Waver Smart One WAC52N Quick Start Manual

Hide thumbs Also See for Smart One WAC52N:
Table of Contents

Advertisement

Quick Links

QUICK START GUIDE
READ CAREFULLY BEFORE USING THE DEVICE
WAC52N | WAC52N+
WAC52G | WAC52G+
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Smart One WAC52N and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Waver Smart One WAC52N

Summary of Contents for Waver Smart One WAC52N

  • Page 1 QUICK START GUIDE READ CAREFULLY BEFORE USING THE DEVICE WAC52N | WAC52N+ WAC52G | WAC52G+...
  • Page 2 Apple Safari • Broadband Internet Connection (Ethernet) Thank you for choosing our product! Your satisfaction is our top priority. Propose a feature that will be useful to be added on Waver SmartOne in the upcoming software updates at features@wavertech.eu...

  • Page 3: Table Of Contents

    • Read this manual thoroughly before using Waver SmartOne • To ensure proper use of the device, make sure to read “Safety Information” page • After reading, keep it in a readily accessible place for future reference CONTENTS - Safety Information...

  • Page 4: Safety Information

    Safety Information - Use only the supplied Power Adapter. Connection to a different power source may result in improper operation, damage or pose to fire hazard. - Do not cover ventilation holes at the bottom. This product must be operated on a flat surface far from any heater or heating vent. - Avoid direct irradiation of any strong light (such as sunlight) - Keep at least 5 cm of clear space around the device - Operating Temperature: - 20 - 60°...

  • Page 5: Hardware Installation

    (N Series only - with PoE Out 24V) 8. DC Power Jack 9. ON/OFF Switch Hardware Installation To install the Waver SmartOne router, perform the following steps: Connect Ethernet cable from you DSL/Cable modem to the INTERNET Port of Waver SmartOne Router.
  • Page 6 The boot process will start. After a while the power LED will light up. IMPORTANT NEVER DISCONNECT POWER OR TURN OFF THE DEVICE a. During the boot process (it takes about 1 minute and 30 seconds to boot up) b. During Reboot process c.

  • Page 7: Device Management

    Device can be managed via any web browser. Access to the web interface is available from LAN Ports, Local WiFi Inter- faces (local network) and Internet Port. Web Management tools 1. Administration Interface Default access: http://192.168.10.1 Username: admin Password: waver...
  • Page 8 2. User manager Interface User Manager “admin” password: waver Default access: http://192.168.10.1/userman/ (same account with administration interface) User Manager “manager” password: password Default access: http://192.168.10.1/userman/ (limited access account for accessing User Manager) 3. Discount Coupon Code manager Discount Code Manager password: password...
  • Page 9 4. Customization Panel (Whitelabeling) To access this panel, you are going to need a unique customization key. This key is being generated separately for each device. 1. Administration Interface The main administration interface. Networking, guest ses- sion, captive portal settings, customization and management for the local device.
  • Page 10 “I agree the terms and conditions” checkbox and click on the “Login button”. The MAIN page of configuration interface will appear. You are logged in and you can configure your Waver SmartOne router. An overview on the administration interface MAIN: Shows general guest user data statistics, device information, interface throughput and con- nectivity status.
  • Page 11 WAN | LAN Configures Internet connectivity type, Firewall and Port forwarding, Website Filtering and Local Net- work Settings.
  • Page 12 WIRELESS Shows wireless interface information and statistics, Configures interface and wireless networks settings.
  • Page 13 GUEST NETWORK Configures network parameters for guest network. It shows information regarding devices on the guest network.
  • Page 14 CAPTIVE PORTAL Configures the guest landing page appearance and the way guests are authenticated on your guest network.
  • Page 15 GUEST USERS | STATISTICS Analytic guest user data statistics. The synchroniza- tion of user data with third party or external systems can also be managed on this page.
  • Page 16 DISCOUNT COUPONS Controls the discount coupons and Email/SMS discount coupons generation. Discount coupons are based on guest visit count (user login counting).
  • Page 17 SYSTEM Gives you access to system settings, security, data retention and system timezone. Here you will find also firmware update and networking tools.
  • Page 18 Securing the device 1 - Login to the Administration interface 2 - Go to SYSTEM - SECURITY tab Enter a strong password in all the new password fields as maked below Enter the same password in each confirm new password field and click the “Save”...
  • Page 19 Securing Local Wireless Networks In the Administration interface go to WIRELESS -> LOCAL WIRELESS tab. Enter a name for your wireless network in the SSID field Enable security for wireless network Enter a passphrase in the WPA2 Key field Click on the “Save” button The same way you can manage SSID and Security for Local 5GHz and guest wireless interfaces...
  • Page 20 2. User Manager A powerful Web tool for managing user/pass credentials used by Username authentication in captive portal and pay- ment portal. With user manager you can customize Printable tickets, Payment Portal appearance, Payment plans pricing, limits etc. It reports to admin details like PayPal Statistics, Logging of users adding or removal.
  • Page 21 3. Discount Coupon Codes Manager A mobile friendly coupon code manager tool for use by em- ployees to check coupon code validity and redeem the active ones. Discount coupons generation can be managed by Adminis- tration Interface -> DISCOUNT COUPONS tab.
  • Page 22 Customization panel gives the ability to companies and inte- grators to modify the software and use their own logo, page titles and EULA texts instead of Waver defaults. Changes are permanent, which means that even a full factory reset will not affect these settings.

  • Page 23: Firmware Update & Reset

    Firmware Update & Reset UPDATE PROCEDURE: 1 - Download device firmware from our website 2 - Login to the Administration interface 3 - Go to SYSTEM - MAINTENANCE tab 4 - Upload the downloaded .bin firmware file 5 - Press the reboot button and confirm when you will be prompted to reboot the device 6 - Wait a few minutes until the boot procedure finishes up (approx 3 minutes)

  • Page 24: Multilingual Instructions

    Multilingual Instructions EN. Instruction manual: Connect the power adapter to turn on the device. Open 192.168.10.1 in your web browser, to configure it. More information on https://www.wavertech.eu/downloads BG. Инструкция: Свържете адаптера на захранване, за да включите устройството. Отворете 192.168.10.1 в уеб браузър, за да настроите...
  • Page 25 IT. Manuale di istruzioni: Collegare l’adattatore di alimentazione per accendere l’unita. Aprire 192.168.10.1 in un browser Web per configurare il prodotto. Maggiori informazioni in https://www.wavertech.eu/downloads LV. Lietošanas instrukcija: Pievienojiet Strāvas adapteri, lai ieslēgtu ierīci. Atvērt 192.168.10.1 ar interneta pārlūku, lai konfigurētu produktu. Plašāka informācija https://www.wavertech.eu/downloads LT.
  • Page 26 SK. Navod na použitie: Pripojte napajaci adapter k zapnutiu pristroja. Otvorte 192.168.10.1 vo webovom prehliadači pre konfiguraciu produktu. Viac informacii najdete v https://www.wavertech.eu/downloads SI. Navodila: Priključite napajalnik za vklop naprave. Odprite 192.168.10.1 v splet- nem brskalniku nastaviti izdelek. Več informacij v https://www.wavertech.eu/downloads FI.

  • Page 27: Warranty And Returns

    Limited Warranty & Returns WAVERTECH LTD. (“WAVERTECH”) warrants that the product(s) provided hereunder (the “Product(s)”) will be free from defects in material and workmanship for a period of twenty four (24) months. The warranty duration begins from the date of purchase by the customer from WAVERTECH or its authorized representatives.
  • Page 28 Returns of defective products During the warranty period defective products are accepted for repair or replacement only if they are accompanied by a Return Materials Authorization (RMA) number from WAVERTECH, details on the RMA process are available at: https://www.wavertech.eu/support under the Returns Policy section.

  • Page 29: Declaration Of Conformity

    Směrnice 2014/53/EU. [DK] Danish Undertegnede WAVERTECH erklarer herved, at folgende udstyr WAVER SMART ONE overholder de vasentlige krav og ovrige relevante krav i direktiv 2014/53/EU. [DE] German Hiermit erklart WAVERTECH dass sich das Gerat WAVER SMART...
  • Page 30 2014/53/ EU iranyelvben meghatarozott vonatkozo rendelkezeseket. [NL] Dutch Hierbij verklaart WAVERTECH dat het toestel l WAVER SMART ONE in overeenstemming is met de essentiele eisen en de andere relevante bepalin-gen van richtlijn 2014/53/EU.
  • Page 31 WAVERTECH tymto vyhlasuje, že WAVER SMART ONE spĺňa zak- ladne požiadavky a všetky prislušne ustanovenia Smernice 2014/53/ [SI] Slovenian WAVERTECH izjavlja, da je ta WAVER SMART ONE v skladu z bistven- imi zahtevami in drugimi relevantnimi določili direktive 2014/53/EU. [FI] Finish...

  • Page 32: Technical Specifications

    Technical Specifications Fast Ethernet Inter- 1x WAN/Internet, 4x LAN, faces 1x Guest Port With Passive PoE out Dual Chain 2.4GHz 802.11b/g/n Wireless Interfaces Single Chain 5GHz 802.11a/n/ac Concurrent Active 200 - WAC52N Model Guests 500 - WAC52N+ Model Power On/Off, Factory Reset Buttons 2.4GHz Radio, 5GHz Radio Maximum supported...
  • Page 33 1x GbE WAN/Internet, 4x LAN Fast Ethernet, Ethernet Interfaces 1x GbE Guest Port Dual Chain 2.4GHz 802.11b/g/n Wireless Interfaces Dual Chain 5GHz 802.11a/n/ac Wave-2 Concurrent Active 200 - WAC52G Model Guests 500 - WAC52G+ Model Power On/Off, Factory Reset Buttons 2.4GHz Radio, 5GHz Radio Maximum supported 1 Gbps...
  • Page 34 Industry Canada This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause unde- sired operation of the device.
  • Page 35 Support www.wavertech.eu/support Downloads www.wavertech.eu/downloads Document date 16/01/2020...
  • Page 36 Quick Start Guide WAVER SMARTONE WAC52N/WAC52N+ WAC52G/WAC52G+ www.wavertech.eu ©2020 Wavertech Ltd. Europe. All rights reserved.
