- Page 1 NXLONG/HD TRAILER NX Trailer Operating Manual Hilomast LLC 402 Chairman Court Debary FL32713 Tel: +1 (386) 221-5006 Email: sales@hilomast.com Website: www.hilomast.com...
-
Page 2: Table Of Contents
NX Trailer Operating Manual Issue 1 Contents Safety Information..........................2 Product Information..........................4 Trailer Specification........................4 Mast Specification........................5 Compressor Specification......................5 Trailer Features............................. 5 Trailer Operation ..........................6 Mast Operation..........................12 Maintenance............................14 Trailer............................. 15 Mast............................15 Notes ..............................16 Figures Fig. -
Page 3: Safety Information
NX Trailer Operating Manual Issue 1 Safety Information Always follow the Operating Instructions ALWAYS wear protective shoes, safety helmets and protective gloves when in the area of the trailer or when operating the trailer. ALWAYS check with the local and state authority of the Country where the trailer is to be used in for specific trailer regulations. - Page 4 NX Trailer Operating Manual Issue 1 Before towing the trailer, check that the wheel nuts are tight. Check the wheel nuts for the first 10, 25 and 50 miles of driving on newly mounted wheels. Before towing the trailer, check the tire pressure and tread condition of each trailer tire.
-
Page 5: Product Information
NX Trailer Operating Manual Issue 1 Product Information The NXLONG/HD is designed to carry the HD9 Pneumatic Telescopic Hilomast. The trailer is designed and constructed for road use, with Radial style wheels. Trailer Specification Trailer Category Length 16ft Dimensions Width... -
Page 6: Mast Specification
NX Trailer Operating Manual Issue 1 Features Trailer Ladder Mast Mast Safety Strop Tread Plate Lighting Board Spare Wheel Jockey Wheel Storage Box Winch Extension Arm Fig. 1 Trailer Features Trailer and Mast shown in the stored position Manual NX... -
Page 7: Trailer Operation
NX Trailer Operating Manual Issue 1 Trailer Operation 1. Park the trailer on level ground in accordance with the local and state authority regulations. Wear all required safety equipment and clothing. 2. Disconnect the trailer lighting plug from the towing vehicle. -
Page 8: Fig. 4 Trailer Operation Stage 7
NX Trailer Operating Manual Issue 1 5. Set-up an operational zone around the trailer 6. Move the towing vehicle outside of the trailer’s operational zone 7. Remove the through pins holding the extension arms and extend them to fully extended position, then engage the through pin to secure the extension arms in place. -
Page 9: Fig. 5 Trailer Operation Stage 8
NX Trailer Operating Manual Issue 1 8. Release the locking pins and swing the stabilizing jacks down into position. Stabilizing Jack Jack Locking Fig. 5 Trailer Operation Stage 8 Ensure the Locking Pins fully engage into the Stabilizing Jacks and The Pin Retainers are installed 9. -
Page 10: Fig. 6 Trailer Operation Stage 11 - 12
NX Trailer Operating Manual Issue 1 Locking Collar Handles Mast Safety Strop Fig. 6 Trailer Operation Stages 11-12 Mast Safety Strop Fig. 7 Trailer Operation Stages 11-12 11. Remove the mast safety strop by unclipping the carbine from the Eye-Bolt on the mast Head. -
Page 11: Fig. 8 Trailer Operation Stage 13
NX Trailer Operating Manual Issue 1 13. Activate the Winch Switch and guide the mast into the operational position. Be sure to not over tension the winch line Winch Switch Down Winch Locking Pin Mast Carriage Fig. 8 Trailer Operation Stage 13... -
Page 12: Fig. 9 Trailer Operation Stage 14
NX Trailer Operating Manual Issue 1 14. (1) Activate the winch until the mast is seated firmly in the mast carriage. (2) Lift locking pin from the cradle; (3) line up the holes on mast carriage and the trailer and (4) insert the locking pin. -
Page 13: Mast Operation
NX Trailer Operating Manual Issue 1 Mast Operation Raising the Mast 1. Make sure swing assembly is secured fully prior to use. 2. Climb the mast carriage using the ladder. (*Harness should be worn when climbing the mast.) Ladder *Harness not included Fig. -
Page 14: Fig. 11 Mast Operation Stages 4 - 5
NX Trailer Operating Manual Issue 1 3. Secure all locking collars (with the exception of the top mast section) by turning the thumb screw in a Clockwise direction 4. Engage the compressor 5. Use compressor control to extend the mast... -
Page 15: Fig. 12 Mast Operation Note
NX Trailer Operating Manual Issue 1 *Type21 Valve Fig. 12 Mast Operation *Note *Note: Type 21 Valve may also be used to quickly release air contained in mast or connect black supply hose for drainage purposes. Run hose off of trailer 4. -
Page 16: Maintenance
NX Trailer Operating Manual Issue 1 Maintenance Trailer Inspect the trailer before every use. Check all electrical connections to ensure that they are in good working order and replace where necessary. Check the trailer lighting board for correct operation. The trailer must not be used until the lighting board is functioning correctly. -
Page 17: Notes
NX Trailer Operating Manual Issue 1 Notes __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ Manual NX... - Page 18 NX Trailer Operating Manual Issue 1 Hilomast LLC 402 Chairman Court Debary FL32713 Tel: +1 (386) 221-5006 Email: sales@hilomast.com Website: www.hilomast.com Manual NX...
