CreativeStar Artemis TI-CS-T11 Quick Manual

Thermal scanner
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
TI-CS-T11 Quick Guide
Product By:
CreativeStar Solutions
1601 Trapelo Road Suite 260
Waltham, MA
V1.0.3
June 2020
02451

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Artemis TI-CS-T11 and is the answer not in the manual?

Questions and answers

Related Manuals for CreativeStar Artemis TI-CS-T11

Summary of Contents for CreativeStar Artemis TI-CS-T11

  • Page 1 TI-CS-T11 Quick Guide Product By: CreativeStar Solutions 1601 Trapelo Road Suite 260 Waltham, MA V1.0.3 June 2020 02451...

  • Page 2: Computer Configuration Requirements

    Computer configuration requirements Recommended configuration, CPU i7, 16GB RAM • Window 7 or Window 10 • The software and electronic manuals are stored on the SD card that comes with the package. Please unzip the files to the folder as required and install the software.

  • Page 3: Hardware Connection

    Hardware Installation Quick Setup Hardware connection The aviation connector is used to connect the equipment. When installing, please insert the aviation plug into the aviation receptacle, make sure that the pins are inserted into the receptacle properly, then twist the metal lock ring clockwise, and then complete the installation after hearing a "click".

  • Page 4: Recommended Installation Environment

    Recommended installation environment The temperature measurement principle of the infrared camera is measured by collecting infrared radiation from the surface of the human body. The accuracy of temperature measurement is affected by environmental conditions related to infrared transmission, especially air flow, air transmission rate, environmental humidity, environment temperature, and other factors.
  • Page 6 Software Installation Quick Setup The required software and electronic manuals are saved on a USB flash disk (or a SD card) that comes with the package. Thermal Scanner Software Find the T11 setup software in the SD card. Right-click on T11_setup_Vx.x.x.x.exe and click Run as administrator. Choose your preferred language, and click OK.
  • Page 8 Temperature Measurement Software 1. Find the ODS setup software in the SD card. 2. Right-click on ODS_setup_Vx.x.x.x.exe and click Run as administrator. 3. Choose your preferred language, and click OK. 4. Follow the instructions until successful installation.
  • Page 10 IP Address Setup Click Start Menu > Control Panel > Network and Sharing Center or Network and Internet > Network and Sharing Center. 2. Click Change adapter settings. 3. Right-click on Ethernet, and click Properties. Select Internet Protocol Version 4 (TCP/IPv4), and click Properties.
  • Page 11 5. Set the IP address to 192.168.1.XXX. Note: XXX can be set to1-255, except for 64 and 65. 6. Click OK.

  • Page 12: Software Startup

    Software Startup 1. Right-click on the Human body temperature measuring server icon, and click Run as administrator. Note: Please keep this server running and do NOT close the window when you are running the T11 temperature measurement software. You can minimize the window of the Human body temperature measuring server.
  • Page 13 3. Enter the Username and Password, and click Login. Username: admin Password: Abc.12345 4. Click Info Mgt > Video Manager. 5. Click Add. The Add Video dialog box displays. 6. Add IP Address: 192.168.1.64 for Light Video • 192.168.1.65 for IRD Video •...

  • Page 14: Configuration Setup

    Configuration Setup 1. Right-click on WebPlugin.exe, and click Run as administrator to start installing the web plug-in for IE browser to configure the Thermal Scanner Software. 2. Choose your preferred language. 3. Follow the instructions until successful installation. 4. Open IE browser and type in 192.168.1.65. Note: It is recommended to use the 32-bit Internet Explorer to configure the Thermal Scanner Software.
  • Page 15 Click the Setting tab. 7. On the Body temperature detection sub-tab, select the Body temperature detection enable checkbox.
  • Page 16 8. Click the Blackbody parameter sub-tab, select the Blackbody real-time calibration checkbox, and set the Blackbody temperature to the same value as the temperature that you set on the blackbody. Note: This step is applicable only if you use T11 together with a blackbody. If the blackbody is not used, the Blackbody real-time calibration checkbox must be deselected.
  • Page 17 11. After all these settings, you can run the TI-CS-T11 software to start measurement. Note: It may take up to 2-3 minutes for the cameras to finish self-diagnosis after each start-up. Therefore, it is recommended that you run the software 2-3 minutes after you power on the equipment.

  • Page 18: Time Synchronization

    Time Synchronization ONVIF Device Manager is an open-source software application used to administrate network video servers and cameras. 1. Double click the Onvif Device Manager.msi software to start installing the Onvif Device Manager. 2. Follow the instructions until successful installation. 3.
  • Page 19 Note: If the device has not been detected and displayed automatically: • Check the connection and click Refresh. • From the navigation panel, click Add to manually add the two cameras. 5. Select a device from the device list, e.g., IPC. The device menu displays. 6.
  • Page 20 10. Repeat steps 5-9 to set up the time for the other camera. Note: Please make sure that you use the same time settings for the two cameras. Note: For more detailed instructions, please refer to the full manual. CreativeStar Solutions 1601 Trapelo Road Suite 260 Waltham, MA 02451 info@cssinco.com...
