Key Features
• Safe handling with slip-proof rubberised housing
• Signals if press not completed correctly - Immediately
after the pressing cycle a green lights shows if the
required pressing force was achieved, a red light if not
• Automatic press cycle. Once it starts, it will
automatically complete. (manual override)
• Electronic log book allows for quick and precise
analysis of errors for servicing and repair
• Electronic monitoring of the jaw locking
bolt and visual error indicator (KPL)
• When you reach the maximum number of presses
before a service is required a warning light flashes.
The machine will not close down enabling you to
complete the job in hand.
• Redundant switch-off
Tool Operation
Holding the tool securely, press and hold the start button
for 2 seconds to begin the automatic press cycle (the green
LED will go out). Release the start button and continue to
hold the tool securely. The green LED will light when the
press cycle is complete. To cancel the automatic press cycle
press and hold the release button on the side of the tool
until the tool turns off.
If the red LED lights up, press the start button. If the tool
does not run, contact Kembla Hong Kong for advice. If the
red and green LEDs flash alternately, the tool is ready for
a service, contact Kembla Hong Kong Customer Service
Centre.
The tool will turn off automatically after 30 minutes of no use.
Turn the tool ON by quickly pressing and releasing the start
button and open the jaws around the fitting.
Bluetooth Connectivity & NovoCheck (KPSA2 & KPL3)
New KPSA2 and KPL3 tools are equipped with Bluetooth
technology so you can connect to you press tool straight
from your smart phone or tablet using the intelligent
NovoCheck App. The NovoCheck App allows you to
monitor the performance of your tool and installation
with the following unique features:
• Pre-start tool checks to ensure your tool is ready for work
• Analysis of your tools performance, usage and time until
next service
• Ability to change your tool settings
• Generate installations reports that showing completed
and incomplete press information
• Compare completed press results to the number of presses
required for a section of work to ensure the job has been
completed with all fittings pressed in your installation
To begin monitoring your tool and installation performance,
simply download the NovoCheck App onto your smart phone
or tablet via the Apple App Store or Google Play.
®
Tool Maintenance
Carry out basic inspection of the pressing device and jaws
prior to each use to ensure they are clean and free from
debris and dirt. The pressing jaws should be visually inspected
to ensure there are no cracks. If there are any cracks in the
pressing jaws, do not use them, as there is risk of the jaws
shattering and potential injury from flying fragments. It is
recommended to always wear appropriate eye protection
whenever using the pressing device. When inspecting the
pressing jaws, also ensure that there are no foreign material
deposits and that the contours of the jaw surfaces are in order.
Failure to do this may result in damage to the jaws and/or the
pressing device. Always remove the battery before performing
regular cleaning and maintenance work.
Regular application of light machine oil to the moving parts of
the jaws, adaptor jaws and collars and general application of
anti-corrosive spray is recommended to maintain a serviceable
condition and function.
The pressing device, jaws and batteries must be serviced
at least within 35,000 presses for the KemPress Small Tool
(KPSA2) and every 2 years for the KemPress Large Tool (KPL3)
and Extra Large Tool (KPXL2). It is recommended to have the
press tool, jaws, adaptor jaws and collars inspected by Kembla
Hong Kong at least once per year. Failure to have the required
services carried out may affect the warranty.
Tool Service Program
The Kembla Hong Kong tool service and repair program
is easy, ensures minimal down time and provides known
maximum costs for repairs. The key components of the
program include:
• Replacement tools available while your tool is being
serviced/repaired
• Maximum repair price guarantee: the cost won't exceed
our maximum repair price and if the cost of repair is less,
you only get charged that amount
• No fix, no charge
• Up to 12 months warranty on repairs
• Kembla recommends an annual service of the tools, jaws,
adaptor jaws and collars
Any service or repair of the KemPress
requiring opening the device, or mechanical repairs, shall
only be carried out by Kembla Hong Kong or their authorised
agent. Failure to do so may void the warranty.
pressing tool or jaws,
®
