DESCRIPTION
Professional prop builders know a secret: audio is more than half of the experience of a high-quality prop.
Until now, most consumer-level audio boards lacked some real professional features -- features like quality
amplification, stand-alone randomization of sounds, relay control for automated output while audio plays, and
easy connections for manual and remote control. The AP-16+ is a high-quality, stereo WAV file player
designed for serious prop builders of all levels. It's very easy to use, yet rich in features, and is easily
integrated into props and displays.
PRODUCT APPLICATIONS
•
Props and holiday displays
•
Sophisticated audio annunciation for small-scale industrial control
FEATURES & BENEFITS
•
Plays stereo WAV files (16-bit, PCM, up to 44.1kHz)
•
Files stored on standard SD card (FAT or FAT32 format)
•
24 stand-alone files under manual control
•
Optional, auto-playing ambient file (AMBIENT.WAV)
•
Manual input via (normally-open) dry-contact, (optically isolated) 12-24 VDC input, or PIR sensor
•
Eight, dry-contact auxiliary inputs
•
Relay output active when file plays (N.O. and N.C connections provided)
•
Pre- and post-play delay potentiometers (manual mode, only)
•
Dual 20W amplifiers (one per channel)
•
TTL serial control for connection to host microcontroller
- unlimited files under serial control
•
User-configured baud rate (2400 or 38.4k) for serial control
•
User-configured address allows up to four AP-16+ boards on one serial connection
•
Easily updated as new features become available – update loads from SD card
•
Size: 4.25" x 4.50" (107.95mm x 114.30mm)
•
Four, 0.135" (3.4mm) mounting holes
EFX-TEK ● www.efx-tek.com ● teamefx@efx-tek.com
AP-16+ Audio Player
Document Version: 1.30 ● 15 JUL 2010
Version 1.0
Copyright © 2010 EFX-TEK
1
Advertisement
Table of Contents
Related Manuals for EFX-TEK AP-16+
Summary of Contents for EFX-TEK AP-16+
- Page 1 User-configured address allows up to four AP-16+ boards on one serial connection • Easily updated as new features become available – update loads from SD card • Size: 4.25” x 4.50” (107.95mm x 114.30mm) • Four, 0.135” (3.4mm) mounting holes EFX-TEK ● www.efx-tek.com ● teamefx@efx-tek.com...
-
Page 2: Connections And Controls
F. Start input: 12 to 24 VDC P. Pre-play delay potentiometer G. Start input: PIR Q. Post-play delay potentiometer Start input: manual button R. Relay output terminals Audio Select switch (SFX files) S. Status LED J. Serial input (Open-True TTL) EFX-TEK ● www.efx-tek.com ● teamefx@efx-tek.com... -
Page 3: Power Input
Using the auxiliary manual inputs (IN1..IN8) the AP-16+ can play any of eight files, named AUX01.WAV through AUX08.WAV. Note that when the EN (audio stop enable) option switch is set to ON, IN8 will serve as EFX-TEK ● www.efx-tek.com ● teamefx@efx-tek.com... -
Page 4: Manual Control
When the audio stop enable (EN) option switch is ON, IN8 serves as an audio stop; AUX08.WAV – even if present – will not play under manual control Pre-Play and Post-Play Delays For stand-alone projects the AP-16+ includes potentiometers for setting pre- and post-play delays applied to EFX-TEK ● www.efx-tek.com ● teamefx@efx-tek.com... -
Page 5: Configuration Switches
TTL (0 to 5 VDC) using “open-true” baud mode to enable daisy-chaining devices. All exchanges are initiated by the host controller. The format of host communications to the AP-16+ is as follows: "!AP16", address, command { , data } EFX-TEK ● www.efx-tek.com ● teamefx@efx-tek.com... - Page 6 "V" :: Get AP-16 Version Number Syntax: "!AP16", address, "V" Reply: 3-byte (ASCII) version string Prop-1 Example: SEROUT Sio, OT2400, ("!AP16", %00, "V") SERIN Sio, OT2400, id0, id1, id2 DEBUG "AP-16 Version ", #@id0, #@id1, #@id2, 13 EFX-TEK ● www.efx-tek.com ● teamefx@efx-tek.com...
- Page 7 Note that the AP-16+ maintains an internal play list so that – if using the same limit # in the "P?" command – no file will be repeated until all within the range have played. EFX-TEK ● www.efx-tek.com ● teamefx@efx-tek.com...
- Page 8 AP-16+ must stop AMBIENT.WAV in order to search and verify the file specified in the "PW" command. NOTE: Any "P" command will always stop audio that is playing. Use the "G" command (get status) to check on the AP-16+ if you do not desire this behavior EFX-TEK ● www.efx-tek.com ● teamefx@efx-tek.com...
-
Page 9: Status Led
The AP-16+ uses a multi-color status LED (S) to provide information regarding the operational state. The table that follows illustrates steady and blinking patterns that you will see from the status LED under various operational conditions. EFX-TEK ● www.efx-tek.com ● teamefx@efx-tek.com... -
Page 10: Firmware Updates
Firmware Updates From time-to-time EFX-TEK may release firmware updates to add to or improve the features of the AP-16+. These updates will be provided free-of-charge. To install the update you will download an update file from EFX-TEK that will have the form: AP16_vXYY.EEPROM... -
Page 11: Mechanical Specifications
Symbol Unit Min. Typical Max. Supply Voltage Supply Current Output Power (@18VDC) - 4Ω Output Power (@18VDC) - 8Ω Output Power (@12VDC) - 4Ω Output Power (@12VDC) - 8Ω Output power rating is per channel. EFX-TEK ● www.efx-tek.com ● teamefx@efx-tek.com...
