INSTALLATION INSTRUCTIONS
WIBAT LINTEAU
VERSION 1-10 ANG
2, rue des Métiers
21110 – Genlis - FRANCE
Tél. : (33) 03 80 37 85 71
Fax : (33) 03 80 37 88 61
http://www.mation-smt.fr
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the WIBAT LINTEAU and is the answer not in the manual?

Questions and answers

Related Manuals for MANTION SMT WIBAT LINTEAU

Summary of Contents for MANTION SMT WIBAT LINTEAU

  • Page 1 INSTALLATION INSTRUCTIONS WIBAT LINTEAU VERSION 1-10 ANG 2, rue des Métiers 21110 – Genlis - FRANCE Tél. : (33) 03 80 37 85 71 Fax : (33) 03 80 37 88 61 http://www.mation-smt.fr...

  • Page 2: Important Safety Instructions

    The assembly steps must be followed, as must the operating instructions, and safety rules must always be heeded. Before installing the shutter motor, check that both the driven part and the entire WIBAT LINTEAU are in good physical condition and that the structure has the necessary load-bearing capacity for the WIBAT LINTEAU in its entirety.
  • Page 3 MANTION SMT shall on no account be liable for drilling and embedding conditions. MANTION SMT shall in any event only be liable for the WIBAT LINTEAU product. The guarantee does not apply in case of overvoltage or short-circuiting resulting for instance from connection errors, weather...

  • Page 4: Caracteristiques Techniques

    CARACTERISTIQUES TECHNIQUES WIBAT LINTEAU is designed for opening and closing swing shutters (one or two leaves). It is designed for domestic use. Tlis product must be install under the windows lintel Minimum width per leaf 0,40 m* Maximum width per leaf 0.8 m*...
  • Page 5 Dimension to check Windows Wall Shutter Opened Windows Wall Shutter closed Dimension A: Distance between wall and outside of shutter: depends on the type of arm, see abacus Dimension B: Distance between frame and hinge centreline: depends on the type of arm, see abacus Dimension C: Distance between window and closed shutter: depends on the type of arm, see abacus Dimension D: Min Distance between the top of shutter = 90 mm if shutter with horizontal bar.
  • Page 6 Contents of the 2 shutters motor set : Radio remote control Or wired switch Arm screw x4 Wall plugs x6 Left and right arm Shaped coupling sleeve X2 Scews x6 Motor 2 Track Track X2 screw x4 Motor 1 + Electronic Track support x4 Cover...
  • Page 7 Before fitting Changing the shutter stops Shutter stop to remove Shutter stop The presence of low shutter stoppers is essential for the proper functioning of the product. Modification of espagnolette. If you have an espagnolette on your shutters, you need to remove the higher part. Make sure the shutters rotate properly.
  • Page 8 Depending on the configuration, refer to the installation instructions: Mounting 2 leaves Mounting 1 leaf, 580 mm lower bay Mounting 1 leaf, upper bay to 580 mm Electrical connection Start up Final assembly Notice radio pairing...
  • Page 9 1-INSTRUCTIONS FOR THE 2 MOTORISATIONS SET 1-1 Before fitting 1-1-1 Motors identification. The shutter with the Overlap will be open the first. WIBAT-LINTEAU is pre-wired to drive the right shutter (see from inside) Le motor with electronic have to be install on the right side (see from inside) Overlap Aux.
  • Page 10 1-1-2 Change wiring according to overlap position If the overlap isn’t on the right shutter you need to reverse the cables M1 with M2. Standard wired with overlap on the right Wire modification if overlap is on the left Black Black Black Black...
  • Page 11 1-2 Mounting the 2 motors 1-2-1 Template use Marks 1, 2, 3: Use to drill the hole for motors 1 and 2 . 1-2-2 Mounting Align the template with the shutter and the wall Marks out the 3 points 1,2,3...
  • Page 12 Repeat the same operations for the second motor. Drill the holes Ø 6 and insert the wall plugs Install the motor without locking the screws. Install the second motor. Check the alignment with motor1 then Lock all the screws.
  • Page 13 Wired the 2d motor. Red with red Black with black Put the 2 motors covers Don’t forget to pass the cables throw the grommet.

  • Page 14: Preparation Before Installation

    2- INSTRUCTION FOR 1 MOTORISATION SET 2-1 Preparation before installation 2-1-1 Motors identification. Wibat LINTEAU is pre-wired to drive the right shutter (see from inside) Le motor with electronic have to be install on the right side. (see from inside) Motor with electronic...
  • Page 15 2-1-2 Change wiring according to the hinges position If the hinges are on the left side (see from outside), the motor’s connection has to be change: Reverse the red and black cable from M1 Standard wired with hinges on the right Wired modification if hinges are on the left Black Black...
  • Page 16 2-2 Mounting the motor for shutter less than 580mm 2-2-1 Template use Marks 1, 2, 3: Use to drill the hole for motors 1. 2-2-2 Mounting Align the template with the shutter and the wall Mark the drill position 1,2,3 For motor...
  • Page 17 Drill the holes Ø6 and insert the wall plugs Install the motor and verify the alignment before locking the screws. Put the motor cover Don’t forget to pass the cable throw the grommet.
  • Page 18 2-3 Mounting the motor for shutter more than 580 mm 2-3-1 Template use Marks 1, 2, 3: Use to drill the hole for motors 1. Marks 4,5,6,7: Use to drill the position of the extension on the right side 2-3-2 Mounting Align the template with the shutter and the wall...
  • Page 19 Drill the holes diam 6 and insert the wall plugs Align the template with the shutter and the wall Mark the drill position 1,2,3 For motor...
  • Page 20 Install the motor without locking the screws. Install the extension. Check the alignment with motor1 then Lock all the screws. Put the motor and extension cover Don’t forget to pass the cable throw the grommet.
  • Page 21 3- Fitting the tracks NB: for 400 mm shutters the rail must be placed on the outer edge of the shutter. 3-1 Mark the A position of the roller center with the shutter open. 3-2 Mark the B position of the roller center with the shutter close Put 2 marks, name C, at 26mm under the cover to help you to align the track.
  • Page 22 3-4 Mount the 2 end pieces and bring the shutter close to the track. Position the rail in such a way that the distance between the marks and the screw holes is the same on either side. 3-5 Align the bottom track using the 2 marks C at 26mm and check the level before to tighten the screws 3-6 Check that the shutter rotates properly.

  • Page 23: Electrical Connection

    ELECTRICAL CONNECTION Pay attention to your safety: The electrical installation must be carried out in accordance with the national standards in force, as well as any obligations foreseen by the law and/or by all obligations in force, laid down for this purpose. Electrical connection must take place without voltage: Do not connect the sector before having disconnected all assembly operations.
  • Page 24 Connect the wired switch Pull down keys of the switch to make the connection realized a bridge with 0.5 mm² wire WHITE Commun with 0.5 mm² wire BROWN Close with 0.5 mm² wire GREEN Open with 0.5 mm² wire Press one of the buttons and at the same time insert the wire into one of the two cavities located below the button.
  • Page 25 (Open button when opening in progress) (Button closure if closure in progress. WIBAT LINTEAU is equipped with a current-measuring safety device. If any obstacle is detected when the shutter is opening or closing, the shutter reverses its direction and returns to its initial...

  • Page 26: Final Mounting

    Final mounting. After verification that the product is working fine, add the final cover. Centre it between the 2 motors.
  • Page 27 Wireless setup instructions 1 – Radio specifications: Frequency 433.92MHz Transmitter range approx: 70 metres line-of-sight Propagation of radio waves varies according to the medium they traverse. The range of the radio waves will vary according to the type of construction: Plasterboard/Plaster/Wood Brick/Conglomerate Reinforced concrete...
  • Page 28 Peering a timer: 1. Press and hold down the setup button for roughly 5 seconds. The LED comes on (the card is in "radio peering" mode) 2. While the LED is on and not flashing: Refer to the timer's setup instructions. The LED flashes quickly then goes out: the timer is now peered.
  • Page 29 symptoms probable Causes Solutions The motors do not work The control unit is not Check the connection of the control box to powered power supply. The motors operate at Learning problem Repeat the learning procedure (see manual) low speed The motors do not slow Learning problem Repeat the learning procedure (see manual) down at the end of the...
