Standard Accessories - Dilo SF6-LeakPointer Operating Manual

SF -LeakPointer
6
Visual alarms:
Power:

2.2 Standard accessories

1 Carrier case
3 1.5 V alkaline batteries
1 Spare sensor
1 Operating manual (multilingual) on CD-ROM
www.dilo-gmbh.com
|
C 3970-00
| 3-033-R002
|
Page 7 / 12
TACHOMETER bar graph display. Eight high
intensity LEDs are arranged in a Tachometer-like
display indicating leak intensity per sensitivity range.
GEARSHIFT display is arranged in a gearshift
pattern. Seven LEDs indicate the current sensitivity
range of the unit and subsequent leak size as follows:
GEAR --- LEAK SIZE
N --- No Leak
1 & 2 --- Small
3 & 4 --- Medium
5 & 6 --- Large
Three size 'C' alkaline batteries (NEDA/ANSI 14A)
Continuous Operating battery life at 25 °C (77°F):
High intensity alarm: 55 hrs
Low intensity alarm: 75 hrs
Because the instrument turns itself off after 10 min. of
inactivity, the actual useful battery life may be longer
than stated. See Maintenance section for LO BAT
conditions.
