- Page 2 SAFETY INFORMATION The Drum Filter C-30 PRO manual is also available online. To download or view it, go to https://aqua-exclusive.com/manuals/. For detailed information about your C-30 PRO, go to www.aqua-exclusive.com, and log on to your account, or sign up to get an account.
-
Page 3: Table Of Contents
Contents Aqua Exclusive Safety & Requirements....................2 Overview...........................3 Filter Overview............................3 UV-System Overview..........................4 Setup..........................6 Gravity..............................7 Pump Fed..............................7 Installation........................8 Water Level Sensor..........................8 UV-C System............................9 Rinse Pump............................10 Flexible Coupling..........................11 Controlbox............................11 Filter..............................12 Water Level............................13 Maintenance........................14 Disassembly............................14 Bypass..............................14 Slip Clutch.............................14 Setting Torque............................14 Replacing Filter Panel...........................15... - Page 4 Aqua Exclusive Safety & Requirements FUNCTION with high quality materials! from the system. The water with dirt is removed through the drain gutter into the sewer. This cycle is repeated as often as necessary and fully automatic! for ponds up to 8.000 Gallons (30.000 liters). You can also easily place two next to each other for larger ponds.
-
Page 5: Overview
Filter Overview Aqua Exclusive Figure 1: Drum Filter C-30 PRO overview 1. Spray bar connector 6. Filter inlets 2x (4”/110mm) 2. Drum motor 7. Drum frame 3. Build-In UV-C system 4. Water level sensor DMX cable 9. Spray bar 5. Drain gutter 10. -
Page 6: Filter Overview
Aqua Exclusive Filter Overview Figure 2: UV-C System overview Power Plug USA Rubber O-Ring B Ballast 40W High Output Bulb Tank transit connector Bulb Connector Rubber O-Ring A Threaded Connector Ring Quarts sleeve C-25 EVO OWNER’S MANUAL... - Page 7 UV-C SYSTEM The C-30 Pro is equipped with our newest UV-C technology. A 40watt UV-C system with high high quality materials produce a high UV-C radiation. The wavelength of the UV-C system is exactly 253.7nm, the high level of radiation kills almost all bacteria, viruses and even fungi!
- Page 8 Setup The C-30 PRO can be used for both a gravity and pump fed set up. You might have to reposi- the water level sensor next to the drum, which is ideal for the gravity setup. If you want to use We will explain the two main methods that are applied to garden ponds below.
-
Page 9: Setup
Setup Aqua Exclusive Figure 3: Gravity setup overview Figure 4: Pump fed setup overview Setup... - Page 10 Aqua Exclusive Water Level Sensor the water level sensor should be placed in the chamber of the drum. Figure 5: Water level sensor C-25 EVO OWNER’S MANUAL...
-
Page 11: Uv-C System
UV-C System Aqua Exclusive Connecting the UV-System Step 1: Insert the rubber O-Ring A into the transit connector. Step 2: Step 3: Insert the rubber O-Ring B into the quarts sleeve. Step 4: Gently slide the UV Bulb into the quarts sleeve. -
Page 12: Rinse Pump
Aqua Exclusive Rinse Pump Figure 7: C-30 PRO with rinse pump 1. Rinse Pump Filter outlet 4” (110mm) 2. Hose/PVC pipe to Rinse Pump Inlet 3. PVC Reducer ring 4. Spray Bar 5. Hose/PVC pipe from Rinse Pump Outlet to Spray Bar 6. -
Page 13: Flexible Coupling
Flexible Coupling Aqua Exclusive Figure 8: Flexible coupling Filter outlet 4” (110mm) Flexible Rubber Tee Coupling 4” (110mm) PVC Pipe Figure 9: Controlbox overview Manually Rinsing Button Water Pump Power Socket UV-C Power Socket Drum Motor Power Socket Rinse Pump Power Socket... - Page 14 Aqua Exclusive Filter installation • • With a pump-fed system it is advisable to create a staggered upward arrangement a the with water. 4. Check the water level in the housing. 5. Check all pipes, hoses and connections for leaks.
-
Page 15: Water Level
Water Level Aqua Exclusive WATER LEVEL A lower water level is not a problem, but higher water levels can cause leaks. Figure 10: C-30 PRO water height Installation... -
Page 16: Maintenance
Aqua Exclusive Maintenance Maintenance & Disassembly The device requires maintenance at least once a month. During maintenance the power sup- ply must be disconnected. The screen panel should be checked for wear and tear. 1. Disconnect the power supply and close the piping. - Page 17 Replacing Filter Panel Aqua Exclusive Once you have established that the screen panel is showing wear, it is important that you replace it with a new screen panel as soon as possible. This will ensure the continued optimal 1. Disconnect the power supply.
- Page 18 Aqua Exclusive Publication date: August 12, 2020...
