- Page 1 CHARGE BOOSTER BPC 12-12/40 USER MANUAL VERSION 3 07/04/2021 www.leab.eu LEAB Automotive GmbH Thorshammer 6 24866 Busdorf...
-
Page 2: Table Of Contents
LEAB Automotive GmbH Table of Contents 1 About this Manual ........................ 2 General Safety........................Intended Use....................... Foreseeable Misuse....................3 About this Product ....................... 4 Technical Specifications ....................5 Package Contents ......................... 6 Preparation ..........................7 Assembly ..........................8 Installation ..........................10 Connecting an External LED.................. -
Page 3: About This Manual
Skilled workers in the field of automotive electrics . Any modifications to the product or its components are prohibited and do not conform to its intended use. Only use original LEAB or LEAB-approved ac- cessories. Throughout the manual, you will be alerted to warnings and safety notices about potential hazards associated with handling the device. -
Page 4: General Safety
LEAB Automotive GmbH DANGER Danger that will lead to severe injury or death A safety instruction with the signal word Danger indicates a hazard with a high degree of risk which, if not avoided, will result in death or severe injury. Read the safety information carefully and follow the instructions to avoid it. -
Page 5: Intended Use
LEAB Automotive GmbH WARNING Risk of fire from overheated battery Flammable gases can escape if the battery overheats. 1. Always charge batteries in well-ventilated rooms and away from ignition sources. Notice Device defects from incorrect installation Incorrect installation can result in device defects. -
Page 6: About This Product
LEAB Automotive GmbH 3 About this Product Fig. 1: BPC charge booster LEAB Automotive GmbH Thorshammer 6 24866 Busdorf... -
Page 7: Technical Specifications
LEAB Automotive GmbH 1 DC output (Out) 2 DC input (In) 3 LED Status 4 LED Failure 5 LED Com 6 Program button 7 Port for D+ signal 8 Port for ground (GND) 9 Port for external LED 10 Port for CAN communication 4 Technical Specifications Part no. -
Page 8: Package Contents
LEAB Automotive GmbH Part no. 1041003001 Operating temperature -20 °C … +50 °C International Protection (IP class) IP21 DC connector Bolt, M8 (max. 15 Nm) Operating display Dimensions (L x W x H) 170 mm x 137 mm x 70 mm... -
Page 9: Assembly
LEAB Automotive GmbH ð The device is ready for operation (‘LED Status’ flashes green). 5 Connect the starter battery to the on-board supply system. ð The BPC charge booster is connected to the starter battery. Setting the Output Voltage The BPC charge booster provides 3 different output voltages: –... -
Page 10: Installation
LEAB Automotive GmbH To assemble the device, perform the following steps: ü Assemble the device on a flat and heat conductive surface. 1 Fasten the device with screws to the 4 lateral holes (Ø 4 mm). ð The device is assembled. -
Page 11: Connecting An External Led
LEAB Automotive GmbH 8.1 Connecting an External LED To connect an external LED, perform the following steps: 1 Connect the anode lead of the external LED to the DC input of the device. 2 Connect the cathode lead of the external LED to the of external LED port on the device. -
Page 12: Checking The Set Output Voltage
LEAB Automotive GmbH The BPC charge booster provides 3 different output voltages: – 14.1 V for wet batteries – 14.5 V for gel and AGM batteries – 15 V for lithium batteries To change the output voltage, perform the following steps: ü... -
Page 13: Error Codes And Error Descriptions
LEAB Automotive GmbH LEDs on charge booster Status Meaning LED Status Does not illuminate Device inactive (no input voltage) LED Status Illuminates green Battery is charged LED Status Illuminates red Reduction in charging current, overheating protection (from 70 °C surface temperature) -
Page 14: Maintenance
LEAB Automotive GmbH ð The error codes are displayed. NOTE! The first error code displayed is the most current error code. The device stores up to 5 error codes. Error Description Meaning The temperature is too high. The temperature is too low. -
Page 15: Eu Declaration Of Conformity
LEAB Automotive GmbH 13 EU Declaration of Conformity The BPC 12-12/40 charge booster complies with the re- quirements of the following directives: – 2014/30/EU: EMV – 2011/65/EU: RoHS LEAB Automotive GmbH Thorshammer 6 24866 Busdorf... - Page 16 Tel: +49 (0) 4621 9 78 60-0 Fax: +49 (0) 4621 9 78 60-260 info@leab.eu It is prohibited to copy, duplicate, translate or otherwise pass on the content of this guide to third parties without the express written permission of LEAB.
