- Page 1 ® DESIGN & INSTALLATION GUIDE COPPER PRESS-FIT FITTINGS FOR WATER TO EUROPEAN STANDARD EN 1254...
- Page 2 ® INSTALLATION The following is a step by step guide to installing the KemPress System. For projects requiring maintenance and repair, visually ® inspect the copper tube to ensure it is in reasonable condition with no signs of external corrosion. 1.
- Page 3 ® 6. Check the fitting is clean and the O-ring is free from debris 7. Check the fitting outer edge still lines up with the marking. Open the pressing jaw and close it around the fitting so and correctly sitting in place. Push fitting on tube all the the raised bump in the fitting rests inside the groove of the way to the engagement marking.
- Page 4 ® PRESS TOOL Small tool (KPSA) designed for 15, 22, 28, 35mm The KemPress tool is the smartest, lightweight copper ® Large tool (KPL) designed for 15, 22, 28, 35, 42 and 54mm pressing tool on the market and its slim line design makes it easy to handle.
- Page 5 Turn the tool ON by quickly pressing and releasing the start requiring opening the device, or mechanical repairs, shall only button and open the jaws around the fitting. be carried out by MM Kembla or their authorised agent. Failure to do so may void the warranty.
