- Page 1 S I G B E R G SUBWOOFER A U D I O USER MANUAL 10D & INKOGNITO...
- Page 2 WE CAN’T WAIT TO PLAY YOUR FAVORITE MUSIC!
- Page 3 Thank you for purchasing a Sigberg Audio product. We have done our best to provide a high quality product that will be yours to enjoy for many years to come. Please read this manual carefully to ensure that you get the most out of your investment! It includes information about how to install, set up and care for your subwoofer.
-
Page 4: Installation And Setup
For advice on optimal placement of your subwoofer, please refer to the articles section of our website: www.sigbergaudio.no INSTALLATION & SETUP... - Page 5 (use included adapter). USB input Connect your laptop to access the parametric EQ and additional settings. Otherwise for maintenance / service only. USB audio not supported SIGBERG AUDIO SUBWOOFER USER MANUAL © 2020-2021 Sigberg Audio...
- Page 6 BASIC OPERATIONS...
-
Page 7: Basic Operations
Amplifier overview FA251: Inkognito 10 FA501: Inkognito 12 & 10D BASIC OPERATIONS SIGBERG AUDIO SUBWOOFER USER MANUAL © 2020-2021 Sigberg Audio... - Page 8 Click the “select” button on the back of the subwoofer to switch between BASIC presets. OPERATIONS: The green LED lights marked P1 / P2 / P3 will indicate the active setting. BACK PANEL SIGBERG AUDIO SUBWOOFER USER MANUAL © 2020-2021 Sigberg Audio...
- Page 9 (green led blinking). OPERATIONS: Signal auto-detect can be disabled on the main screen by changing the “Force ADJUSTING input” setting to the active input DEFAULTS Note: this setting is defined independently per preset. SIGBERG AUDIO SUBWOOFER USER MANUAL © 2020-2021 Sigberg Audio...
- Page 10 PRESETS...
- Page 11 Preset 2 is optimized for use with the Sigberg Audio SBS.1 active speakers. what works best for your setup. Preset 3 is optimized for use with a stereo amplifier, and has a fixed crossover of 40hz.
- Page 12 80hz or higher for most speakers. 100- 120hz often works well. MODES Unlike many subwoofers, our subwoofers will happily reproduce punchy, clean bass all the way up to 250hz. SIGBERG AUDIO SUBWOOFER USER MANUAL © 2020-2021 Sigberg Audio...
- Page 13 Please refer to the SBS.1 manual for gain recommendations. If you own the SBS.1 speakers, but have active crossover support in your amplifier/processor and want to experiment with different crossover settings, please use Preset 1. MODES SIGBERG AUDIO SUBWOOFER USER MANUAL © 2020-2021 Sigberg Audio...
- Page 14 If you need a different crossover, this can be defined manually in the subwoofers internal EQ software (see page 16). MODES SIGBERG AUDIO SUBWOOFER USER MANUAL © 2020-2021 Sigberg Audio...
- Page 15 EQUALIZER...
- Page 16 Tip: Trying to use all nine filters to perfectly flatten the response isn’t always a good idea. Two or three well placed filters may actually sound best even though the result isn’t perfectly flat. Warning: We strongly advice against adding boost beyond 3dB. SIGBERG AUDIO SUBWOOFER USER MANUAL © 2020-2021 Sigberg Audio...
- Page 17 Center frequency: Double the number entered above (example: 160 hz) Q factor: 0,8 CROSSOVERS Gain: -8dB To apply changes: Make sure «EQ Enabled» is selected, and then click the «Upload to DSP» button. SIGBERG AUDIO SUBWOOFER USER MANUAL © 2020-2021 Sigberg Audio...
- Page 18 WHEN YOU’RE DONE READING, LET’S WATCH A MOVIE!
- Page 19 HELP YOUR SUBWOOFER BLEND IN...
- Page 20 The Inkognito & 10D subwoofers are designed to blend into a modern interior. Here are a couple of suggestions on how to do it. Placing something on top of the subwoofer The subwoofer does not vibrate much during playback, so placing something like a plant on top of the subwoofer will be perfectly fine, and will not affect sound quality.
- Page 21 Otherwise you may cause the driver to physically hit the floor BLENDING IN during playback, and subsequently damage the driver. Damage to the driver due to physical impact with surfaces or objects will not be covered by WITH YOUR warranty. INTERIOR SIGBERG AUDIO SUBWOOFER USER MANUAL © 2020-2021 Sigberg Audio...
-
Page 22: Maintenance
Control / tighten the screws holding the subwoofer driver by hand every 6 months. Do not overtighten, and cross tighten like you would the wheels on a car. SIGBERG AUDIO SUBWOOFER USER MANUAL © 2020-2021 Sigberg Audio... -
Page 23: Technical Specifications
•High Line input voltage: 200-240Vac ±10% •Max power consumption: 350W Dimensions •Width / Height / Depth: 650 / 540 / 155 mm •Included feet adds an additional 30 mm Weight: 20kg SIGBERG AUDIO SUBWOOFER USER MANUAL © 2020-2021 Sigberg Audio... - Page 24 •High Line input voltage: 200-240Vac ±10% •Max power consumption: 650W Dimensions •Width / Height / Depth: 650 / 540 / 165 mm •Included feet adds an additional 30 mm Weight: 22kg SIGBERG AUDIO SUBWOOFER USER MANUAL © 2020-2021 Sigberg Audio...
- Page 25 •High Line input voltage: 200-240Vac ±10% •Max power consumption: 650W Dimensions •Width / Height / Depth: 360 / 370 / 410 mm •Included feet adds an additional 15 mm Weight: 27kg SIGBERG AUDIO SUBWOOFER USER MANUAL © 2020-2021 Sigberg Audio...
-
Page 26: Contact & Support
CONTACT & contact options. SUPPORT We wish to thank you once again for purchasing a Sigberg Audio subwoofer, we hope it will bring you joy! Sincerely, Thorbjørn Sigberg Founder SIGBERG AUDIO SUBWOOFER USER MANUAL © 2020-2021 Sigberg Audio... - Page 27 ENJOY THE MUSIC!
- Page 28 S I G B E R G A U D I O...
