- Page 1 Zond-12e 500A Ground Penetrating Radar USER’S MANUAL Riga, 2019 Darzauglu Str. 1-105, Riga LV-1012, Latvia Phone/Fax: (+371)-67141041 E-mail: radsys@radsys.lv Web: www.radsys.lv...
-
Page 2: General Description
The computer performs the following functions: it controls operation modes of the GPR, and receives, stores, processes and displays data. Battery. The Zond-12e 500A GPR utilizes Li-Ion battery 11.1 V 8.7 A*h, which is built into the case under control panel. The status of the battery (voltage and percentage of the charge balance) is displayed on the computer screen in the settings and data receipt menu. - Page 3 Fig.1. Zond-12e 500A Ground Penetrating Radar in shockproof case. Fig.2. View of shock proof case control panel of Zond-12e 500A GPR.
- Page 4 Once the installation is completed, you must perform the actions prescribed by the Manual in paragraphs 5.1 and 5.2 “Configuring the computer to connect with Zond-12e GPR Control Unit” and paragraph 6 “What to Do Immediately After Installation”. Prism2 3) Run program.
- Page 5 Close setup menu. Fig. 5. Setup menu. Important: Zond-12e 500A GPR has built-in deactivating mechanism, i.e. transmitter is switched ON only when operator enters SETUP menu item or START data acquisition. Transmitter switches OFF immediately after operator STOP data acquisition or leaves SETUP menu item.
- Page 6 Fig. 6. Operating configuration of Zond-12e 500A GPR. Just SETUP menu is closed button START is active. Press Enter or Space key. Display shows data as on picture below. To stop data acquisition press Esc key or Enter (Space) when STOP button is active.
- Page 7 3.2. It is allowed operation of the also at lower temperature applying the heat insulating cover for the control unit. 3.3. It is not recommended to switch on the Zond-12e 500A GPR earlier than after an hour after its transfer from environment having negative temperature to a warm premise.
-
Page 8: Ce Declaration Of Conformity
6. CE DECLARATION OF CONFORMITY For the following equipment: Zond-12e 500A GPR consisting of: 1. Control Unit; 2. Antenna 500A; is herewith confirmed to comply with the requirements set out in the Council Directive on the Approximation of the Laws of the Member States relating to Electromagnetic Compatibility and Radio Spectrum Matters (99/5/EC), Short range devices, Ground- and Wall-Probing Radars applications, Low-voltage Directive (73/23/EEC) and the Amendment Directive (93/68/EEC). -
Page 9: Federal Communications Commission (Fcc)
7. FEDERAL COMMUNICATIONS COMMISSION (FCC) FCC ID: 2AUQQ-ZOND12E500A 7.1. Class A Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 10 Fax this form to the FCC at: 202-418-1944 or mail to: Frequency Coordination Branch, OET Federal Communications Commission 445 12th Street, SW Washington, D.C. 20554 ATTN: UWB Coordination or fill this form online: https://www.faa.gov/about/office_org/headquarters_offices/ato/service_units/techops/safety_ops _support/spec_management/library/gprc.cfm Do not send this information to Radar Systems, Inc. or its representatives...
-
Page 11: Industry Canada (Ic)
8. INDUSTRY CANADA (IC) IC ID: 25515-ZOND12E500A 8.1. Industry Canada Regulations – English This device complies with RSS-220 of the Industry Canada Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 12: Our Address
9. OUR ADDRESS Radar Systems Inc., Darzauglu Street 1-105, Riga LV-1012, LATVIA. Phone: (+371) 67141041. E-mail: radsys@radsys.lv...
