Radomír Bednář, production of fishing tackle and
metal-working production
V kotlině 16, 77900 Olomouc, Czech Republic, IČO: 13239449
tel. +420585224291, e-mail: radomir.bednar@volny.cz
web: http://www.r-bednar.cz
Control panel 160NB
CONTENT: Description
DESCRIPTION
Control panel is designed for adjusting the AC voltage from electric generator (230V) for fishing purposes.
AC from electric generator is adjusted using the phase-controlled one-way rectifier, which is handled using
the power potentiometer. Specific shape DC pulses temporarily stupefy fish but don't hurt them.
On the control panel, there is:
1. Main switch
2. Power scale switch (I, II)
3. Peak modulation switch
4. Power control switch
5. Pulse frequency regulation knob
6. Fuse case with 8A fuse
The ammeter shows mean values of output current (peak value is higher) and those values are of
informative character for the operator and for the instrument operation. Output current value directly
corresponds to fishing environment properties (water conductivity, etc.). Voltmeter shows mean values of
output voltage. On the side of the control panel, there are sockets for connecting the anode (+ sign) and
cathode (- sign).
Basic instruments for electrofishing are: fishing handle with extension and electric landing net (anode),
cable and cable drum, drum support, cathode, grounding pin and dielectric gloves.
Control panel 160NB is suitable for waters of water conductivity 50-1500µS.
The product complies with the technical requirements on products as per the Act No. 22/1997 Coll.,
Government Regulation No. 168/1997 Coll., and Government Regulation No. 169/1997 Coll. and
a Declaration of Conformity was issued for the product.
OPERATING INSTRUCTIONS
Advertisement
Table of Contents
Related Manuals for Radomir Bednar 160NB
Summary of Contents for Radomir Bednar 160NB
- Page 1 Basic instruments for electrofishing are: fishing handle with extension and electric landing net (anode), cable and cable drum, drum support, cathode, grounding pin and dielectric gloves. Control panel 160NB is suitable for waters of water conductivity 50-1500µS. The product complies with the technical requirements on products as per the Act No. 22/1997 Coll., Government Regulation No.
- Page 2 3. Start the electric generator according to its own manual, switch on the breaker on the generator output (next to sockets). 4. Switch on the main switch of control panel 160NB. 5. Change the power scale according to fishing conditions. Switch position I is for conductivity greater than 250 µS.
- Page 3 For all ways of fishing there is always one common rule: set the power supply high enough for fishing effects to be sufficient and low enough for fish not to be stunned for too long. When setting too high power supply you can restrain the fish galvanotaxis (an ability of anode to attract fish) and the fish will remain stunned at the bed.
- Page 4 e) Dismantle the carbon segment holder and replace carbon segments with new ones 2. The fishing effectiveness of the device is not sufficient. Possible defect: a) Improper settings of the rotor rotation speed b) Improper electrodes (size, technical condition) c) Extreme requirements, unfavourable parameters of the fishing environment d) Inlet cable isolation failure Remedy: a) Move the engine control lever to the left...
