ToSee Defender User Manual

Smart wireless garage door opener
Hide thumbs

Advertisement

Quick Links

Download this manual
User manual
Defender Smart Wireless Garage Door Opener
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Defender and is the answer not in the manual?

Questions and answers

Summary of Contents for ToSee Defender

  • Page 1 User manual Defender Smart Wireless Garage Door Opener...
  • Page 2 Introduction Defender Smart Wireless Garage Door Opener is a companion device of your existing door opener. It makes your door smarter and securer. By using it, your door opener can be controlled and monitored at your own will. Confirm the Following before installation: Tools required: Reminder: please check the compatibility of your door opener before installation.
  • Page 3 How to check compatibility? Compatibility of some brands A) Chamberlain® or LiftMaster® All models with security+ are not compatible. B) Craftsman® All models with assurance+ 2.0 are not compatible. C) Genie® Compatible models: Genie Series II openers – best identified by the wall console button(s), which is/are a non-black color. This covers the vast majority of Genie openers, including all the currently sold models.
  • Page 4 2. Check by yourself Take a wire with both ends stripped or a straightened-out paper clip and put each end to the same terminals as the wall button wires are terminated to (Terminal #A and Terminal #B, See the figure above). By doing so, if your door activates, then your door opener is compatible with our device.

  • Page 5: Button Operations

    Wi-Fi indicator Status Name Performance Status Flashing rapidly in red Wi-Fi is not configured, Smart Mode. Flashing slowly in red Wi-Fi is not configured, AP Mode. Wi-Fi configured, Not connect to network; Please check the Wi-Fi Flashing in green router’s firewall or the Wi-Fi ssid and Wi-Fi password. indicator Door Sensor is not paired with Controller, please open or Flashing in blue...

  • Page 6: Installation

    3) Clear door sensor pairing If the Wi-Fi indicator flashes in green or stays in solid green, press and hold the button for 10 seconds, the Wi-Fi indicator will flash in blue, it means that the door sensor was cleared from controller. Installation 1.
  • Page 7 Add device through network 1) Plug in the device to your socket; Power Defender Garage Door Opener device on and check that the Commented [5]: 根据自己产品命名修改 Wi-Fi indicator is rapidly blinking in red. If not, long-press the Wi-Fi button for 3 seconds to reset the device.
  • Page 8 Commented [7]: 自行配图 6) After successfully configuring the devices, the device will be shown on the home page.Tap to enter its control page. The device’s Wi-Fi indicator light will flash in blue. Commented [8]: 自行配图...
  • Page 9 Note:  When device is online, it can be controlled.  When device is offline, it displays "Offline" and cannot be remotely powered on.  The garage door opener does not support 5GHz networks, ensure your Wi-fi is 2.4GHz. If you can’t add device to the app successfully, please contact us for help and don’t go to next step. 4.
  • Page 10 5. Install Door sensor Stick the sensor on the top flap of your garage door; Please make sure the direction of the sensor is correct; Commented [10]: 可自行配图 Note: Power on the device and check the controller’s Wi-Fi indicator light state after you installed the door sensor.
  • Page 11 6. Testing Power on the device and the garage door opener, open or close the door, check the state on your app, If the door state is not correct after you operate the door up to four or more times, it means something wrong.
  • Page 12 How to add the device to “Condition” list? Commented [11]: 根据自己的 app 配图 Note: Only “Open” or “Closed” state is valid.
  • Page 13 How to add the device to “Action” list? Commented [12]: 根据自己的 app 配图 Note: Only “Open” or “Close” action is valid.
  • Page 14 • Make sure you have added Defender Smart Wireless Garage Door Opener to “Smart life” application successfully and you have added an Alexa device to the Amazon Alexa application. 1. Launch Amazon Alexa app and login with your account;...
  • Page 15 Google home How to set google home? Commented [14]: 请参照添加此部分，google home 我 这里使用不了。...
  • Page 16 Voice command: “Ok Google, open (WitGarage)” OR “Ok Google, close (WitGarage)” If the voice command above doesn’t work, please try “Ok Google, turn on (WitGarage)” OR “Ok Google, turn off (WitGarage)” Note: “witgarage” is the device name.
