- Page 1 WIFI GRILLE DOOR LOCK User Manual...
-
Page 2: Table Of Contents
6.6. Lock Settings ....................... 15 6.6.1. Passage Mode Setting ................15 6.6.2. Mute Mode Setting ..................15 6.6.3. Factory Reset Mode ..................15 6.6.4. Language Setting ..................15 App User Manual ....................... 16 7.1. App Download ....................16 AVANT GUARD... - Page 3 How to connect door lock to App ..............16 7.3. App Functions ..................... 17 7.3.1. Battery Status ....................17 7.3.2. Temporary Password ................... 17 7.3.3. Remote Unlocking via app ................. 18 7.3.4. Records ......................19 Parameters ......................... 21 AVANT GUARD...
-
Page 4: Warning And Safety Instructions
For safety purposes, when 5 continuous entry error detected smart lock will enter self-protection mode and keyboard panel will freeze for 1 minute. Please read this user manual carefully before first use. Keep this manual for further guidance in case. AVANT GUARD... -
Page 5: Product Layout
Product Layout Smart lock installation requires heavy duty tools handling. Please engage professionals for proper installation. Our company shall not be liable for any direct or indirect problems, hazards or losses incurred due to improper installation. AVANT GUARD... -
Page 6: Components
Components Front and back lock panels Mortise Lock body iii. Cylinder lock IC Card x 2 Mechanical keys x 2 Lithium Battery x 1 3.1. Accessories List AVANT GUARD... -
Page 7: Installations
Installations AVANT GUARD... - Page 8 AVANT GUARD...
-
Page 9: Lock Functions
Lock Functions 5.1. Unlocking Methods 5.1.1. Fingerprint 5.1.2. Password AVANT GUARD... -
Page 10: Card
5.1.3. Card 5.1.4. Key AVANT GUARD... -
Page 11: App
5.1.5. App Press “6” + “#” to activate doorbell function Receive doorbel call notication on app iii. Open app and select smart lock Press on “Click open remotely”, then press on “Confirm” to allow remote opening Door unlocked. AVANT GUARD... -
Page 12: Temporary Password
5.1.6. Temporary Password 5.2. Locking Methods 5.2.1. Deadbolt Locking To engage deadbolts locking rotate the internal or external door handle upwards. AVANT GUARD... -
Page 13: Operations
Press “#” for confirm key or menu function key iii. Press “6” + “#” for Doorbell key Swipe panel to activate keypad 6.3. Enter Administrator mode Swipe panel to activate screen Enter “*” + “#” iii. Enter Administrator Information (password, fingerprint, or card) Enter function management AVANT GUARD... -
Page 14: Administrator Settings
Password or Scan Card •Press "#" 6.5.2. Delete User 1. Add User Enter Unlock Information Delete OK 2. Delete User 3. Passage Mode 4. Mute Mode 5. Add Master •Scan Fingerprint or Enter •Press 2 Password or Scan Card •Press "#" AVANT GUARD... -
Page 15: Lock Settings
5. Add Master •All info and records •Enter "666" + "#" •Press 2 cleared. •Initial password is "123456" 6.6.4. Language Setting Run Factory Reset Mode Enter Code Language Changed •Press 2 •Enter "555666333" + "#" •Chinese & English Available AVANT GUARD... -
Page 16: App User Manual
Select 2.4GHz WiFi network and enter password. If Wi-Fi is 5GHz, please set it to be 2.4GHz. vii. On smart lock tap “*” + “#” to enter function management. viii. Enter Admin information. Select “1” to add user. Ignore the “Enter Unlock Information”. Wait to connect device. Connection successful. AVANT GUARD... -
Page 17: App Functions
On the smart lock control panel, tap on the “Temporary PW”. Tap the button in the upper right corner to create new temporary password. iii. Enter password, name, and effective time period. Password is limited to number 1 – 6. AVANT GUARD... -
Page 18: Remote Unlocking Via App
Press on “6” + “#” on door lock Doorbell call notification received. Open app. iii. Press on “Click open remotely” Click on “Confirm” to allow remote opening. Door unlocked. If unattended after 6 seconds, door will be automatically locked. AVANT GUARD... -
Page 19: Records
Smart lock touch panel will be deactivated for 1 minute. 7.3.4.3. Prying Alarm Alarm and phone notification alert when tampering attempt is detected at smart lock. Alarm siren at smart lock will be activated to scare off possible intruders. AVANT GUARD... - Page 20 Tap member management. Associate A with a username and mark A as a hijacking alarm. This helps locate the hijacked person. Use A to unlock the door. A hijacking alarm will be sent to the app’s Message Centre. AVANT GUARD...
-
Page 21: Parameters
Quiescent Current <50 μA Working Current <250 μA Fingerprints <=100 (9 Admin, 91 Users) Cards <=300 (9 Admin, 291 Users) Passwords <=300 (9 Admin, 291 Users) Working Temperature C ~ 60 ° ° Working Humidity 20% ~ 93% AVANT GUARD...
