RELEASED TO PRODUCTION - DATE: 7/19/2021
Rev
Date
ECN
Description
-
06/07/2021
-
Initial Release
Document
Number:
SF973-INST
Description:
SolidFX Mud Master Kit
Instruction Sheet
L
H
upe
udwig
Signature CHKR: ____________________
Signature ENGR: ___________________
Tony Winiewicz
7/6/21
Signature MFG: ____________________
7/19/21
SF973-INST
1
Advertisement
Related Manuals for CUES Solid FX
Summary of Contents for CUES Solid FX
- Page 1 RELEASED TO PRODUCTION - DATE: 7/19/2021 Date Description 06/07/2021 Initial Release Document Number: SF973-INST Description: SolidFX Mud Master Kit Instruction Sheet udwig Signature CHKR: ____________________ Signature ENGR: ___________________ Tony Winiewicz 7/6/21 Signature MFG: ____________________ 7/19/21 SF973-INST...
- Page 2 NOTES – UNLESS OTHERWISE SPECIFIED 1. Applying blue threadlocker (440061) to all threaded fasteners is recommended. 2. Where brown threadsealant (445091) is specified, Teflon tape (440350) may be used as an alternative. Pressurizing the system and leak checking all hoses, PTC fittings, and NPT fittings is recommended. 3.
- Page 3 • Unplug the electric lift and the transmission. • Unplug all of the lights. • Remove the rear cover and cut the zip tie to remove the TM356 cable. • Reinstall the rear cover and apply dust caps and dummy plugs to the TM356 cable.
- Page 4 • Remove the electric lift from the Mud Master Chassis. • The electric lift will not be needed in this configuration. Retain hardware for future installation. • Install SF750 onto the Mud Master chassis as shown. • Mounting hardware: • 4X – 101022 •...
- Page 5 • The Rear View Camera (SF385) will now be mounted to the Light Array (SF380). Installation of the LiDAR (SF362) will also be covered. • Remove the two screws shown RVC. • Repeat for the 2 screws on the other side. •...
- Page 6 • Remove the 3 screws shown (left) and set aside for reassembly. • Install the LiDAR onto the RVC (right) using the four M3 screws provided with the LiDAR. Hardware: 4X – HW952 • Reinstall the intake/blower portion of the assembly using the three screws that were previously removed (left).
- Page 7 • Note: When installing the LiDAR/RVC assembly, make sure to route the LiDAR cable as seen below. • Reinstall the RVC/blower subassembly to the mounting plate using the 4 screws that were previously removed. • The light array will now be mounted to the top half of the manual lift (SF749).
- Page 8 • Flip over both, the SF380 (with SF385 mounted) and SF749. • Align SF749 as shown. • Note: It may be necessary to loosen the mounting tabs on SF380. • Fix the SF749 to the light array using the four button head screws provided with SF380.
- Page 9 • Assemble the regulator and fittings in the orientation shown below. All fittings should be tightly fastened. Use brown threadsealant (PN 445091) on all mating threads. Brown threadsealant has a 24 hour cure time and should be fully cured before supplying pressure through the fittings. Note: Teflon tape (PN 440350) can be used in place of brown...
- Page 10 • Note orientation of SF791. • Next SF251 will be mounted to SF791. • Mount SF251 to SF791. • Mounting Hardware: • 2X – 101024 • 2X - 101736 SF973-INST...
- Page 11 • Cut an HW4077 hose clamp to appx. 18 in. and grind down sharp corners. Cut appx. 9” of heat shrink (PN 712586) and slide to appx. 1.5” from the screw housing. Heat up the tubing to shrink it in place. •...
- Page 12 • Insert the regulator/tank assembly through the two hose clamps and orient approximately as shown. Tighten down hose clamps to secure the assembly. • NOTE: SF250 should be securing the valve portion of the regulator tank assembly NOT the neck of the pressure tank.
- Page 13 • Remove the stem plugs from 90° Push To Connect (PTC) fittings and retain for future use. These should be installed when the unit isn’t being used. • Insert on end of the black tubing to the 90° PTC fitting that corresponds with the black tubing on the SF382.
- Page 14 • Route the black and red tubing through a tubing clamp and secure with a screw. • Hardware: • 1X – 121104 • 1X – 101001 • Route the black tubing around the back side of the regulator. • Cut the black tubing to an appropriate length for it be plugged into the 90°...
- Page 15 • Note: Don’t kink/pinch the tubing. • Route the red tubing through SF791 as shown. • Route the red tubing through the two tube clamps on the side of SF380. Remove the set screw from the hole shown. Route the tube through a hose clamp and secure.
- Page 16 • Cut the red tubing to an appropriate length for it be plugged into the 90° PTC fitting on the regulator. • Insert the end of the red tubing into the PTC fitting shown. Make sure the tubing is properly mated. •...
- Page 17 • See note 5 on page 2. • Plug the SF393 cable into the 12-pin receptacle shown. • Remove the set screws from the holes shown below. • Route and secure the cable with hose clamps as shown. • Hardware: •...
- Page 18 View of Routing for Pneumatic Tubing View of Routing for Pneumatic Tubing SF973-INST...
- Page 19 • Remove the 4 screws shown from the sonar guard (SF381-1). Retain for sonar guard reassembly. • Repeat the last step for the screws on the other side • Place sonar into cradle and align pin to socket as shown below.
- Page 20 • Plug the 8-pin end of the SF369 cable into the sonar. • Slide the threaded jacket forward and screw into the sonar. • Route the loose end of the sonar cable through the clearance hole in the chassis (left). •...
- Page 21 Reference pictures for mounted sonar position. • Secure the sonar cable as shown. • Hardware: • 2X – 121104 • 2X – 101001 SF973-INST...
- Page 22 • Mount SF749 in the upmost position on SF750 using the four spring plungers on SF749. • Route remaining length of sonar cable as shown. • Plug the 12-pin end of the sonar cable into the 12-pin receptacle shown. • Note: The sonar cable should be routed such that manual lift operation does...
- Page 23 • Install SF396 on to the SF349-1 cable using the hardware that was provided with SF396. • Replace the bottom fork on the camera with the SF349-1 cable. • Note: Do not force the mounting block down. When aligning the cable connection you should feel the mounting block slide into place.
- Page 24 • Plug the 8-pin end of the SF393 cable into the camera. • Apply dust caps that were provided with SF379 to all unused receptacles. SF973-INST...
- Page 25 Views of Complete Assembly SF973-INST...
- Page 26 OZ-II Configuration • Unplug the SF349-1 cable from the electronics box. • Unplug the blue tubing from the PTC fitting on the front of the DUC. • Place PTC cap on the end of the blue tubing. • Hardware: • HW4435 SF973-INST...
- Page 27 • Remove the SF393 cable from the assembly. • Remove the DUC from the cradle. • Remove the SF603 cable from the assembly. • NOTE: Leave all hose clamps in their positions for OZ-II cable routing. • Route the SF618 cable as shown.
- Page 28 Views of Complete Assembly SF973-INST...
