- Page 1 NL TRAILER Trailer Operating Manual Hilomast LLC 402 Chairman Court Debary FL 32713 Tel: +1 (386) 221-5006 Email: sales@hilomast.com Website: www.hilomast.com...
-
Page 2: Table Of Contents
NL Trailer Operating Manual Issue 1 Contents Safety Information..........................2 Product Information..........................4 Trailer Specification........................4 Trailer Features............................. 5 Mast Installation……………………………………………………………………………………………………….…………………...10 Maintenance............................11 Trailer............................11 Mast............................11 Notes..............................12 Figures Fig.1 Trailer Features........................... 5 Fig.2 Trailer Operation. Stages 1-3...................... 6 Fig.3 Trailer Operation. Stages 4.a - 4.b ....................6 Fig.4 Trailer Operation. -
Page 3: Safety Information
NL Trailer Operating Manual Issue 1 Safety Information Always follow the Operating Instructions ALWAYS wear protective shoes, safety helmets and protective gloves when in the area of the trailer or when operating the trailer. ALWAYS check with the local and state authority of the Country where the trailer is to be used for specific trailer regulations. - Page 4 NL Trailer Operating Manual Issue 1 Before towing the trailer, check that the wheel nuts are tight. Check the wheel nuts for the first 10, 25 and 50 miles of driving on newly mounted wheels. Before towing the trailer, check the tire pressure and tread condition of each trailer tire.
- Page 5 NL Trailer Operating Manual Issue 1 Manual NL/Trailer...
-
Page 6: Product Information
NL Trailer Operating Manual Issue 1 Product Information The NXLONG/HD is designed to carry the HD9 Pneumatic Telescopic Hilomast. The trailer is designed and constructed for road use, with Radial style wheels. Trailer Specification Trailer Category Length Dimensions Width (*Mast in the Stored Position) -
Page 7: Fig.1 Trailer Features
NL Trailer Operating Manual Issue 1 Features Trailer Mast Mounting Bracket Mast Spare Wheel Lighting Board Storage Box Jockey Wheel Extension Arm Extension Arm Fig. 1 Trailer Features Trailer and Mast shown in the stored position Manual NL/Trailer... -
Page 8: Fig. 3 Trailer Operation. Stages 4.A-4.B
NL Trailer Operating Manual Issue 1 Trailer Operation 1. Park the trailer on level ground in accordance with the local and state authority regulations. Wear all required safety equipment and clothing. 2. Disconnect the trailer lighting plug from the towing vehicle. - Page 9 NL Trailer Operating Manual Issue 1 5. Set-up an operational zone around the trailer 6. Move the towing vehicle outside of the trailer’s operational zone 7. Remove the through pins holding the extension arms and extend them to fully extended position, then engage the through pin to secure the extension arms in place.
- Page 10 NL Trailer Operating Manual Issue 1 8. Release the locking pins and swing the stabilizing jacks down into position. Stabilizing Jack Jack Locking Fig. 5 Trailer Operation. Stage 8 Ensure the Locking Pins fully engage into the Stabilizing Jacks and The Pin Retainers are installed 9.
-
Page 11: Mast Installation
NL Trailer Operating Manual Issue 1 Mast Installation 1. Remove the bolts holding the top bracket together 2. Loosen the T-handle, bolt, and screws on the cup bracket 3. Place mast into the cup bracket securely and repeat steps 1 and 2 in reverse order. -
Page 12: Maintenance
NL Trailer Operating Manual Issue 1 Maintenance Trailer Inspect the trailer before every use. Check all electrical connections to ensure that they are in good working order and replace where necessary. Check the trailer lighting board for correct operation. The trailer must not be used until the lighting board is functioning correctly. -
Page 13: Notes
NL Trailer Operating Manual Issue 1 Notes __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ Manual NL/Trailer... - Page 14 NL Trailer Operating Manual Issue 1 Hilomast LLC 402 Chairman Court Debary FL32713 Tel: +1 (386) 668-6784 Email: sales@hilomast.com Website: www.hilomast.com Manual NL/Trailer...
