- Page 1 SR3 INSTALLTION GUIDE & USER’S MANUAL UniKey’s Bluetooth Smart Reader...
-
Page 2: Table Of Contents
Reader Enrollment ......................... 6 SR3 Animations ........................7 SR3 Reset ..........................8 SR3 Factory Reset ........................9 Identifying SR3 Firmware Version ..................10 UniKey Mobile Credentials ....................11 Definitions ............................11 Typical Lifecycle ..........................11 Troubleshooting the SR3 ...................... 17 Certifications ........................ -
Page 3: Sr3 Overview
The reader is both cost-effective and easy to install, without requiring any rewiring or paneling. The SR3 is intended to be used in conjunction with an access controller as part of the access control system to provide secure access to buildings or areas. The reader is installed and communicates an access request to the controller using the standard Weigand protocol. -
Page 4: Sr3 Installation Guide
This section will walk a professional installer through the steps needed to attach a UniKey Smart Reader 3 (or SR3) (SR3-UK-0001) to an access control panel. The SR3 supports 125 KHz prox cards as well as UniKey mobile credentials. Please review the information below to ensure the reader is installed quickly and properly. -
Page 5: Mounting The Reader
Mobile Device and Software The SR3 utilizes BLE version 5.0 or greater. • The UniKey SR3 is it to be used in conjunction with the UniKey Mobile App (Version 1.0 or • higher). In order for the SR3 to function properly, the mobile device’s software must be up to date. -
Page 6: Prox Weigand Format
The recommended ambient temperature conditions for SR3 functionality are between -35 to Commented [LJ2]: “-35” • 66°C The recommended humidity conditions for SR3 functionality is less than or equal to 85%. • AN1031 V1.0 Copyright ©2019 UniKey Technologies. All rights reserved. -
Page 7: Reader Enrollment
Once the SR3 has been properly installed. It must then be enrolled to an organization using a mobile device using UniKey Mobile App and an installer credential to log in. First Select the Organization in the UniKey Mobile App and tap the + button to enroll a reader to •... -
Page 8: Sr3 Animations
& User Manual SR3 Animations Each animation corresponds with a specific response from the SR3 and can be customized individually for the user’s commercial organization. Other animation colors as well as various presentation styles are just some of the alternatives available for the UniKey SR3. -
Page 9: Sr3 Reset
The reader’s enrollment has now been cleared and is ready to be enrolled at a specified organization. Buzzer Reset B utton Cable Figure 1: Reset button is located on the back of the reader between the buzzer and cable. AN1031 V1.0 Copyright ©2019 UniKey Technologies. All rights reserved. UNIKEY PUBLIC. -
Page 10: Sr3 Factory Reset
The reader’s enrollment has now been cleared, along with any firmware updates that have been initiated since manufactured. It is important to be sure the reader is re-connected to power while simultaneously holding the reset button; not before or after. AN1031 V1.0 Copyright ©2019 UniKey Technologies. All rights reserved. UNIKEY PUBLIC. -
Page 11: Identifying Sr3 Firmware Version
SR3 Installation Guide & User Manual Identifying SR3 Firmware Version The firmware versions for the SR3 can be identified once the SR3 is enrolled to an organization. Via the Via the Via the Via the Web Web Portal Portal Portal Portal To identify the firmware version for the SR3 in the UniKey web portal. -
Page 12: Unikey Mobile Credentials
& User Manual UniKey Mobile Credentials This section provides an overview of commercial mobile credentials within the UniKey platform. The various actors in a typical deployment will be defined as well as a review of the typical lifecycle of the mobile credential. - Page 13 SR3 Installation Guide & User Manual When a customer submits a purchase order to UniKey to procure redemption codes, information such as that in the example table below must be included. It is important to note that the number of credentials per code is arbitrary and is defined entirely by the partner.
- Page 14 SR3 Installation Guide & User Manual Step 1: End customer navigates to the View / Add Users page in the portal and clicks “Redeem Credits” AN1031 V1.0 Copyright ©2019 UniKey Technologies. All rights reserved. UNIKEY PUBLIC.
- Page 15 SR3 Installation Guide & User Manual Step 2: End customer enters a valid credential code serial number. AN1031 V1.0 Copyright ©2019 UniKey Technologies. All rights reserved. UNIKEY PUBLIC.
- Page 16 SR3 Installation Guide & User Manual Step 3: End customer enters valid authentication number for the credential code. AN1031 V1.0 Copyright ©2019 UniKey Technologies. All rights reserved. UNIKEY PUBLIC.
- Page 17 If the partner chose to sell redemption codes direct to end customers, the system supports that as well. Additionally, if a partner chooses not to issue credits at all and allow unlimited sending of credentials by end customers, that is also possible. AN1031 V1.0 Copyright ©2019 UniKey Technologies. All rights reserved. UNIKEY PUBLIC.
-
Page 18: Troubleshooting The Sr3
125 KHz cards and fobs, turning off that portion of a reader. portion of the reader so it will only read the Bluetooth-based credentials. Can I turn off that portion of the reader? AN1031 V1.0 Copyright ©2019 UniKey Technologies. All rights reserved. UNIKEY PUBLIC. -
Page 19: Certifications
3. RF Exposure Guidance: In order to comply with FCC RF Exposure requirements, this device must be installed to provide at least 20 cm separation from the human body at all times. AN1031 V1.0 Copyright ©2019 UniKey Technologies. All rights reserved. UNIKEY PUBLIC. -
Page 20: Ised
2. Afin de se conformer aux exigences d'exposition RF FCC / ISED, cet appareil doit être installé pour fournir au moins 20 cm de séparation du corps humain en tout temps. AN1031 V1.0 Copyright ©2019 UniKey Technologies. All rights reserved. UNIKEY PUBLIC.
