CUES K2 Screen Operations

P/N CK912 - v051020
CUES K2/K3 SCREEN OPERATIONS: HELP MENU
Instructions for using the K2/K3 system are included in the HELP menu, which is accessible by pressing the F1
button at any time. The K2/K3 HELP system includes all of the information in Chapter 2 of the printed user manual.
CUES HELP INDEX
========== CUES HELP INDEX ==========
1. KEYS: ALL SCREENS?
ALL SET UP SCREENS?
RUN-TIME SCREEN1?
RUN-TIME SCREEN2?
RUN_TIME SCREEN3?
FREE-FORMAT SCREEN?
FREE FORMAT RUN-TIME SCREEN?
TEST CONTROLLER HELP SCREEN?
LAMPII HELP SCREEN?
GXP HELP SCREEN?
2. FIELD ENTRY HELP SCREEN?
<ENTER> to all screens
STATUS LINE - displays the action to be
performed in each field.
KEYS FOR ALL SET UP SCREENS
== CUES KEYS FOR ALL SET UP SCREENS =
<ENTER> - SELECT ACTION/HILIGHT NEXT FLD
<UPARROW> --- PREV SELECTION/FIELD
<DOWNARROW> - NEXT SELECTION/FIELD
<LEFTARROW> - MOVE CURSOR LEFT
<RIGHTARROW> MOVE CURSOR RIGHT
<DELETE> ---- DELETE AT CURSOR
<BACKSPACE> - DELETE LEFT OF CURSOR
<CTRL><DELETE> - CLEAR ENTRY
<TAB> ------- HIGHLIGHT NEXT FIELD
<SHIFT><TAB> HIGHLIGHT PREVIOUS FIELD
<SPACEBAR> -- TOGGLE TWO SELECTIONS
<CTL><ALT><INSERT> - RESTORE SCREEN
<INSERT> - TOGGLE OVERWRITE/INSERT
<ESCAPE> previous screen
KEYS FOR RUN-TIME SCREEN2
=== CUES KEYS FOR RUN-TIME SCREEN2 ==
<F1> --- TO/FROM HELP SCREENS
<F2> --- TO/FROM EQUIPMENT CONFIGURATION
<F3> --- TO/FROM FREE-FORMAT SCREEN
<F4> --- TO/FROM FREE-FORMAT W/RUN SCRN
<F5> --- TO/FROM INSPECTION SETUP SCREEN
<F6> --- To/FROM DISPLAY SETUP SCREEN
<F7> --- TO/FROM DIAGNOSTICS MENU SCREEN
<F8> --- TO/FROM REMINDER SETUP SCREEN
<F9> --- TO/FROM COMMENT DEFINITION SCRN
<F10> -- TO CONFIGURE REELS SCREEN
<CTRL><i>- ZERO INCLINATION
<CTRL><p>- ZERO PRESSURE
<CTRL>-<d>/<z>- PRESET/ZERO DISTANCE
<SHIFT><HOME> HOME FIELDS
<SHIFT><INSERT>TOGGLE ALL FIELDS ON/OFF
<ESCAPE> previous menu
CUES 3600 Rio Vista Avenue Orlando, FL 32805
Press F1 at any time to
access the HELP screen.
• p 407.849.0190
KEYS FOR ALL SCREENS
===== CUES KEYS FOR ALL SCREENS =====
<F1> ------------- TO HELP INDEX SCREEN
<CTRL><F2> ------- CLEAR COMMENT FIELDS
<CTRL><F4> ------- CLEAR FREE FORMAT SCN
<CTRL><F5> ------- CLEAR INSP. SETUP SCN
<CTRL><F6> ------- CLEAR ALARM
<CTRL><F7> ------- TOGGLE MUTE/UNMUTE
<CTRL><F10> ------ DEFAULT COMMENT SET
<CTRL><ALT><t> --- DISABLE/ENABLE TITLER
<CTRL><ALT><s> --- DISABLE/ENABLE STATUS
<CTL><ALT><UPARROW> SPEAKER VOLUME UP
<CTL><ALT><DNARROW> SPEAKER VOLUME DOWN
<CTRL><ALT><+>---- LOG SCREEN
<ESCAPE> previous screen
KEYS FOR RUN-TIME SCREEN1
=== CUES KEYS FOR RUN-TIME SCREEN1 ==
<SHIFT><F1> ---- TOGGLE COMMENTS ON/OFF
<SHIFT><F2> ---- TOGGLE OBSERVATN ON/OFF
<SHIFT><F3> ---- TOGGLE INCLINE ON/OFF
<SHIFT><F4> ---- TOGGLE ARROW ON/OFF
<SHIFT><F5> ---- TOGGLE TITLE ON/OFF
<SHIFT><F6> ---- TOGGLE DATE ON/OFF
<SHIFT><F7> ---- TOGGLE TIME ON/OFF
<SHIFT><F8> ---- TOGGLE MANHOLES ON/OFF
<SHIFT><F9> ---- TOGGLE PRESSURE ON/OFF
<SHIFT><F10> --- TOGGLE DISTANCE ON/OFF
<F11> ---------- TOGGLE TRANS SPD ON/OFF
<CTRL><F11> ---- TOGGLE DIRECTION ON/OFF
<CTRL><F12> ---- TOGGLE LENGTH ON/OFF
ARROW-LF/RT ---- MOVE FIELDS/ARROW LF/RT
ARROW-UP/DN ---- MOVE FIELDS/ARROW UP/DN
<ESCAPE> previous menu
KEYS FOR RUN-TIME SCREEN3
=== CUES KEYS FOR RUN-TIME SCREEN3 ==
<CTRL><f> ----- TOGGLE FONT RENDERINGS
There are two ways to input observations
either <ENTER> and
use arrow keys to see stored comment fields,
or input a code
and it will display the comment.
either,<ENTER>will save
the observation. These work for FreeFormat
w/RunTime also.
<ENTER> -------- TO ENTER COMMENTS MODE
ARROW UP/DN - DISP. PREV/NEXT COMMENT
<ENTER> ----- SAVE THIS COMMENT
<A-Z> ---------- INPUT CODE/GET COMMENT
<ENTER> ----- SAVE THIS COMMENT
<ESCAPE> previous menu
• f 407.425.1569 •
After
