- Page 1 Design, Installation, Operation and Maintenance Manual AF-X Fireblocker Nano Series Date: 01-09-2020 Version: User Manual AF-X Fireblocker November 2015 version 1...
- Page 2 Please read this user manual carefully before installing AF-X Fireblocker fire extinguishers of the Nano Series. The AF-X Systems BV general terms and conditions can be retrieved at the Chamber of Commerce, Amsterdam office, reference number 52010430 Copyright ©...
-
Page 3: Table Of Contents
Measures after activation of the extinguishing system ........ 15 Storage and transport ................15 Maintenance of the AF-X Fireblocker ............16 Maintenance task for the user of the AF-X Fireblocker system ...... 16 Residue removal, disassembly, waste and the environment ......17 Introduction ..................17 Residue removal ................... -
Page 4: Signs To Indicate Prohibitions, Mandatory Actions And Cautions Used In This Manual
No switching off No switching on MANDATORY ACTION respiratory Foot protection protection MANDATORY ACTION Attention / Head Hand Unplug / Eye protection important protection protection disconnect CAUTION Fragile Fall danger Hot surface Damage User Manual AF-X Fireblocker Nano Series version 3.5... -
Page 5: Foreword
The AF-X Fireblockers are delivered with the mandatory CE Marking according the Pyrotechnic Directive 2013/29. An AF-X Fireblocker must be installed, inspected and maintained by qualified personnel with a minimum age of 18 years in compliance with local laws and regulations for installation and use of aerosol units and fire extinguishing systems. -
Page 6: Introduction
In case of incorrect use of the information in this manual AF-X Systems BV will not accept any responsibility for any damage caused by the AF-X Fireblocker system. -
Page 7: Design Of The Af-X Fireblocker
All types are equipped with a heat absorbing mechanism (insulation). A tension of 6-36 V (Direct Current) on the AF-X Fireblocker and an electric current of at least 1,0 amperes for 1-2 seconds activates the extinguishing agent and convert it into dispersed nano particles. The aerosol is then cooled by the heat absorbing elements and discharged into the protected area, blocking the fire by stopping the combustion chain reaction. -
Page 8: Design And Installation Of A Standalone System With One Generator
Design and installation of a standalone system with one generator A standalone AF-X Fireblocker generator can be activated by means of a thermal circuit. For this the AF-X Bimetal Switch can be used. A standalone system cannot be larger than the max coverage volume of the generator. -
Page 9: Af-X Mcu (Monitoring & Control Unit)
AF-X Fireblocker Aerosol in the area to be protected. The aerosol formed by the AF-X Fireblocker leaves the generator at some speed. This can be observed as a spreading transparent-white cloud. The temperature of this cloud, consisting of extremely small nanoparticles, is usually somewhat higher than its surroundings. -
Page 10: Calculation Of Quantity And Type
Calculation of quantity and type When you have the protected volume at hand you can use the AF-X Fireblocker Density Calculation Sheet to determine the amount of extinguishant you need and which types of extinguishing generators to choose. This Calculation Sheet is available for trained technicians upon request with AF-X Systems at all times. -
Page 11: Projection Of The Generators Within The Area
Guidelines for the correct positioning and distribution in the area AF-X Fireblocker Generators need to be positioned in such a way that the discharged aerosol will be dispersed in the enclosures protected volume as quickly and homogenously as possible. - Page 12 This includes openings that are usually closed or pushed closed with door- closers or automatically by the FECP before extinguishing starts. Away from doors: Away from windows or other potential openings: User Manual AF-X Fireblocker Nano Series version 3.5...
- Page 13 In areas up to a hight of 8 m, generators should be placed in the meter of space directly below the ceiling. For areas higher than 8 m, consult the AF-X Systems experts how to approach a design for a system for enclosures of such height.
-
Page 14: Mounting Guidelines Af-X Fireblocker Extinguishing Generators
AF-X Systems supplies. The AF-X Fireblocker is delivered with a short circuit safety between the poles 1 and 2 of the female inlay in the connector. This prevents unwanted currents in the activation unit. To assure a secure and safe installation of the generator, please keep the short circuit safety as long as possible in its safeguarding position. -
Page 15: Measures After Activation Of The Extinguishing System
This dust is not harmful for man and/or environment. The AF-X Fireblocker needs to be stored in its original packaging in racks in warehouses (either heated or unheated, clean and well ventilated). Keep the AF-X Fireblocker away from heat sources such as radiators, stoves, electric heaters and other heating appliances. -
Page 16: Maintenance Of The Af-X Fireblocker
Fireblocker is not exposed to temperatures that are outside the normal operating temperature range of -10 and + 50 degrees Celsius, as stipulated in this manual. The service life of the AF-X Fireblocker is monitored by the producer by testing product batches on a regular basis. -
Page 17: Residue Removal, Disassembly, Waste And The Environment
Unscrew the bolts and nuts holding the AF-X Fireblocker in the mounting bracket; Gently take the AF-X Fireblocker out of its mounting bracket and place it on a stable base; Upon the AF-X Fireblocker(s)’ disassembly, consult with the manager about reactivating the fire detection and alarm system;... -
Page 18: Replacement Of An Af-X Fireblocker Unit
Replacement of an AF-X Fireblocker unit. Please take the following steps when replacing a AF-X Fireblocker unit when it has to be repositioned or removed in a new configuration design, or when it has surpassed its operational service life span. -
Page 19: Annex 1 General Technical Data
NB: The system design and applicability per m3 of the AF-X Fireblocker extinguishers are prescribed by the manufacturer, recorded in the systems log and cannot be changed by third parties without loss of warranty. User Manual AF-X Fireblocker Nano Series version 3.5... -
Page 20: Annex 2 Af-X Fireblocker Production Label
Annex 2 AF-X Fireblocker Production Label All AF-X Fireblocker generators hold a production sticker like the one in this annex. When making reference to a specific generator, please use the Serial number together with the Production code as referred to in the lower left corner of the label. -
Page 21: Safety Data Sheet
As experience has learned that in the supply-chain (transportation and storage), entities involved frequently show the need to have more detailed technical information, AF-X provides the following user Safety Data Sheet information in the same sequence as required in accordance with Commission Regulation (EU) 2015/830. - Page 22 You can check with your distributor, dealer, AF-X Systems BV or on the website: www.af-x.com User Safety Data Sheet for an AF-X Fireblocker Generator of the Nano Series SECTION 1: IDENTIFICATION OF THE SUBSTANCE/MIXTURE AND THE COMPANY/ UNDERTAKING 1.1.
- Page 23 Present > 60 Oxidant Ox. Sol. 3 – H272 13XX-XX-X < 10 Metal hydroxide 4XX-XX-X Present 5 - 25 Secondary fuel Phenol- H315, H317, H319, H335, 2XXXX-XX-X < 25 formaldehyde H411, resin User Manual AF-X Fireblocker Nano Series version 3.5...
- Page 24 AEROSOL CLOUD WILL ITSELF BE AN EXTINGUISHING MEDIA FOR SURROUNDING FIRES. 5.1. Extinguishing media Suitable extinguishing media: Use water spray, alcohol-resistant foam, dry chemical or carbon dioxide. Dry powder and dry sand are also suitable. User Manual AF-X Fireblocker Nano Series version 3.5...
- Page 25 Ensure a low relative humidity in the room. As the extinguishing particles are microscopically small, they might attract moist. Create a corrosion stop to protect sensitive electronical equipment if present. Also see ‘Methods for cleaning up’ under 6.3. User Manual AF-X Fireblocker Nano Series version 3.5...
- Page 26 8. Protect from moisture. Keep away from sources of ignition. Always wash hands after handling the product. Do not eat, drink or smoke when using this product. Wash contaminated clothing before reuse. User Manual AF-X Fireblocker Nano Series version 3.5...
- Page 27 Good resistance gives: rubber, butyl rubber, natural rubber, neoprene. Nitrile rubber (NBR). Permeation time: minimum >480min long term exposure; material / thickness [mm]: Nitrile rubber (NBR) / 0,11 mm. Take advice to gloves' supplier. User Manual AF-X Fireblocker Nano Series version 3.5...
- Page 28 Training staff on good practice. Regular cleaning of equipment. Minimization of manual phases. SECTION 9: PHYSICAL AND CHEMICAL PROPERTIES 9.1. Device Appearance Form Metal casing containing solid blocks Colour Metal User Manual AF-X Fireblocker Nano Series version 3.5...
- Page 29 LD50 Oral – Rat – 3.750 mg/kg (potassium nitrate) LD50 Oral – Rat – >10000 mg/kg (cyanoguanidine) Skin corrosion / irritation Not data available Serious eye damage / eye irritation Not data available User Manual AF-X Fireblocker Nano Series version 3.5...
- Page 30 Sewage disposal-relevant information : Waste should not be disposed of by release to sewers. Other disposal recommendations Contaminated packaging should be treated and disposed of as an unused product. User Manual AF-X Fireblocker Nano Series version 3.5...
- Page 31 SECTION 15: REGULATORY INFORMATION In case of escape/free Extinguishing Agent 15.1. Safety, health and environmental regulations/legislation specific for the substance or mixture No data available 15.2 Chemical safety assessment No data available User Manual AF-X Fireblocker Nano Series version 3.5...
- Page 32 Adaptations This safety data sheet is a general SDS and replaces all the individual SDSs of the products mentioned in SECTION 1. Additional NFPA identification (US Federal Regulations): User Manual AF-X Fireblocker Nano Series version 3.5...
- Page 33 The AF-X Fireblocker of the Nano Series is a product of AF-X Systems BV, Amsterdam, The Netherlands. This Safety Data Sheet is prepared by AF-X Systems BV in close cooperation and based on the data as supplied by Aerospace Propulsion Products BV (part of Ariane Group).
