    1. Product Summary Artemis TI-CS-T1 is a specially designed infrared human body temperature measurement camera, which has the characteristics of accurate temperature measurement, real-time imaging, automatic high temperature tracking, fast aiming, etc. It can be used for human body temperature measurement in public places, in order to prevent the spread of disease.
  • Page 6: Battery And Charger

    2. Battery and Charger It is recommended to charge battery immediately when the device indicates low power. For detailed information on how to change a battery, please refer to Section 4.1 Battery Setting on page 7. The device is equipped with two sets of lithium-ion batteries and a battery charger.
  • Page 7: Panel Function Summary

    3. Panel Function Summary In this manual, a “long press” means pressing a button down for about 2 seconds, and a “press” or a “short press” means pressing and releasing right away. 3.1 Main Control Panel 1. Power LED Light After the infrared camera is turned on, the indicator light will display as a green power indicator;...
  • Page 8 temperature limits. Long press to turn on/off the laser. 4, 5, 6,7 Direction buttons Up ( ), Down ( ), Left ( ), and Right ( ) keys have different usages in different modes. In the main menu, direction buttons are used for moving selected items or changing slide-bar values.
  • Page 9: Side View

    manually rectify measurement result, LCD screen will display the word “rectifying”. 4). In image viewing mode, long press this button to exit. : After auto rectifying, if device has abnormal noise, long press button to perform manual rectifying usually solves such issues. 9, 10, Manual Focus (T / W) button Press T/W button to manually focus to get better thermal image when auto-focus thermal image is not good enough.
  • Page 10: Bottom View

    17. USB Interface Standard USB interface can be connected to the computer for data transmission. 3.3 Bottom View 18. External DC In External DC requirement is DC 5V. 19. Screw nut on tripod Size of screw nut on tripod 1/4” _20. 3.4 Left Side View 20.
  • Page 11: Quick Start Reference

    4. Quick Start Reference 4.1 Battery Setting Insert and move the lithium battery in the direction indicated, users can easily insert and move the battery. Battery Installation Battery Removal 4.2 Quick Operations Insert the battery correctly. Long press Power button until the LED light is on, and wait until system finishes initialization.
  • Page 12: Measure Target Temperature

    4.3 Measure Target Temperature Adjust the position of the thermal imaging camera so that the image of the object moves to the cross temperature measurement point on the screen. The "*=××" (* indicates the number value of temperature measurement points 1, 2, 3, and 4) is the temperature of the target at the point.
  • Page 13: Infrared Image Playback

    4.5 Infrared Image Playback Press the Enter button to enter the main menu. Select the Main Menu → File → Manage, and then select the file directory and file name, the thumbnail image of the stored image is displayed, then press the Enter button to enter the viewing state. When viewing thermal image, press the Left ( ) or Right ( button to switch thermal image in the same folder.
  • Page 14: Operation Menu

    5. Operation Menu 5.1 Display Summary All items can be selected by short pressing HotKey 2 button. (Note: Long pressing Hotkey 2 button will turn on/off laser sight). The selected item is flashing in yellow color. If no operation in 3 seconds after selection, Hotkey mode will exit automatically.
  • Page 15: Main Menu

    under the real-time measurement mode or the preview mode, click key to change infrared images step-by-step in the multiple of 0.1. 3 and 4 indicates temperature Point measure: value of point 1, 2, 3 and 4 respectively. Imaging mode: Infrared, visual, and WIW can be switched by pressing the button.
  • Page 16 Enter the Main Menu: When there is no menu and the shortcut is not selected, click to enter the main menu. The menu is shown in the figure below. In infrared real-time temperature measurement mode, long press execute manual calibration function instead of entering the main menu. Main Menu button to select menu item, and selected item is highlighted with white background.
  • Page 17: File

    button to return to the previous menu or exit. (The key is unavailable to switch under a sub-menu consisting of left or right switchable options). 5.2.1 File The file menu can realize the following operations: preview stored image files, analyze temperature, add voice annotations, delete, format disks, etc.
  • Page 18: Save

    Working directory: The machine automatically creates a new directory when saving the picture. The pictures saved on the same day (based on the clock in the machine) are in the same working directory. The name of the directory is MYYMMDD, where YY, MM, and DD represent the last two digits of the year, month, and day, respectively.
  • Page 19: Record & Play

    Record & Play The Voice menu is used for recording, playing back, save and cancel operations. icon and icon indicate voice annotation data with current thermal image. If voice annotation already exists, press Record will record new voice annotation and erase previously saved one. Press Cancel first to stop recording then press Save to save.
  • Page 20: Format

    Delete saved thermal image Long press the Enter key to exit the preview mode. Format Format the built-in FLASH or SD card. When Press Enter button to Main Menu → Setup → System Setup → Storage Medium to select the “Internal”, then format the built-in FLASH;...
  • Page 21: Measure

    5.2.2 Measure There are 5 items: Spot, Line, Area (Rect), Parameters, and Save Setting in Measure menu. Measure Sub-menu Spot Measure Press button to select or deselect. Selected spot is check marked. Up to 4 spots can be selected at the same time. Spot Target Selection...
  • Page 22 Spot Measure Measure result on upper-right LCD corner is temperature reading at location marked with . Up to 4 spots can be selected. Spot Measure Attribute Press Hotkey button 2 until spot marker is flashing in yellow, and then press Up ( ), Down ( ), Left ( ) and Right (...
  • Page 23: Line Measure

    Line Measure There are 2 line measure options: vertical and horizontal. Horizontal Line Measure Horizontal Line Measure Horizontal line is temperature sampling line, and upper-right LCD corner displays temperature measurement reading on vertical cursor line intersection. After using HotKey button 2 select line measure, press button to adjust sampling line position, and press button to adjust cursor line position.
  • Page 24: Vertical Line Measure

    Vertical Line Measure Vertical Line Measure Vertical line is temperature sampling line, and upper-right LCD corner displays temperature measurement reading on horizontal cursor line intersection. After using HotKey button 2 select line measure, press button to adjust sampling line position, and press button to adjust cursor line position.
  • Page 25: Area (Rect) Measure

    Area (Rect) Measure Press button to select or deselect. Selected Area is check marked. Up to 3 areas can be selected. Area (Rect) Measure Measure result on upper-right LCD corner is the temperature measurement result within the corresponding rectangle. There are 3 measure types: max, min, and average temperature.
  • Page 26: Parameters

    Emissivity: Refer to Appendix: Emissivity of raw materials. Set Reference: Set current area as reference. If selected, all measure result will be relative value to this temperature. Measure Type: Select from max, min, and average. Location / Size: Change the size or position of the temperature measurement area.
  • Page 27: Save Setting

    Distance This value can be omitted if target subject is close to device (less than 10m). Otherwise, set Distance value accordingly to get more accurate temperature reading. Press once to change Distance 0.1m. Long press will change Distance in 1m interval. Humidity This value can be omitted if the target is close to device (less than 1 0 m).
  • Page 28: Image Setup

    Image Setup Image Setup Sub-menu Alarm capture Select whether to enable the alarm capture function when in area measurement. Click to turn this function on or off; when this function is enabled, the system will auto take a picture when the area temp exceeds the set alarm temp.
  • Page 29 When this option is Auto, there is no Isothermal display. Otherwise, target subject Infrared image will change to selected color when temperature is within the range of (Isothermal Temp ± Isothermal Width/2). Default setting is Auto. Isothermal alarm After setting the isothermal temp and the isothermal width, when the isothermal alarm is on, the temp will generate an alarm when temp exceeds the current set range;...
  • Page 30: Analysis Setup

    Analysis Setup Analysis Setup Sub-menu Temp Range The temperature measurement interval is selected by the user according to specific conditions. For a thermal imaging camera with a wide temperature measurement range, the range is 30°C to 45°C (86℉ to 113℉). to select Temperature Unit from ℃, ℉, and K.
  • Page 31: Image Reverse

    Image Reverse Press Enter button to reverse palette for thermal image display. Press Enter again to switch back. Clear Screen Press Enter button to clear all items at thermal image area. Image Auto/Manual Mode Click to switch manually or automatically; in the manual state, manually adjust the upper and lower limits of temperature measurement.
  • Page 32 System Setup Sub-menu Languages There are 10 different language options: Simplified Chinese, Traditional Chinese, English, Korean, Japanese, German, French, Russian, Italian, Portuguese and Spanish. Auto Rectify Set the number of seconds to perform next auto-rectify. Set value between 1 and 3000 seconds. Value 0 means disabling auto-rectify feature. Auto Save Set the number of seconds to perform next auto-save.
  • Page 33: Storage Medium

    : If accidentally selected external monitor device and LCD display is disabled, power off and power on device to get LCD display back. Screen Save Set the number of minutes without operation to trigger disabling LCD display to save power. Select between 5min, 10min, 30min, and None. Power Save Set the number of minutes without operation to trigger power off completely.
  • Page 34: Time & Date

    Time & Date Set system date and time. Press button to select an item, button to change its value and press Enter button to press confirm. If Li-Ion battery is removed for a long time, it is necessary to reset system time and date.
  • Page 35 List of Default Settings Items Parameters Value/function Spot 1, 2, 3, 4 Spot 1 Area 1, 2, 3, 4, 5 Area 3 Measured Target Area 3 Enabled Measuring line None Emissivity 0.98 Distance Measurement Humidity Parameters Correction 0.0℃ (32.0℉) temperature Alarm capture Disenabled Alarm...
  • Page 36: System Information

    System Information Select to display system information, such as: serial number, software version, and production date etc. Disc Information Select to display Disc Information as follows: the dialog box can indicate the FLASH’s used disc space and free space, as well as used space, free space of SD card.
  • Page 37: Human Body Temperature Measurement Cases

    6. Human body temperature measurement cases The following pictures show several cases of human body temperature measurement. Case 1 Case 2...
  • Page 38 Case 3...
  • Page 39: Technical Specifications

    7. Technical Specifications UFPA micro-bolometer Detector Field angle / minimum focal 384x288 24°×18°/0.5m length IFOV 384x288 1.2mrad NETD/Sensitivity ≤60mK Frame 50/60Hz Image Quality Pixel pitch 17μm Focus Auto/Motor Spectral range 7.5~14μm 3 million pixel CMOS module, Built in visible light auto focus, 1 LED fill light Fill-in light 10cd/m²...
  • Page 40 Real-time 4 movable points, 5 movable areas (rectangular and circular maximum temperature, minimum temperature capture, Temperature average temperature measurement mode measurement), movable line temperature measurement, isothermal analysis, temperature difference measurement, Date / time, temperature unit ℃ / temperature alarm (sound, color) ℉...
  • Page 41 Supply Battery operating 3 hours of continuous work time (normal temperature) Charging system Smart charger or local charging ℉~89.6℉ External power DC 5V,±5% Operation Temp +16℃~+32℃ (60.8 ℉~158℉ Storage temperature -40℃~+70℃ (-40 range Operating Humidity ≤95%(Non-condensing) Condition Encapsulation IP54 Shock 25G, IEC60068-2-29 Vibration 2G, IEC60068-2-6...
  • Page 42: Technical Support

    8. Technical Support For common mistakes and issues during operation, please refer to the following table. If you cannot resolve the issues, please power off the device and contact our technical department. Failures Possible Causes Solutions The infrared • The battery is uninstalled •...
  • Page 43: Appendix: Emissivity Of Raw Materials

    Appendix: Emissivity of Raw Materials (For reference purpose only) Material Surface Temp (℃/℉) Emissivity (ε) inoxidized 100/212 0.20 Aluminum Oxidized 100/212 0.55 Brown polished 20/68 0.40 Brass Unpolished 38/100.4 0.22 Oxidized 100/212 0.61 Copper Oxidized badly 20/68 0.78 Oxidized 100/212 0.74 Iron Rusted...
