- Page 1 User Manual Digital Weighing Scales User’s Series Manua Digital Weighing Scale...
- Page 2 ASW Weighing Scale User Manual...
- Page 3 Cautions Upon receiving the scale, please take at least 8 hours to recharge the battery before you start to operate this scale. Please recharge the battery after a long period of storage (more than one month). It takes 8~10 hours to fully recharge the battery.
- Page 4 Dimension The below panel & keypad are suitable for table scale/ Indicator/bench scale/floor scale. ※Installation Diagram of Bench Scale: please see page 7. ASW Weighing Scale User Manual...
-
Page 5: Symbols On Lcd
Symbols on LCD Zero Symbol appears on the left-bottom corner of LCD, and indicates the scale is at zero-point. NET Weight Symbol on the bottom edge of LCD, and indicates Net appears the tare weight has been deducted. ... - Page 6 Battery Symbol - When LCD indicates and the scale sounds - beep for four times, it means the battery is running in low-voltage status. LCD will indicate - continuously for reminding the user to recharge the battery.
- Page 7 Press this key to deduct the tare weight. Put the package or container on the platter and then press [TARE] key. LCD will show RS232 Interface Connection: <optional device> 5 4 3 2 1 5 4 3 2 1 DATA OUT 9 8 7 6 9 8 7 6...
-
Page 8: Recharge The Battery
Recharge the Battery Power off the scale and connect the power cord to an AC outlet. CHARGE LED will indicate the ongoing status of the battery. It takes about 8~10 hours to fully recharge the battery. CHARGE LED: Color of LED Status of the battery Initial connection ORANGE... -
Page 9: Installation Procedure
Installation Diagram of Bench Scale List of Components: Item <1> Indicator <2> Regulator <3> Stainless Steel Tube <4> Tube Base <5> Stainless Steel Platter <6> Main Structure <7> Cable of Load Cell <8> Connector Installation Procedure: A. Screw <4> Tube Base and <6> Main Structure together (with 2 screws of Tube Base). - Page 10 Note: ASW Weighing Scale User Manual...
- Page 11 ASW Weighing Scale User Manual...
- Page 12 Digital Weighing Scale We do more than you expect ASW Weighing Scale User Manual...
