- Page 1 OPERATOR’S MANUAL Automatic Pretreat Spray Machine www.ecofreen.com...
- Page 2 Use the Mister T2 only for its intended use. Mister-T2 has to be operated with a precoating liquid for fabrics for DTG printer. Cleaning MUST be done with distilled water only! Other liquids alcohol or solvent may damage pumps or other components of the machine.
-
Page 3: Table Of Contents
Table of Contents Congratulations on your purchase of a pretreat Machine! In order to work professionally with the machine and start production, please make sure you read this manual carefully. Reproduction of this manual requires written consent. Errors and amendments of technical details excepted, all rights reserved. We are not liable for any direct or indirect damages caused by the use of this product. -
Page 4: Machine Parts Diagram
Machine Parts Diagram <FRONT> Control Panel Two Nozzles LED Lamp Capping Station Volume Chart Platen (16” x 20”) <BACK> Main Power Switch Ventilation Fan Emergency Button Multi-Inlet Selector Valves Bottle Holder Air Exhaust Vent Drain Connector... -
Page 5: Specifications
Specifications Specifications Dimensions 560mm(W) x 800mm(L) x 590mm(H) Weight 40kgs Platen Size 40cm x 50cm (16" x 20") Number of Spray Nozzle Two Nozzles Maximum Spray Area 40cm x 50cm (16" x 20") Spray Cycle Time 3 sec ~ 9 sec, by 10 to 99 speed Power Supply Free Voltage (100V~240V 50/60hz) Power Consumption... -
Page 6: Installation
Installation Installation Gently open the top of the machine and find the accessory box inside of the machine and please check if all the components are in the box. ② Screws (6ea) ③ 1L Bottles (4ea) ① Bottle Holder ⑤ Extra Filters (4ea) ④... - Page 7 This will collect any excess pretreatment when the machine run. PREPARE A BOTTLE WITH PRETREAT SOLUTION If using ECOFREEN UNIVERSAL concentrate, mix the liquid and purified water as below. Universal Water for DARK and...
- Page 8 Installation Installation (Continued) PUT THE FILTERS INTO THE BOTTLES Please put the filters into the bottles for pretreat liquid or water as below. DISTILLED WATER ONLY ① ② ③ Liquid Liquid Liquid DISTILLED WATER Please turn the valve clockwise to open the preferred valve to spray the liquid or water. This position is ONLY Pretreat Liquid Pretreat Liquid...
-
Page 9: Operating Instructions
Operating Instructions Control Panel ⑫ ⑪ ⑭ ⑮ ⑩ ⑬ ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ Understanding the Control Panel Menu 1) POWER ON/OFF BUTTON 2) ROUND TRIP BUTTON : Spray pretreat liquid with bi-direction when the light above is on. Otherwise, it sprays with uni-direction only. -
Page 10: Operation
Operating Instructions Operation 1) Turn on the POWER SWITCH on the back of the machine. * Ensure the emergency button on the left side of the machine is not locked. If the emergency button is locked unlock by turning the button clockwise. 2) Press the POWER BUTTON on the control panel to start the machine... -
Page 11: Switching The Pretreat Liquid
Operating Instructions Operation (Continued) BOTTLE SELECT Switch the bottles by turning the desired valve in clockwise. * Only ONE valve can be open at a time. CLEANING Closed Open When you change the bottle to another (to different liquid), please press “CLEAN” BUTTON. WARNING IF YOU USE MULTIPLE COATING LIQUIDS, CHEMICAL REACTION MAY OCCUR WHICH CAN BE THE REASON FOR THE NOZZLES TO BE CLOGGED... -
Page 12: Pretreatment Guide
Pretreatment Guide Pretreating a shirt Use the Recommended Spray Volume and Fixation Temperature. 1. Please prepare all equipment to be turned on. Turn on the machine. 2. If pretreatment is already loaded in the tubes, skip steps 2 & 3. Press the clean button to ensure that the pretreatment solution is loaded into tubes. -
Page 13: Dtg Fixation Guide
Dark Cotton Poly Blended (Hoodie) Quantity 10-20g 20-35g Volume Level on Volume Level Volume Level Volume Level Volume Level 10~30 10~20 Mister-T2 Spraying Direction Uni-Direction Bi-Direction Bi-Direction Bi-Direction on Mister-2 Time 35-45 seconds 60-70 seconds 90 seconds 90-120 seconds Temperature 320-338℉... -
Page 14: Volume Chart
* The volume of the pretreat liquid showed on the display is provided for general information purposes only. It does not represent the accurate volume of the liquid. ECOFREEN will have no responsibility for the accuracy of the data and the issue which may arise from using or relying on the information. -
Page 15: Maintenance (Important)
Maintenance Scan the QR CODE for the video ! DAILY MAINTENANCE Press “CLEAN” button to flush with water and clean the nozzle everyday at the end of work. Never leave the filter exposed to air to prevent filter from drying and clogging. Always put the filter into the pretreat or cleaning water container. - Page 16 Maintenance DAILY MAINTENANCE : Cleaning at the End of Work ( Step 1 + Step 2 ) Step 1. Collecting Remaining Pretreat Liquid 1.) Take out the filter from the bottle of pretreat liquid. (Make sure to turn the valve on, otherwise filter will be unable to suck the liquid) Pretreat Liquid...
- Page 17 Maintenance DAILY MAINTENANCE : Cleaning at the End of Work (Continued) 5.) Place the empty bottle underneath the right side of the nozzle. 6.) Press and hold “CLEAN” button for “3 seconds” until you hear a beep. Then, the pretreat liquid will be flushed out of the machine.
- Page 18 Maintenance Cleaning The Nozzle Step 1 : Press POWER ON/OFF BUTTON on the control panel to switch off. Step 2 : Open top lid. Step 3 : Turn the Nozzle Cap Nut to counter-clockwise to loosen and dislocate the nozzle. Step 4 : Clean the Nozzle Tip, Cap Nut and Sol Valve using water and wet paper tower.
- Page 19 Maintenance Cleaning The Nozzle (continued) Step 5 : Assemble the Nozzle Tip and the Nozzle Cap Nut as the picture on the right. CAUTION When assembling Nozzle Tip after disconnecting and cleaning the nozzle, Please make sure the Nozzle Tip’s alignment. Failure to do this will result in the pretreat not being sprayed properly on the shirt.
-
Page 20: Other Settings
Other Settings How to Adjust Angles of Nozzles 1) Open the top lid and check the current angles. The graduations are marked as the picture below. The Left Nozzle The Right Nozzle Center of the gradations Center of the gradations ** Initial setting of the gradations** 2) Adjust the Angles of right and left nozzles. - Page 21 Other Settings How to Adjust Angles of Nozzles (continued) The Left Nozzle The Right Nozzle < Initial setting of the angle (center) of both nozzles > The Left Nozzle The Right Nozzle < After adjusting the angles >...
-
Page 22: Preset
Other Settings How to Create Preset Options SELECT PRESET # Select which preset # you would like to program (1~9) ENTER THE PRESET MODE Press and hold “setting ” button on the control panel for 3 sec. The LED inside of the machine will be turned off and the numbers on the display will be blinking. - Page 23 Other Settings How to Create Preset Options (Continued) ③ Spraying Area Full, Middle, Side Pocket Area Start Start Start Start Full Area Middle Area Right Side Right Pocket Step 1. Select start area and press button to save. Step 2. Select end area and press button to save.
-
Page 24: Cost Of Pretreat Liquid
* The cost of the pretreat liquid showed on the display is provided for general information purposes only. It does not represent the accurate cost of the liquid. ECOFREEN will have no responsibility for the accuracy of the data and the issue which may arise from using or relying on the information. -
Page 25: Setting Mode For Other Setting
Other Settings SETTING MODE ENTER THE SETTING MODE Simultaneously press and hold button in the COST section on the control panel until both the numbers INDEX Setting# on the control panel (red boxes on the right) are blinking. SET the EACH OPTIONS AS DESIRED Refer to the table below and set the each options as desired. -
Page 26: Trouble Shooting
Trouble Shooting Problem Possible Reason Solution - The nozzles are clogged -Streaking on the shirts after - Filters are clogged to maintenance) coating 2. Replace with new nozzle/ -I rregular Spraying Filter The pump generates no pres- - Electronic valve, nozzle or sure or the spray is too weak pollution and clean - The pump is dirty... -
Page 27: Warranty Information
Other liquids alcohol or solvent may damage pumps or other components of the machine. Damages caused by unauthorized liquids are excluded from the wattanty. Mister-T2 comes with 12 months warranty. This warranty includes the whole construction of the machine, mechanical parts, electronis, drawer with rails, casing, pumps, electronic valve and pipes.
