- Page 1 User Manual SOUNDBAR 2.0 VXA-220 Please read this manual carefully for proper usage before lnstallatlon and use. It is recommended to keep this manual for future check. The pictures in this manual are only for reference.
-
Page 2: Table Of Contents
Contents 1. Important Safety Instructions ................4 1.1 Safety ................................4 1.2 Caution ..............................5 1.3 Warning ..............................5 2. What’s in the Box ....................6 3. Identifying the parts ....................7 3.1 Main Unit ..............................7 3.2 Wireless Subwoofer........................... 8 4. - Page 3 10. Troubleshooting ....................15 11. Technical specifications ..................16 11.1 Soundbar ..............................16 11.2 Bluetooth ............................... 16 11.3 Remote Control ........................... 17 12. Marking ........................17...
-
Page 4: Important Safety Instructions
1. Important Safety Instructions The lightning flash with 8. Do not install near any heat sources arrowhead symbol, within an such as radiators, heaters, stoves, or equilateral triangle, is intended other apparatus (including amplifiers) to alert the user to the presence of that produce heat. -
Page 5: Caution
15. This equipment is a Class II or double • Danger of explosion if battery is insulated electrical appliance. It has incorrectly replaced. been designed in such a way that it • Replace only with the same or does not require a safety connection equivalent type. -
Page 6: What's In The Box
DO NOT INGEST BATTERY, CHEMICAL RISK OF ELECTRIC SHOCK BURN HAZARD DO NOT OPEN If you think batteries might have been To reduce te risk of electric shock, do swallowed or placed inside any part not remove cover or back. No user- of the body, seek immediate medical serviceable parts inside. -
Page 7: Identifying The Parts
3. Identifying the parts 3.1 Main Unit 1. Remote Control Sensor 2. LED Indicators. Red indicator: In standby mode Green indicator: In AUX mode Blue indicator: In Bluetooth mode White indicator: In optical mode 3. Wall hanging slots/Rubber location, use these to hang the sound bar on a wall 4. -
Page 8: Wireless Subwoofer
3.2 Wireless Subwoofer 1. Power button, turn On/Off the unit 2. Mute or resume the sound 3. Increase/decrease the volume level 4. Function buttons, select the play function 5. Previous/Next (track) in Buetooth mode 6. Play/pause in Bluetooth mode/Pair. Press and hold to activate the pairing function in Bluetooth mode or disconnect the existing paired Bluetooth device. -
Page 9: Replace The Remote Control Battery
5. Placement and Mounting 4.2 Replace the remote control battery The remote control requires a CR2025, 3V 5.1 Placement Lithium battery. If your TV is placed on a table, you can 1. Push the tab on the side of the place the unit on the table directly in battery tray towards the tray front of the TV stand, centered with the... -
Page 10: Wall Mounting
5.2 Wall Mounting • Installation must be carried out by • Additional tools (not included) are qualified personnel only. Incorrect required for the installation assembly can result in severe personal • Do not overtighten screws injury and property damage (if you •... -
Page 11: Connections
6. Connections 6.1 Use the optical socket Remove the protective cap of the optical socket, then connect an optical cable (not included) to the TV’s “optical out” socket and the optical socket on the unit. The digital optical connector might be labeled SPDIF or SPDIF OUT. -
Page 12: Connect Power
6.3 Connect Power • Risk of product damage! Ensure that the power supply voltage corresponds to the voltage printed on the back or the underside of the unit • Before connecting the AC power cord, ensure you have completed all other connections Picture 6.3 •... -
Page 13: Aux/Optical Operation
1. While in ON mode, press the power button on the soundbar or press the 3. Select “VXA-220” in the pairing list. AUX or Optical button on the remote After the “Paired” voice prompt, the control to select the desired mode system is successfully connected and the Blue indicator will light up solidly. -
Page 14: Disconnect The Bluetooth Function
9.2 Disconnect the Bluetooth function 9.3 Listen to Music from Bluetooth Device • Switch to another function on the If the connected Bluetooth device unit. supports Advanced Audio Distribution Profile (A2DP), you can listen to the • Disable the Bluetooth function on music stored on the device through the your device. -
Page 15: Troubleshooting
10. Troubleshooting To keep the warranty valid, never try to repair the system yourself. If you encounter problems when using this unit, check the following points before requesting service. No power • Ensure that the AC cord of the apparatus is properly connected •... -
Page 16: Technical Specifications
• I can’t find the Bluetooth Ensure the Bluetooth function is activated on your name of this unit on my Bluetooth device Bluetooth device • Re-pair the unit with your Bluetooth device This is a 15 mins power When the unit’s external input signal level is too low, off function, one of the unit will be turned off automatically in 15 minutes. -
Page 17: Remote Control
11.3 Remote Control Distance Angle 30° Battery Type CR2025 12. Marking Declares that the design and We hereby declares that this manufactureing of this product complies product is in compliance with the with the european directives for CE- essential requirements and other relevant marking as stated below: provisions of Directive 2014/53/ EU.
