- Page 1 2823 & 2823-REF High-Precision C, L & tan δ Measuring Bridge Quick Start Guide 4844145 | Version 0.3...
- Page 2 Title 2823 & 2823-REF Quick Start Guide Date 05-2017 Authors Layout Part number 4844145 Revision History Date Version Author Remarks 24.05.17 Initial release of the document 28.06.17 Installation to be run as administrator and small changes 30.03.20 Logos Update Safety...
-
Page 3: Mains Connection
All repairs and upgrades that require the unit to be opened must be referred to HAEFELY TEST AG or one of their nominated agents. This equipment must be operated only by trained and competent personnel who are aware of the dangers and hazards involved in testing transformers and other HV apparatus. -
Page 4: Installation
With the purchase of this measuring instrument you have opted for all the advantages that have built a world- wide reputation for a Haefely Instrument: robustness, performance and quality is assured. As a result this instrument provides a solution which achieves the optimal combination of traditional know-how and leading edge technology. -
Page 5: Instrument Setup
To take benefit of the galvanic isolation and increase the operator safety, it is recommended to install the 2823 inside the High voltage laboratory, either fixed in a plate in the button of the nominal capacitor or at any other location inside the high voltage laboratory. -
Page 6: Instrument Connections
Instrument connections Connections to the instrument should be done as in the Figure 3-3. Main attention to connect the HV ground first. Lemo type connectors for C and C have a rotary screw at the end to be locked/unlocked. Make sure the Lemo connector is locked after plugging in. - Page 7 V and Ground Connected Figure 3-6 UST and GST Selection in the 2823 Electrical connection between the V(supply) point from the back of the 2823 and the low voltage point of the high voltage power supply is required. Missing this connection can end in instrument damages.
- Page 8 V Connection This 2823 is able to measure capacitances with highest accuracy to determine trending analysis of insulating materials. Depending on the measuring circuit it could exist other capacitances (ex. stray capacitances) measured together with the DUT that can influence the measured values significantly.
-
Page 9: Computer Connection
Media Converter Setup Media Box connections The connection of the Fiber optic cable and USB cable to the media Box is shown in the figure Figure 3-7. Figure 3-7 Media converter connection Computer connection The USB cable from the media converter should be connected to any available USB port with power supply in the computer. -
Page 10: Software Installation
Windows. The installation starts automatically after the installation of the 2823 software. 6. Select “Automatically start the WinPCap” at boot time Once software is installed, a new icon and application group will appears in the desktop and start menu respectively called 2823. Installation... - Page 11 It is recommend to use always the same USB port to connect the media converter to the computer The driver for the media box is installed together with the 2823 software. Therefore no manual installation required. Once the media converter is plugged for first time to an empty USB port, an additional Ethernet port should be available.
-
Page 12: Starting The Software
If communication with the 2823 fails, “not connected” error will arise in the upper band and measurements will not be possible. Possible reasons are. 1. 2823 has not been switched on, make sure the mains switched is in I position and the green led beside is on. - Page 13 2. Communication cable between 2823 and media converter not properly connected. 3. Incorrect Ethernet communication settings, double check the communication settings following carefully the instructions in the “computer communications settings” chapter The main options of the software are located on the right side of the screen, including Setup, Manual, Sequence and Analysis.
- Page 14 1. Go to Setup -> DUT Info and Introduce the desired information, no field is mandatory. Tan δ (power factor) varies with the temperature for some test objects. The 2823 can automatically compensate this variation and refers the values at reference temperature. 1. In Ambient->Temperature introduce the ambient temperature 2.
-
Page 15: Additional Information
Please check the manual for further information about the instrument use or troubleshooting. If persistent problems or faulty operation should occur then please contact the Customer Support Department of HAEFELY TEST AG or your local agent. The Customer Support Department can be reached at the following postal... - Page 16 Additional information...
