Section 2
NOTE: An Alarm Event report will be generated immediately after the transition from
a non-alarm to an alarm event. The reverse situation (alarm state to non-alarm
state) does not trigger the event-based Datalogger.
Event-based Datalogger messages conserve memory. However, if you use this feature to moni-
tor a level such as Flow Alarm, set the alarm threshold high enough to avoid repetitive trig-
gering. You must select Site ID (Name) and Time to "time-stamp" the alarm events. Note that
on the Datalogger report, a [-] represents a reserved letter code space (inactive alarm) and a
letter code represents an active alarm.
To select Datalogger Event items:
To access the [Datalogger Events] option list press
pressing
To de-select Datalogger Events:
Move the cursor to the item by pressing
plus sign (+) from the item.
After selecting all desired items press

2.9.5 DISPLAY DATALOGGER

Use this menu cell to enable and format the on-screen datalogger. You can allow the report to
scroll on the screen with or without line wrapping. Selecting line wrap, forces a line feed after
approximately 40 characters. This command is effective only after you select data items and
the Datalogger has accumulated some data.
To enable the on-screen datalogger display:
To access the [Display Datalogger] option list press
Move the cursor to the desired function.
To invoke the function press
To scroll the on-screen datalogger display:
To display one line at a time press
+
Use key to scroll down one screen (10 lines) at a time.
Use key to jump to 15 lines of the last screen.
=
In No-Line Wrap mode:
Use or
to scroll 8 columns to the right or the left. To get out of the display, press
then to select it. Note that a plus sign(+) appears before the item.
ENT
ENT
to scroll one column to the left or right. Use
. Move cursor to desired item by
then . Note that this removes the
CLR
to leave the [Datalogger Events] option list.
2-58
1010PVNFM-3A
