Please be sure and remove all parts from your box and assemble your new furniture on a blanket so
you don't damage your new furniture while assembling. Do not over tighten!!! Over tightening of
hardware can cause damage to the item.
HARDWARE
Glider Arms
A
x4
1/4" x 3" Carriage Bolts
D
x6
TOOLS
For assembling this product, you need the following tools:
#2 Square Tip Bit with Drill
STEP 1
Glider Base Assembly
a. Locate the Left Glider Base (5) and Right Glider base (6) as well as 2pcs. 14 1/4" Stretcher Boards (7).
b. Place Stretcher Boards in the the small incuts located on the Glider Base.
c. Use 6pcs. 2 1/2" Polybuster Screws (E) to fasten each side (small pilot holes) - repeat on the other side.
E
3/8" x 2 3/4" Carriage Bolts
2 1/2"
Polybuster Screws
E
x12
Wrench 7/16" and 9/16"
E
E
E
5
Questions in regards to your product email support@daybreakoutdoor.com
A S S E M B L Y I N S T R U C T I O N S
PRODUCT NAME: #1304 Rollback Glider
3
5
B
x4
3/8"
Flange Nut
F
x4
7
5
E
E
E
1
2
7
7
1/4" x 4" Carriage Bolts
C
x4
3/8"
Lock Nut
G
x8
Assembly time: 20 min
Soft Rubber Mallet
E
6
E
E
7
4
6
1/4"
Flange Nut
H
x10
E
E
E
Page 1/2
