- Page 1 Owner’s Manual Olympic Dental Table Model 50901, 50903, 50905 Serial # OLYMPIC VETERINARY Phone: 800-789-6867 • Fax 206-905-0839 Web: www.OlympicVeterinary.com 9311 SE 36th Street, Unit 220 Mercer Island, WA 98040 Email: Info@OlyVet.com...
-
Page 2: Table Of Contents
About this Manual This manual contains information on the setup, use and upkeep of the Olympic Dental Table and should be read in its entirety before first use to assure safe operation and optimal performance. This Dental Table has a serial number you will need to reference when seeking technical support. This is stamped on the bottom right corner of the Product Identification Label, which is located at the end of the table top. -
Page 3: Component Identification
Component Identification The following illustration demonstrates the key components of the Dental Table. Figure 1 Item Description Item Description Braking Casters Drain Trough Swivelling Foot switch Table Top Panels Mounting Platform for Compressor Front Head Support Thumbscrews Power Strip Rear Head Support Thumbscrews Power Cord Removable Drain Pan 2-Socket Swing arm... -
Page 4: Introduction
Introduction The Olympic Dental Table is a fully adjustable dental table designed to provide better patient presentation, save time and improve operator comfort. The Dental Table is adjustable in three ways to meet the ergonomic needs of the operator: table is height adjustable from 29"... -
Page 5: Assembly
5. Remove the 2x4 retaining board located in front of the dental table from the floor of the pallet by sliding it out of the slotted enclosure. 6. Position the two included wood ramps in front of the dental table so that the protruding pin at the end of each ramp drops into the matching hole in the floor of the pallet. -
Page 6: Quick-Start Instructions
Quick-Start Instructions Note: This section is intended for use only after you have read and familiarized yourself with the entire contents of this manual. Refer to Figure 1 for component identification. 1. Lock all 4 casters 2. Plug the Power Cord into a suitable 120V/60Hz grounded wall outlet. -
Page 7: V-Table Dorsal Positioning Adjustment
V-Table Dorsal Positioning Adjustment The table top on your Olympic Dental Table consists of two panels, each hinged at the center of the table. Adjust the V-Table panels to the desired angle for dorsal positioning by depressing and holding each V-Positioner Lock Lever while raising the panel to the desired angle. -
Page 8: Cleaning
Weight – 275 pounds Ordering Information 50901 – Olympic Dental Table with 1 Swing Arm with 2 sockets for accessories. Includes 1 Instrument Tray. 50903 – Olympic Dental Table with 2 Swing Arms with 2 sockets for accessories on each arm. -
Page 9: Warranty
3-Year Unconditional Warranty The Olympic Dental Table (model 50901, 50903, 50905) is unconditionally warranteed for a period of three (3) years from the date of invoice. Olympic Veterinary will elect to repair or replace a defective component without charge within the warranty period.
