- Page 1 Owner’s Manual Olympic Dental Table Model #50901, 50903 Serial # OLYMPIC VETERINARY Phone: 800-789-6867 • Fax 206-905-0839 Web: www.OlympicVeterinary.com 9311 SE 36th Street, Unit 220 Mercer Island, WA 98040 Email: Info@OlympicVeterinary.com...
-
Page 2: Table Of Contents
About this Manual This manual contains information on the setup, use and upkeep of the Olympic Dental Table and should be read in its entirety before first use to assure safe operation and optimal performance. This Dental Table has a serial number you will need to reference when seeking technical support. This is stamped on the bottom right corner of the Product Identification Label, which is located at the end of the table top. -
Page 3: Component Identification
Component Identification The following illustration demonstrates the key components of the Dental Table. Figure 1 Item Description Item Description Braking Casters Tie-down Cleats Swiveling Foot Switch Drain Trough Mounting Platform for Compressor Table Top Panels Power Strip Front Head Support Thumbscrews Power Cord Rear Head Support Thumbscrews Instrument Tray Arm with Mounting Plate... -
Page 4: Introduction
Introduction The Olympic Dental Table is a fully adjustable dental table designed to provide better patient presentation, save time and improve operator comfort. The Dental Table is adjustable in four ways to meet the needs of the operator: Height adjustable from 29" to 41". Table Top can be tilted down to a maximum of 10 degrees for drainage. -
Page 5: Assembly
6. Position the two included wood ramps in front of the dental table so that the protruding pin at the end of each ramp drops into the matching hole in the floor of the pallet. Test ramp to assure it is securely attached. 7. -
Page 6: Operation
Caution: To avoid damage to the Instrument Tray while tilting the table top down, make sure it is not directly beneath the Removable Drain Pan Caution: To prevent the table from tilting suddenly, always maintain a firm grip on the table top while depressing the Tilt Lever. -
Page 7: Instrument Tray Adjustment
Table Tilt Adjustment The tilt of the Olympic Dental Table may be adjusted to any angle up to 10 degrees by pressing on the Tilt Lever while simultaneously lifting or lowering the end of the table closest to the lever. Releasing the lever will lock the table at the desired tilt angle. -
Page 8: Routine Maintenance
The Dental Table requires no other routine maintenance. For any questions about the use or maintenance of the Dental Table, please call 1-800-789-6768. Specifications Olympic Dental Table – Model #50901, 50903 Capacity – 250 pounds with centered load V-Positioner Range – zero to 45 degrees (each side) Table size –... -
Page 9: Warranty
Should your Olympic Dental Table, as the result of normal use, require any repair within 3 years after purchase, all replacement parts and labor will be furnished free of charge. Contact Us Olympic Veterinary Corporation, Customer Service 9311 SE 36th Street, Unit 220 Mercer Island, WA 98040...
