- Page 1 MLD-B02 & MLD-R06 使用说明书 User's Manual...
-
Page 2: Table Of Contents
目录 Contents 产品介绍 Product Introduction 注意事项 Precautions 配件清单 List of Accessories 装车说明 Instruction for Installation 安装步骤 Procedures of Installation 语音播报器说明 Voice Broadcaster Introduction 传感器配对步骤 Matching Procedures for Sensors 语音接收器绑定 Binding of Voice player App更多功能介绍 Introduction for More App Function 规格参数 Specification 常见问题及解决方法... -
Page 3: 产品介绍
与胎温,并可通过App 精确显示数值。若胎温胎压发生异常，App会通过语音及警示图标及时向您发出警报。 Malide BLE Tire Pressure Monitoring System (hereinafter referred to as Malide TPMS) can monitor the pressure and temperature of car’s tire,and the value can be correctly displayed through App.If the abnormalities occurs on the tire’s pressure and temperature,the App will send the alarm to you through the voice and warning icon. -
Page 4: 配件清单
配件清单 List of Accessories 传感器×4 语音播报器×1 ×1 voice Broadcaster×1 Sensor 装车说明 Instruction for Installation on the Car 左后 左前 右后 右前 产品出厂时，已经配置好四个轮胎的传感器及ID码（每套传感器都有独立ID码），只需先将传感器安装至相应的位置轮胎上，即可使用； 若想用手机App查看数据，需先把传感器与手机App配对好（配对方法详看“传感器配对步骤”）。 When the product leaves the factory, the sensors and ID codes of four tires have been configured (each sensor has an independent ID code), just need to install the sensor to the corresponding positions of tires, and use it.You need to match the App with sensors first when you want to watch the datas(See the "... -
Page 5: 安装步骤
安装步骤 Procedures of Installation 螺丝钉 Screw 传感器 Sensor 阀杆、橡胶环 阀芯组件 Valve stem,Rubber ring,Valve core components 螺母 Air nozzle 气嘴盖 cover A、内置传感器外观 B、内置传感器分解图 C、松开轮胎 D、从车轮上拆下轮胎 Outer image of internal Decomposition diagram Loosen the tire Remove the tire from sensor os internal sensor car wheel E、用钳子拆下原轮胎... -
Page 6: 语音播报器说明
语音播报器说明 Voice Broadcaster Introduction 功能说明： Function Discription: USB插头 USB Plug USB Plug USB插头：接到USB插口中，为语音播报器供 5.0V直流电 按键 USB Plug:Plug the USB plug into the USB port and support 5V DV for Button the voice broadcaster 喇叭 按键：与App配对时使用，配对方法详见“传感 Horn 器配对步骤” Button:Used when matching the App,see the“Matching Procedures 指示灯... -
Page 7: 传感器配对步骤
传感器配对步骤 Matching Procedures for Sensors 系统设置 车辆1 1、点击图A主界面右上角设置符号，进行系统设置界面，如图B所示 语音提醒 Click the symbol in the upper right corner of the main interface of Figure A to enter the system setting interface, as shown in Figure B. 语言 简体中文 2、点击“绑定新设备”，进入图C所示界面 Click "Binding new device" to enter the interface shown in Figure C. -
Page 8: 语音接收器绑定
语音播报器绑定 Binding of Voice Broadcaster 系统设置 语音提醒 1、绑定好所有轮胎的ID码后，点击这界面右上角设置符号进入图A界面; After binding the ID codes of all the tires, click the upper right corner of the main interface to set the symbol 语言 简体中文 to enter the interface A. 2、进入图B界面后，点击“配套设备绑定”; 车辆设定 After entering the interface of Figure B, click on “Supporting Device Binding”. -
Page 9: App更多功能介绍
App更多功能介绍 Introduction for more APP functions 1、在系统设置界面中，点击“车辆设定”进入到车辆设定界面，如图A所示，您可以对车辆图片、车辆名称、车辆型号和车牌号码进行设定。 In the setting interface of system, click the vehicle setting to enter the setting interface of vehicle as shown in Figure A, you can set the picture, name and type of vehicle as well as license numbers. 2、在系统设置界面中，点击“系统参数设置”进入到系统设置界面，如图B所示，您可以根据实际情况对前后轮的胎温胎压范围进行定义，... -
Page 10: 规格参数
工作温度 -40℃-85℃ Working Temperature 工作湿度 95%(MAX) Working Humidity 工作频率 2.4Ghz Working Frequency 发射功率 -2.83 dBm（MAX） -17.41dBm（MAX） MLD-B02: MLD-R06: Transmitting Power 胎压监测范围 0-640kpa(0-6.4Bar) Monitoring range of tire pressure 胎温监测范围 -40℃-80℃ Monitoring range of tire temperature 电池容量 525mA(CR 2450) Battery Capacity 电池使用寿命... -
Page 11: 常见问题及解决方法
常见问题及解决方法 Common Problems And Solutions 1、刚配对好传感器或者打开App后，主界面无数据显示。 传感器只有在刚装电池的20分钟内、行车速度超过20码、停车10分钟内、轮胎气压瞬间变化超过30kPa或者轮胎转动超过20秒时， 才会发送数据，其他时间处于睡眠状态，睡眠状态不发送数据，因此接收端也不会接收到数据。 After the sensor is just matched or the App is opened, there is no data display on the main interface. The sensor will only send data in the following situation: ①Within 20 minutes after the battery is installed; ②The driving speed exceeds 20 yards; ③The parking time is within 10 minutes; ④The tire pressure changes instantaneously more than 30 kPa;... - Page 12 FCC Statement -This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
- Page 13 苹果App下载 安卓App下载 IOS App Download Android App Download 制造商：深圳市马力德科技有限公司 Manufacturer：Shenzhen Malide Technology Co. Ltd. 地址：深圳市龙岗区平湖街道鹅公岭社区信鹅工业区26号A栋 Address: Building A, No. 26, Xin'e Industrial Zone, Egongling Community, Pinghu Street, Longgang District, Shenzhen, China 公司网址( )： Company Website http://malide.com.cn/ 邮箱( )： Email Malide@malide-sz.com...
