C
We reserve the right to change or revise specifications
and product design in connection with any feature of
our products. Such changes do not entitle the buyer to
corresponding changes, improvements, additions or
replacements for equipment previously sold or shipped.
Item Part #
Description
F
A
AN
SSEMBLIES
4 Ft, 8 Ft & 12 Ft
A. 12W Standard Fan Assembly
0047000
Fan Motor, Evaporator
(MO.4410103)
0461805
Fan Blade (FB.4780446)
12W Energy Efficient Fan Assembly
0477655
Fan Motor, Evaporator
(MO.4410546)
0461805
Fan Blade (FB.4780446)
6 Ft Only
A. 7W Standard Fan Assembly
0058698
Fan Motor, Evaporator
(MO.4410102)
0142780
Fan Blade (FB.0142780)
7W Energy Efficient Fan Assembly
0477654
Fan Motor, Evaporator
(MO.4410545)
0142780
Fan Blade (FB.0142780)
Note: Changed items have been underlined.
©2008 HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
U.S. & CANADA 1-800-922-1919 • MEXICO 1-800-522-1900 • WWW.HUSSMANN.COM
B
Wiring Item #
C
E
D
Item Part #
T
HERMOSTATS
B. Optional Adjustable Refrigeration Thermostat (2)
(1)
L
B
AMPS AND
ALLASTS
C. Ballast, Electronic
0480130
0480131
(1)
0480132
D.
E. 0501213
(1)
F.
(1)
B4X-E
Technical Data Sheet
P/N 0501013_B
NSF
®
March 2008
D
D
F
A
Description
Wiring Item #
2 lamps (BA.4481676)
3 lamps (BA.4481654)
4 lamps (BA.4481677)
Fluorescent Lamp
Replace with like fixtures
Power Supply (EP.4481861)
LED Fixture
Replace with like fixtures
P/N 0501013_B
Certified
(3)
(4)
(5)
(6)
