Radomír Bednář, production of fishing tackle and

metal-working production

V kotlině 16, 77900 Olomouc, Czech Republic, IČO: 13239449

tel. +420585224291, e-mail: radomir.bednar@volny.cz

web: http://www.r-bednar.cz

Control panel BMA-PLUS

CONTENT: Description

Operating Instructions

Safety Instructions

Technical Data

Troubleshooting

Block Diagram

DESCRIPTION

Control panel BMA-PLUS is designed for adjusting the AC voltage from electric generator (230V) for

fishing purposes. AC from electric generator is adjusted using the phase-controlled one-way rectifier, which

is handled using the power potentiometer. Specific shape DC pulses temporarily stupefy fish but don't hurt

them. On the control panel, there is MAIN SWITCH (0,1), POWER SCALE SWITCH (0,1), potentiometer

knob for continuous power adjustment and fuse case with T2.5A fuse. Ammeter shows mean values of

output current (peak value is higher) and those values are of informative character for the operator and for

the instrument operation. Output current value directly corresponds to fishing environment properties

(water conductivity, etc.). Voltmeter shows mean values of output voltage. On the side of the control panel,

there are sockets for connecting the anode (+ sign) and cathode (- sign).

Basic instruments for electrofishing are: fishing handle with extension and electric landing net (anode),

cable and cable drum, drum support, cathode, grounding pin and dielectric gloves.

Control panel BMA-PLUS is suitable for waters of water conductivity 150-1500µS.

The product complies with the technical requirements on products as per the Act No. 22/1997 Coll.,

Government Regulation No. 17/2003 Coll., and Government Regulation No. 616/2006 Coll. and

a Declaration of Conformity was issued for the product.

Page 1 Block Diagram DESCRIPTION Control panel BMA-PLUS is designed for adjusting the AC voltage from electric generator (230V) for fishing purposes. AC from electric generator is adjusted using the phase-controlled one-way rectifier, which is handled using the power potentiometer. Specific shape DC pulses temporarily stupefy fish but don’t hurt them.
Page 2 8. When fishing in running water, always move upstream only. 9. After finishing the fishing, switch off the main switch of the control panel BMA-PLUS first, then turn off the generator. Always roll-up the cable only when the gear is not working.
Page 3 SAFETY INSTRUCTIONS To ensure the safety when using the electrofishing gear, it is necessary to follow instructions given in the generator manual and also following instructions: 1. The person managing the fishing process has to be familiar with operation of the electrofishing gear, with the fishing procedure and with safety rules (ON 341740 and ON 341741).
Page 4 d) Inlet cable isolation failure Remedy: a) Move the engine control lever to the left b) Replace electrodes c) Use another gear d) Replace the inlet cable 3. The engine does not start. Possible defect: a) Lack of fuel, closed fuel feed b) Lack of oil supply (the low oil level sensor does not allow the engine to start up in order to avoid engine seizure) c) Defective spark plug...
