- Page 1 INSTALLATION AND MAINTENANCE GUIDE INFRARED TAPS Electronic taps – saving water, saving power, promoting hygiene DB100 DB125 DBL200 DB150 DBL225 DB175 DBL250 DBL275 DB200 DB225 Important: DB250 Read carefully DB275 before installing product Revision January 2020...
- Page 2 INDEX Technical Data : battery powered taps Technical Data : transformer powered taps Pack Contents Pre Installation Information 7 - 9 Tap Installation 10-11 Range Adjustment using Dolphin Blue Remote Control – DB51 Adjusting the sensor range with a remote control Battery Replacement DB100, DB150, DB200, DB250, DBL200, DBL250 models Maintenance...
-
Page 3: Technical Data
TECHNICAL DATA Technical details for B AT T E RY powered taps Power Supply 9V (1 x 9v PP3) Security Time 90 seconds. Can be reduced with the remote control Recommended 0.5-8.0 bar (7-116 PSI) Water Pressure With water pressure of more than 8 bars use a pressure reducing valve for reduction Preset sensor range 220mm... - Page 4 TECHNICAL DATA Technical details for T R A N S F O R M E R powered taps Power Supply 9V Transformer Security Time 90 seconds. Can be reduced with the remote control Recommended 0.5-8.0 bar (7-116 PSI) Water Pressure With water pressure of more than 8 bars use a pressure reducing valve for reduction Preset sensor range...
-
Page 5: Pack Contents
PACK CONTENTS Familiarise yourself with the part’s names and confirm that the parts are included. DB100 DB200 DBL200 1 1 x tap and attachment 2 1 x filter 3 1 x battery box DB125 DB225 DBL225 1 1 x tap and attachment 2 1 x filter 3 1 x transformer DB100, DB200 &... -
Page 6: Pre-Installation Information
PRE INSTALLATION INFORMATION Check contents • Separate all parts from the packaging and check each part with the ‘pack contents’ section. • Pay attention to the different model variations. • Make sure all parts are accounted for before discarding any packaging material. •... -
Page 7: Tap Installation
TAP INSTALLATION Familiarise yourself with the part’s names and confirm that the parts are included. DB150 DB250 DBL250 1 1 x tap and attachments 2 2 x filters 3 1 x battery box DB175 DB275 DBL275 1 1 x tap and attachments 2 2 x filters 3 1 x transformer DB100, DB200 &... - Page 8 TAP INSTALLATION Step 1 – Remove all mounting hardware 1 Shut off water supply and remove the hexagonal nut, the disk O ring Gasket Disk Hexagonal nut Step 2 – Installing the tap 1 Place the tap with O-ring into the hole in the basin or O ring basin/sink.
- Page 9 TAP INSTALLATION Step 3 – Connecting the Water Source 1. a. DB100, DB125, DB200, DB225, DBL200, DBL225: connect the flexible pipe to the water supply b. DB150, DB175, DB250, DB275, DBL250, DBL275: connect the red flexible pipe to the hot water supply and the blue flexible pipe to the cold water supply. 2.
-
Page 10: Range Adjustment
RANGE ADJUSTMENT Adjusting the sensor with the remote control This tap was supplied with a Self Adjusting Sensor. The ideal detection range for the specific location will be set automatically. DETECTION RANGE: Only if necessary, use the remote control to adjust the sensor range as follows: Shut off the water supply. Hold the remote control straight in front of the sensor in a distance of about 6 - 8”... - Page 11 RANGE ADJUSTMENT DELAY OUT TIME: This button allows modifying the water flow time after the user removes his hands from the tap. A delay out time close to 0 will save more water. An increased delay out time will make the user experience more comfortable.
-
Page 12: Battery Replacement
BATTERY REPLACEMENT For models DB100, DB150, DB200, DB250, DBL200, DBL250 Battery models only When the battery weakens, the red indicator light will blink at a constant rate. The battery must be replaced within two weeks. To replace the battery Carefully open the battery’s box Remove the old battery Replace the used battery with a new 9V battery (Lithium battery is recommended) -
Page 13: Maintenance
MAINTENANCE Filter Cleaning Instruction This tap is provided with one/two stainless steel filter(s) preventing foreign particles to enter the lines. If the water flow has decreased, this may be because the filter(s) is/are clogged. The filter(s) can be changed as follows: Shut off the water shut-off valve For DB100, DB125, DB200, DB225, DBL200, DBL225 Disconnect the flexible pipe... -
Page 14: Troubleshooting
TROUBLE SHOOTING PROBLEM INDICATOR CAUSE SOLUTION Sensor flashes continuously when user’s hands are Low batteries Replace batteries within the sensor’s range Range is too short Increase the range with remote Range is too long ie tap Decrease the range with remote Red light in the has gone into security mode sensor does not flash... - Page 15 SPARE PARTS LIST DB100 Item Description Part No. – Seals and Screws Kit DB07210007 O-ring O-ring O-ring Gasket Screw Screw – Sensor Kit DB07220183 Infra-Red Sensor O-ring – Filter Adapter Kit DB07212001 Filter Nipple – Cover Kit DB07270004 Cover O-ring –...
- Page 16 SPARE PARTS LIST DB200 Item Description /Part No. – Seals and Screws Kit DB07210007 O-ring O-ring Gasket Screw Screw O-ring – Sensor Kit DB07220009 Infra-Red Sensor O-ring – Filter Adapter Kit DB07212001 Filter Nipple – Cover Kit DB07270003 Cover O-ring –...
-
Page 17: Limited Warranty
This product is covered by a limited warranty for two years from date of purchase. During this period, Dolphin Solutions Ltd undertakes, at its option, to repair or replace any faults caused by defective materials or manufacturer defaults that may arise. - Page 18 18 | Dolphin Blue | DB100, DB200 & DBL200 Ranges Dolphin Blue DB100, DB200 & DBL200 Ranges...
- Page 19 DB100, DB200 & DBL200 Ranges Dolphin Blue...
- Page 20 Dolphin Solutions Ltd Southpoint, Compass Park, Bodiam, Robertsbridge, TN32 5BS Tel: +44 (0)1424 20 22 24 Fax: +44 (0)1424 205 200 info@dolphinsolutions.co.uk www.dolphinsolutions.co.uk...
