• Cases are designed to operate at 75 degrees Fahrenheit and 55% relative humidity
Self-Contained
Remote
Length
Height
Depth
Depth w/bottom door 38-1/2"
(Dimensions are +/-1/4")
• Specification subject to change without notice
SC-CFS35-4
SC-CFS35-6 SC-CFS35-8 SC-CFS35-10 SC-CFS35-12
R-CFS35-4
R-CFS35-6
50"
71"
52"
52"
35-1/2"
35-1/2"
N/A
35 Series – Double Duty
Fish and Poultry
• PRODUCT SPECIFICATIONS SHEETS
R-CFS35-8
R-CFS35-10
95"
119"
52"
52"
35-1/2"
35-1/2"
N/A
N/A
R-CFS35-12
143"
52"
35-1/2"
N/A
Advertisement
Related Manuals for Howard McCray R-CFS32E-4
Summary of Contents for Howard McCray R-CFS32E-4
- Page 1 • Cases are designed to operate at 75 degrees Fahrenheit and 55% relative humidity Self-Contained SC-CFS35-4 Remote R-CFS35-4 Length 50" Height 52" Depth 35-1/2" Depth w/bottom door 38-1/2" (Dimensions are +/-1/4") • Specification subject to change without notice 35 Series – Double Duty Fish and Poultry •...
- Page 2 Standard Specifications and Optional Features CONSTRUCTION UL Classified to ANSI/NSF 7 Foamed in place CFC free foam Triple pane insulated front glass-26"H Heavy gauge steel super structure Bottom storage Drain is included for cleaning INTERIOR Designer white interior ends White aluminum floor (bottom storage area) Air insulated baffle (prevents moisture from dripping into display area) Solid stainless steel ice pan-full length...
- Page 3 Model Length Height Depth Depth with bottom door (Dimensions are +/- 1/4") Operating temperature Refrigerant (expansion valve) Compressor size HP Pressure control settings @ 75°F, 55%RH Defrost per day (24 hours) BTU’s at +20°F Evap. Temp. Voltage Amperage Amperage, lights only Cord and plug Exterior color Interior color...
- Page 4 35 Series – Double Duty Fish and Poultry Technical Data • Side View • Plan View 4’ (6’-8’-10’-12’) Plan View Self-contained Cross Section Plan View Remote A Division of HMC Enterprises LLC • 2501 Grant Avenue • Philadelphia, PA 19114 USA (215) 464-6800 •...
