Summary of Contents for Sigberg Audio Inkognito 10
- Page 1 S I G B E R G INKOGNITO A U D I O 10/12 USER MANUAL...
- Page 2 WE CAN’T WAIT TO PLAY YOUR FAVORITE MUSIC!
- Page 3 Please read this manual carefully to ensure that you get the most out of your investment! It includes information about how to install, set up and care for your subwoofer. INTRODUCTION INKOGNITO 10 / 12 USER MANUAL © 2020 Sigberg Audio...
- Page 4 For advice on optimal placement of your subwoofer, please refer to the articles section of our website: www.sigbergaudio.no INSTALLATION & SETUP...
-
Page 5: On-Wall Installation
Carefully lift the subwoofer and hang it on the wall mount. Center it within the wall mounts to minimize transfer of vibrations to the wall. ON-WALL INSTALLATION INKOGNITO 10 / 12 USER MANUAL © 2020 Sigberg Audio... - Page 6 Carefully place the subwoofer on the floor at the location you want it. Slightly adjust as necessary to compensate for uneven flooring, then tighten the nut against the subwoofer. FLOOR INSTALLATION INKOGNITO 10 / 12 USER MANUAL © 2020 Sigberg Audio...
- Page 7 (use included adapter). USB input Connect your laptop to access the parametric EQ. Otherwise for maintenance / service only. USB audio not supported INKOGNITO 10 / 12 USER MANUAL © 2020 Sigberg Audio...
- Page 8 BASIC OPERATIONS...
- Page 9 Amplifier overview BASIC OPERATIONS INKOGNITO 10 / 12 USER MANUAL © 2020 Sigberg Audio...
-
Page 10: Basic Operations
Click the “select” button on the back of the subwoofer to switch between presets. The green LED lights marked P1 / P2 / P3 will indicate the active setting. BASIC OPERATIONS INKOGNITO 10 / 12 USER MANUAL © 2020 Sigberg Audio... - Page 11 PRESETS & EQUALIZER...
- Page 12 Preset 3 is optimized for use with a stereo amplifier, and has a fixed MODES crossover of 40hz. Note: A subsonic filter is enabled in all modes to protect the driver. INKOGNITO 10 / 12 USER MANUAL © 2020 Sigberg Audio...
- Page 13 1 or preset 2 will give the best results. Preset 3 is recommended when you connect to an amplifier without crossover capabilities. A fixed crossover of 40hz is enabled to minimize overlap with your main speakers. INKOGNITO 10 / 12 USER MANUAL © 2020 Sigberg Audio...
- Page 14 Warning: We strongly advice against adding boost beyond 3dB. Also, do not try to boost nulls/dips in the frequency response created by your room. This will only drain the amplifier of power without adding much extra sound. Use cuts to reduce peaks instead. INKOGNITO 10 / 12 USER MANUAL © 2020 Sigberg Audio...
- Page 15 WHEN YOU’RE DONE READING, LET’S WATCH A MOVIE!
- Page 16 HELP YOUR SUBWOOFER BLEND IN...
- Page 17 The laws BLENDING IN of physics dictates that low frequency content will activate the subwoofer cabinet during very loud playback. WITH YOUR INTERIOR INKOGNITO 10 / 12 USER MANUAL © 2020 Sigberg Audio...
- Page 18 BLENDING IN during playback, and subsequently damage the driver. Damage to the driver due to physical impact with surfaces or objects will not be covered by WITH YOUR warranty. INTERIOR INKOGNITO 10 / 12 USER MANUAL © 2020 Sigberg Audio...
-
Page 19: Maintenance
Hitting an object may damage the driver. Control / tighten the screws holding the subwoofer driver every 6 months. Do not overtighten, and cross tighten like you would the wheels on a car. INKOGNITO 10 / 12 USER MANUAL © 2020 Sigberg Audio... -
Page 20: Technical Specifications
•High Line input voltage: 200-240Vac ±10% •Max power consumption: 350W Dimensions •Width / Height / Depth: TBA / TBA / 155 mm •Included feet adds an additional 30 mm Weight: 20kg INKOGNITO 10 / 12 USER MANUAL © 2020 Sigberg Audio... - Page 21 •High Line input voltage: 200-240Vac ±10% •Max power consumption: 650W Dimensions •Width / Height / Depth: 650 / 540 / 165 mm •Included feet adds an additional 30 mm Weight: 22kg INKOGNITO 10 / 12 USER MANUAL © 2020 Sigberg Audio...
-
Page 22: Contact & Support
CONTACT & We wish to thank you once again for purchasing a Sigberg Audio SUPPORT subwoofer, we hope it will bring you joy! Sincerely, Thorbjørn Sigberg Founder INKOGNITO 10 / 12 USER MANUAL ©... - Page 23 ENJOY THE MUSIC!
- Page 24 S I G B E R G A U D I O...
