- Page 1 Installation and User Manual AF-X Fireblocker Carbon Series Original issue date: July 2018 Revision date: 07-12-2019 Version: User Manual AF-X Firestopper November 2015 version 1...
- Page 2 Please read this user manual carefully before installing AF-X Fireblocker Carbon Based Fire Extinguishers. AF-X Systems BV general terms and conditions can be retrieved at the Chamber of Commerce, Amsterdam office. Copyright © All rights reserved. Nothing in this publication may be reproduced and/or made public by means of printing, photocopying, microfilm or any other method without prior written consent from AF-X Systems BV.
-
Page 3: Table Of Contents
Residue removal, disassembly, waste and the environment Introduction ...................... 17 Residue removal ............................17 Disassembly after the AF-X Fireblocker has been activated ............18 Disassembly of an AF-X Fireblocker unit..................... 18 Waste and the environment ........................18 ............................18 10.0 CE-Marking... - Page 4 Foot Beware No switching off No switching on protection MANDATORY ACTION Attention / Head Hand Unplug / Eye protection important protection protection disconnect CAUTION Fragile Fall danger Hot surface Damage User Manual AF-X Fireblocker Carbon Based Fire Extinguishers version 2.2...
- Page 5 GOST R 51047-97 All tests performed on the AF-X Fireblocker Carbon Series have been done according to the norms of the EN 15276 and NEN-ISO 15779. This present manual is based on the results that comply with the EN15276, NEN-ISO15779 and UL2775.
-
Page 6: Introduction
The AF-X Fireblocker Carbon Series is designed to extinguish a fire. The authors of this user manual have constructed it in such a way that it covers every important aspect of the AF-X Fireblocker Carbon Series’ functional use. To ensure functional use of the AF-X Fireblocker Carbon Series, all instructions of this manual need to be followed closely. -
Page 7: Design Of The Af-X Fireblocker Carbon Series
All types are equipped with a heat absorbing mechanism (insulation). A tension of 12/24 V (Direct Current) on the AF-X Fireblocker Carbon Series generator and an electric current of at least 0,02 amperes for 1,0 seconds activates the extinguishing agent and convert it into dispersed micro and nano particles. -
Page 8: Precautions And Safety Instructions
Warning: the AF-X Fireblocker Carbon Series may only be installed, maintained or serviced by technically qualified and trained persons and in accordance with the latest applicable local laws, regulations and norms. -
Page 9: Design And Installation Of The Fire Extinguishing System
Design and installation of the fire extinguishing system A standalone AF-X Fireblocker Carbon Series generator can be activated by means of a thermal circuit (e.g. an AF- X bimetal switch that activates at 65 ºC, see annex 2). The self-activation temperature of the compound is 350 ºC. The self-activation time of the electronically controlled activation device is >... -
Page 10: Af-X Mcu (Monitoring & Control Unit)
All these control panels have their own prices and possibilities. If the usage of other brands or types of control panels is considered it is required to contact the technical department of AF-X Systems first for an opinion and approval regarding compatibility. Also, if a certifying authority requires the usage of a specific panel. -
Page 11: Detection Systems And Peripheral Equipment
When you have the available net volume of the to be protected space at hand you can use the “AF-X Fireblocker Density Calculation Sheet” to determine the amount of extinguishant you need, and which types of extinguishing generators will best suit your purpose. -
Page 12: Determination Of The Correct Discharge Direction
There are always several solutions. The challenge is to come up with the optimal mix of choices in type, position and discharge direction and length that makes maximum use of AF-X Fireblocker’s qualities and is in accordance with the Statement of Requirements as well as the local rules and regulations. - Page 13 Horizontal discharge in areas lower than 1m: In an area higher than 1m, generators should preferably discharge downwards at an angle (cf. drawing). Downward discharge in areas higher than 1m: User Manual AF-X Fireblocker Carbon Based Fire Extinguishers version 2.2...
-
Page 14: Mounting Guidelines Af-X Fireblocker Carbon Generators
AF-X Systems supplies. The male insert is properly connected to the (massive core) control cable with a stripping length of 15mm to pole number 1 and pole number 2, using a maximum torque of 0,5 Nm. The AF-X Fireblocker is not earthed. - Page 15 Remove them carefully and completely to assure the free outflow of aerosol during activation. The AF-X Fireblocker is delivered with a short circuit safety between the poles 1 and 2 of the female inlay in the connector. This prevents unwanted currents in the activation unit. To assure a secure and safe installation of the generator, please keep the short circuit safety as long as possible in its safeguarding position.
-
Page 16: 6.0 Product Label
Month & year of production Storage and transport During transport and storage, the AF-X Fireblocker Carbon Series needs to be put up and protected against dirt, moisture and precipitation. The AF-X Fireblocker Carbon Series needs to be stored in its original packaging in racks in warehouses (either heated or unheated, clean and well ventilated). -
Page 17: Maintenance Of The Af-X Fireblocker
NB the entire system, including all parts, must be checked regularly in accordance with the suppliers’ guidelines and/or local laws. The AF-X Fireblocker Carbon series have been designed for a service life of 15 years. Please be aware that the extinguishant contains materials that have a relatively low melting temperature. These materials increase the extinguishant’s efficiency, but it is therefore important to always ensure that the AF-X Fireblocker is not exposed... -
Page 18: Disassembly After The Af-X Fireblocker Has Been Activated
In case the extinguishing units have not been activated and the extinguishing agent is still present in the AF-X Fireblocker, the extinguishing units may be handed in to the AF- X distributor or one of its dealers. -
Page 19: Annex 1 General Technical Data
< 0 cm < 0 cm 400°C NB: The system design and applicability per m3 of the AF-X Fireblocker extinguishers are prescribed by the manufacturer, recorded in the systems log and cannot be changed by third parties without loss of warranty. -
Page 20: Annex 2 General Technical Data Bimetal Switch
Please keep this user manual for future use. It will expire upon publication of a revised issue. The latest version is available with your distributor, dealer or at AF-X Systems BV. Annex 2 General technical data Bimetal Switch User Manual AF-X Fireblocker Carbon Based Fire Extinguishers version 2.2... - Page 21 As experience has learned that in the supply-chain (transportation and storage), entities involved frequently show the need to have more detailed technical information, AF-X provides the following user Safety Data Sheet information in the same sequence as required in accordance with Commission Regulation (EU) 2015/830.
- Page 22 Please keep this user manual for future use. It will expire upon publication of a revised issue. The latest version is available with your distributor, dealer or at AF-X Systems BV. User Safety Data Sheet for AF-X Fireblocker Carbon Generator Extinguisher SECTION 1: IDENTIFICATION OF THE SUBSTANCE/MIXTURE AND THE COMPANY/ UNDERTAKING 1.1.
- Page 23 ECHA in REACH registrations no hazards have been classified on the other ingredients. For the full text of the statements mentioned in this section, see also Section 16 User Manual AF-X Fireblocker Carbon Based Fire Extinguishers version 2.2...
- Page 24 Consult a physician. 4.3. Indication of any immediate medical attention and special treatment needed Treat symptomatically. Follow the recommendations/advice in chapter 4.1. User Manual AF-X Fireblocker Carbon Based Fire Extinguishers version 2.2...
- Page 25 (including helmets, protective boots and gloves) conforming to European standard EN 469 will provide a basic level of protection for chemical incidents. Other information: Avoid mechanical shocks. Avoid high temperatures. Use water spray to cool unopened packages. User Manual AF-X Fireblocker Carbon Based Fire Extinguishers version 2.2...
- Page 26 (transport/Handling). Clean contaminated surfaces with an excess of water. Wash clothing and equipment after handling. Special cleaning advise for the dry or iced cleaning of sensitive electronics can be obtained at the AF-X Systems technical department.
- Page 27 Do not store in unlabeled containers. Packaging material Suitable material: preferably hermetically sealed packages made of materials as polyethylene. 7.3. Specific end use(s) Consult the identified uses in the User Manual of this product. User Manual AF-X Fireblocker Carbon Based Fire Extinguishers version 2.2...
- Page 28 Normal working clothes are suitable. Body Protection: Impervious clothing, the type of protective equipment must be selected according to the concentration and amount of the dangerous substance at the specific workplace. User Manual AF-X Fireblocker Carbon Based Fire Extinguishers version 2.2...
- Page 29 Intended as extinguishing agent Oxidizing properties may intensify fire; oxidizer 9.2. 0ther information Minimum ignition energy Not applicable SADT Not applicable VOC content Not applicable Other Properties Translucent User Manual AF-X Fireblocker Carbon Based Fire Extinguishers version 2.2...
- Page 30 No data available Carcinogenicity IARC: No component of this product present at levels greater than or equal to 0.1% is identified as probable, possible or confirmed human carcinogen by IARC. User Manual AF-X Fireblocker Carbon Based Fire Extinguishers version 2.2...
- Page 31 (Directive 98/83/EC) Not harmful to fishes (LC50(96h) >1000 mg/l). Not harmful to algae (EC50 (72h) >1000 mg/l). Not harmful to aquatic organisms (1700 mg/l 72h EC50 >1000 mg/l). Not harmful to activated sludge. May cause eutrophication User Manual AF-X Fireblocker Carbon Based Fire Extinguishers version 2.2...
- Page 32 Remove waste in accordance with local and/or national regulations. Care should be taken when handling emptied containers that have not been cleaned or rinsed out. Ecology - waste materials Avoid release to the environment. User Manual AF-X Fireblocker Carbon Based Fire Extinguishers version 2.2...
- Page 33 In accordance with the UN recommendations on the transport of dangerous goods Test and criteria and thus ADR / RID / ADNR / IMDG / ICAO / IATA The products and components are tested and documented by AF-X Systems, Aerosol Extinguishing Technologies (Netherlands), Consilab (Germany) and suppliers.
- Page 34 Before using/handling the product one must read carefully the MSDS. Adaptations This safety data sheet is a general SDS and replaces all the individual SDSs of the products mentioned in SECTION 1. Additional NFPA identification (US Federal Regulations): User Manual AF-X Fireblocker Carbon Based Fire Extinguishers version 2.2...
- Page 35 The AF-X Fireblocker of the Carbon Series is a product of AF-X Systems BV, Amsterdam, The Netherlands. This Safety Data Sheet is prepared by AF-X Systems BV in close cooperation and based on the data as supplied by Aerosol Extinguishing Technologies BV, Amsterdam. Aerosol Extinguishing Technologies BV produces this fire extinguishing gas generators exclusively for AF-X Systems BV.
