GLIDiC Sound Air TW-7000
TM
U se rʼs Guide
E n gl i s h
N o t e s
This "User's Guide" describes LED indications,
methods to reconnect, disconnect, or pair
multiple devices, and common solutions for
troubleshooting. Refer to the "Quick Start
Guide" for detailed device operations and
charging, and the "Safety Instructions and
Warranty" for safety instructions.
●The description on this guide
・The screenshots and steps used in this "User's
Guide" are for general smartphones. See the
instruction manual for your device for specific
instructions.
・The operation depends on your device or OS.
C ompa ti ble De v ic e s
Smartphones, tablets and other devices sup-
porting Bluetooth® with music playing function
or calling function.
Sp e cifica tio ns
Can withstand: 5 to 35 C (41 to 95 F)
●Earbuds
Internal battery: Lithium polymer battery
3.7V 85mAh
Bluetooth® Specification: Version 5.0
Connection range: approx. 10m (32ft.)
(Output: Class 2)*
Supported profile: A2DP, AVRCP, HFP, HSP
Supported codec: SBC, AAC
Supported content protection: SCMS-T
Maximum number of paired devices: 8
External dimensions: approx. 23(W) 19(D)
24(H)mm
*: Depends on the environment.
●Charging case
Internal battery: Lithium polymer battery 3.7V
460mAh
Interface: microUSB (Type-B) port
External dimensions: approx. 80(W) 28(D)
36(H)mm
●Charging cable
Interface: microUSB (Type-B) connector,
USB (Type-A) connector
Cable length: approx. 30cm
B att ery L if e
Music playback/phone call: approx. 9 hours
With charging case
Music playback/phone call: approx. 25 hours
Charging time: approx. 1 hour for earbuds,
approx. 2 hours for case
Note) Depends on the environment.
In s tr u c ti on s
Pa ir i n g M ul ti pl e D ev i ce s
You can pair up to eight devices to the earbuds.
Note) The earbuds have to be connected to a device to
answer phone calls on the earbuds or listen to music.
●Pairing to connect to other devices
① Long press the multifunction button on the
right earbud for more than 5 sec. while the
earbud is on standby or in playback.
Multifunction
button
R
The LED indicator blinks red and white.
The sound indicating the start of pairing
mode is heard from the earbuds.
Note） The device that was connected will be disconnected.
②Go through the pairing procedure on your
mobile device.
You can pair/connect other devices in the same
way as the first device. Follow step ② in "Pairing
to Connect a Device" in the "Quick Start Guide".
③Follow the steps below to switch the connected
device.
③-1. Follow the steps in "Reconnecting/Disconnecting a Device"
in this guide on the device you want to disconnect.
③-2. Follow the steps in "Reconnecting/Disconnecting a
Device" in this guide on the device you want to connect.
Reconnecting/Disconnecting a Device
●Reconnecting a Device
Once a device is paired, it is reconnected
automatically when the right earbud is removed
f r o m t h e c h a r g i n g c a s e . G o t h r o u g h t h e
connecting procedure on your mobile device if
it does not reconnect automatically.
Example: Select Settings then Bluetooth.
Select GLIDiC TW-7000 from the list displayed.
< Settings Bluetooth
Bluetooth
Now discoverable as "XXXX" .
MY DEVICES
GLIDiC TW-7000 Not Connected
●Disconnecting a Device
Go through the disconnecting procedure on
your mobile device.
Example: Select Settings then Bluetooth.
Set Bluetooth to Off.
< Settings Bluetooth
Bluetooth
L E D In d i c at or s
●Right earbud
System status LED indicator
Charging On
Power on White
Blink once slowly
Timeout* White
Blink once slowly
In pairing mode Red White Red White
・ ・ ・ Blinking
Pairing complete White White White
Blink three times
Standby w/o connection White White White White Blinking
・ ・ ・
Standby with connection
White ・ ・ ・ Blink every 5 sec.
White
5 sec. 5 sec.
In a call/playback Blink every 4 sec. slowly
White White ・ ・ ・
4 sec.
Calling in White White White White
・ ・ ・ Blink every 2 sec.
2 sec.
Reset complete
White Red White Red White Red Blink six times
●Left earbud
System status LED indicator
Charging
On
Power on White
Blink once slowly
Timeout*
White Blink once slowly
Standby with connection
White ・ ・ ・ Blink every 5 sec.
White
5 sec. 5 sec.
In a call/playback Blink every 4 sec.
White White ・ ・ ・
4 sec.
Calling in White White White White ・ ・ ・
Blink every 2 sec.
2 sec.
Reset complete Blink six times
White Red White Red White Red
*: The earbuds time out and turn off either three minutes
after entering pairing mode or about three to six minutes
after disconnecting from your mobile device.
●Charging case
The LED indicator(s) of the charging case lights or
blinks either when the case is opened or while
charging, depending on its battery level.
Level LED indicator
Low
One LED indicator lights/blinks
Medium Two LED indicators light/blink
High
Three LED indicators light/blink
T roubl es h oo t i ng
Ca n n ot Pa i r a Devi c e
Check ① to ⑤ below in order.
①Does the LED indicator on the right earbud
blink red and white when pairing?
R
Red White Red White
・ ・ ・
If it does not, try one of the following depending
on the status of the LED indicator.
On/blinking The earbud is not in pairing mode.
white Switch to pairing mode.
→See step ① in "Pairing Multiple
Devices" in this guide.
Note) The earbuds switch to pairing
mode a few seconds after they are
removed from the charging case
for the first time or after reset.
The battery is flat. Charge the
Off
battery.
→See "Charging the Case/Earbuds"
in the "Quick Start Guide".
The earbud exits pairing mode and
Blinking red
turns off after three minutes.
and white
Switch them back to pairing mode.
and then off
→See step ① in "Pairing Multiple
Devices" in this guide.
Note) The earbuds switch to pairing
mode a few seconds after they are
removed from the charging case
for the first time or after reset.
②Is Bluetooth on?
Check that Bluetooth is turned on in the Bluetooth
settings screen on your mobile device.
< Settings Bluetooth
Bluetooth
③Is "GLIDiC TW-7000" displayed?
Check that it is displayed in the Bluetooth
settings screen on your mobile device.
< Settings Bluetooth
Bluetooth
Now discoverable as "XXXX" .
OTHER DEVICES
GLIDiC TW-7000
If it is not displayed, try the following.
・Bring the earbuds closer to your mobile device.
・Operate in an environment where radio
waves from other devices such as a Wi-Fi
device, microwave oven, or other Bluetooth
device are not present.
・Check whether the Bluetooth device can be
discovered/discoverable in the Bluetooth
settings screen on your mobile device.
④Can you select and pair the "GLIDiC TW-7000"?
If it cannot be paired when selected, place
the earbuds in the charging case, turn off
Bluetooth on your mobile device, and redo
the pairing operation.
⑤Does it fail to pair even after trying all of the
above?
Delete all pairing information from the earbuds
and redo the pairing operation.
→See "Deleting Pairing Information (Reset)" in
the "Quick Start Guide".
No S ou n d i s He a rd
● Is it connected?
Check that your mobile device is connected
to "GLIDiC TW-7000" in the Bluetooth settings
screen on your mobile device.
< Settings Bluetooth
Bluetooth
Now discoverable as "XXXX" .
MY DEVICES
GLIDiC TW-7000 Connected
If it is not connected, connect the device.
→See "Reconnecting a Device Manually" in this
guide.
If "GLIDiC TW-7000" is not displayed on the
Bluetooth settings screen, pair the device.
・ Pairing the first device
→ See "Pairing to Connect a Device" in the
"Quick Start Guide".
・ Pairing the second and later devices
→ See "Pairing Multiple Devices" in this
guide.
●Is the volume on your mobile device loud
enough?
Check the volume setting on your mobile
device.
●Does the problem only occur with the left
earbud?
The right earbud is in monaural mode.
To switch to stereo mode, place both earbuds
in the charging case and remove them again.
If no sound is heard even after doing so,
delete pairing information and redo the
pairing operation.
→See "Deleting Pairing Information (Reset)" and
"Pairing to Connect a Device" in the "Quick
Start Guide".
Ea rb uds do No t Ch a rg e
●Is the charging case charged?
If not, charge the charging case.
→See "Charging the Case/Earbuds" in the "Quick
Start Guide".
●Are the earbuds properly placed in the case?
The LED indicator on the earbuds turns red if
they are placed properly. If they are not, place
them again.
