Summary of Contents for SOURIAU Esterline UTL Series
- Page 1 UTL Series www.souriau-industrial.com contactindustry@souriau.com Connection Technologies...
- Page 2 UTL Series The reliable connector to power up your device The UTL series is a sealed plastic connector range able to carry up to 1 6A 277V. Key shape coupling with latching Easy mating retention system Designed to be overmolded Secure against unwanted tampering.
- Page 3 UTL Series Technical features Mechanical Electrical Environmental • Durability: 1000 cycles • Working voltage: • Operating temperature: (with stamped & formed contacts & 277VAC per UL 1977 from -40°C to +105°C S18 plating) 277/480VAC per UL 1977 • Flammability rating: UL 94 5VA •...
- Page 4 UTL Series Assembly instruction UTS 0 assembly (mounting suggestion) • Strip wires, crimp contacts • Insert contacts into connector cavities (insert manually or use tool RTM2 5 crimp contacts) • Place receptacle in the panel cut-out • Secure receptacle with screws (not supplied) 3mm max Receptacle fl...
