FASTER AND WILL HELP AVOID ANY UNNECESSARY DELAYS IN PROCESSING YOUR ORDER.
Page 29
BROOM CORE PARTS Ref # Part # Description 850132 Core Hanger 850137 Core Support Frame 502526 Core Frame End Plate 850139 Core Motor Mount - Left Side 850136 Broom Core RW-503B Single Poly Wafer W/Spacer 344145 Single Wire Wafer W/Spacer 344137 Set - Poly Wafers W/Spacer 344148...
Page 30
HYDRAULIC CYLINDER PARTS 2” X 4” CYLINDER 2” X 8” CYLINDER 2” X 10” CYLINDER Ref # Part # Description Cylinder 2 x 4 (Lift) Cylinder 2 x 8 (Steering) Cylinder 2 x 10 (Angle) RC-15 Rod Clevis RC-16 Head RC-14-4 Rod 4”...
Page 34
305900 Valve Assembly Part no. Description 1. 305900 Complete Valve Assy. 2. 305928 Float Detent 3. 305927 Spring Center Detent 4. 305959 Joystick Kit 5. 305960 Load Check ( not shown ) 6. 305962 Seal Kit ( not shown ) HC-228-B Rubber Boot...
Page 35
BRAKE PARTS Ref # Part # Description 850153 Brake Pad B-241-R Rubber Brake Pad 850128 Brake Pedal B-242-R Pivot Bushing HC-229-R Clevis 3/8” x 3” NF 202304 Brake Actuator Push Rod 344167 Master Cylinder 344220 Master Cylinder Repair Kit 202444 Brake Cylinder Rod Plate, Left Side 202443 Brake Cylinder Rod Plate, Right Side...
Page 43
OPTIONAL WATER SPRAY SYSTEM Ref # Part # Description WS-154-R Spray Bar Complete WS-155 Spray Nozzle Assy. Complete WS-158 Nozzle Screen TP8002 Spray Tip 1458 Cap, Spray Tip (plastic) WS-178 Back Flow Check Valve 302402 Water Pump WS-148 Inline Strainer (complete) Plastic 344254 Ball Valve 3/4 (plastic) WS-145-D...
Page 44
OPTIONAL ACCESSORIES Ref # Part # Description 7-40004 Amber Beacon 3614A Amber Strobe Light 23836 Push Pull Switch LG-100-250 Light Group Kit 6-70001 Tail Light 9-50004-SBA 2 Utility Work Light (front or rear) LG-100-TS Light Group, Turn Signal Pkg. 16-35800 Turn Signal Switch Flasher 550FH...
Page 45
3W BROOM TOW BAR LEFT SIDE ITEM PART NUMBER DESCRIPTION QUANTITY 852311 Hitch Tube w/ Hydraulic 2” Actuator 344133 2” Actuator 852312 Hitch Hydraulic Lever Assembly 202573 Hitch Cylinder Rod Clevis End 202571 Hitch 3W Hydraulic Step Shaft 306532 Ball Valve 344290 Hydraulic Hose Assembly 306160...
Page 46
3W BROOM TOW BAR CYLINDER ITEM PART NUMBER DESCRIPTION QUANTITY 202575 Hitch Hydraulic Cylinder 3W CALL Hydraulic Hose Assembly CALL Hydraulic Hose Assembly CALL Hydraulic Fitting 001397 Hose Clip...
Page 47
3W BROOM TOW BAR RIGHT SIDE ITEM PART NUMBER DESCRIPTION QUANTITY 202569 Hitch Lock Pin 3W Hydraulic 3W BROOM HYDRAULIC MANIFOLD ITEM PART NUMBER DESCRIPTION QUANTITY 202580 Hydraulic Tow Bar Control Valve (w/o solenoid) 305983 Coil – 3W Hitch 305984 Cartridge Valve CP 528-5 3W Hitch 305985 Cartridge Valve CP 508-3 3W Hitch...
Page 53
BB-250 D ROCE RIVE NSTALLATION OTES 1/8" PPLY SILICONE BEAD ALL THE WAY 700. AROUND E USE ORNING EMOVE BOTH SCREWS AND FILL WITH OIL UNTIL IT RUNS OUT OF THE LOWER HOLE EPLACE LOWER SCREW AND PUMP MORE OIL ).
Page 54
