Summary of Contents for Quantum Northwest TC 1
- Page 1 Identifier: Revision: Effective Date: TC 1-MAN-2.2 9/17/20 Web Page: http://www.qnw.com Description: TC 1 Temperature Controller for Quantum Northwest Peltier-Controlled Cuvette Holders QNW TC 1 Temperature Controller User’s Guide...
- Page 2 The Quantum Northwest name, QNW acronym and Should Quantum Northwest and the user have a Quantum Northwest logo are trademarks or separate written agreement with warranty terms registered trademarks of Quantum Northwest, Inc.
- Page 3 QNW TC 1 User’s Guide WARNING A CAUTION notice denotes a hazard. It calls attention to an operating procedure, practice, or the like that, if not correctly performed or adhered to, A WARNING notice denotes a hazard. It calls could result in damage to the product or loss of attention to an operating procedure, practice, or the important data.
-
Page 4: Table Of Contents
1.10. Electrical Specifications ......................11 1.11. Computer Requirements ......................11 Installing, Starting and Stopping the QNW TC 1 Temperature Controller ..... 12 2.1. Installing the QNW TC 1 Temperature Controller ................. 12 2.2. Starting the QNW TC 1 Temperature Controller ................14 2.3. - Page 5 QNW TC 1 User’s Guide 5.5. Target Temperature ........................24 5.6. Instrument Status .......................... 25 5.7. Current Sample Holder Temperature.................... 25 5.8. Error Reporting ..........................25 5.9. Probe Status and Temperature ..................... 26 5.10. Temperature Ramping ......................27 5.11. Heat Exchanger Temperature ....................28 5.12.
-
Page 6: General Information
Do not block any ventilation grills present on the QNW TC 1 Temperature Controller. Use of the QNW TC 1 Temperature Controller and accessories may involve materials, solvents and solutions that are flammable, corrosive, toxic or otherwise hazardous. Careless, improper, or unskilled use of such materials, solvents and solutions can create explosion hazards, fire hazards, toxicity and other hazards which can result in death, serious personal injury, and damage to equipment and property. -
Page 7: Ce Compliance
1.4. CE Compliance Your QNW TC 1 Temperature Controller has been designed to comply with the requirements of the Electromagnetic Compatibility (EMC) Directive and the Low Voltage (electrical safety) Directive (commonly referred to as the LVD) of the European Union. Quantum Northwest has confirmed that each product complies with the relevant Directives by testing a prototype against the prescribed EN (European Norm) standards. - Page 8 QNW TC 1 User’s Guide EU Declaration of Conformity Quantum Northwest, Inc. 22910 E Appleway Ave, Suite 4 Liberty Lake, WA 99019-8606 Hereby declare under our sole responsibility that the following devices (and associated options /E, /E2, /L and /L2):...
-
Page 9: Declaration Of Conformity To Eu Directive 2011/65/Eu (Rohs)
QNW TC 1 User’s Guide Declaration of Conformity to EU Directive 2011/65/EU (RoHS) Quantum Northwest, Inc. 22910 E Appleway Ave, Suite 4 Liberty Lake, WA 99019-8606 Declare under our sole responsibility that our products indicated below (and associated options /E, /E2, /L and /L2) are in fully compliance with EU Directive 2011/65/EU, with respect to the following substances: 1. -
Page 10: Introduction: Qnw Tc 1 Temperature Controller
Introduction: QNW TC 1 Temperature Controller Intended Use The QNW TC 1 Temperature Controller is used with an associated Peltier-controlled cuvette holder to control sample temperature during optical measurements. Temperature control is achieved using the TC 1 Temperature Controller alone or along with a computer interfaced to the TC 1 Temperature Controller box, using the QNW T-App software provided. -
Page 11: Electrical Specifications
All power supplies for the TC 1 Temperature Controller must be single-phase, AC voltage, three-wire system (active, neutral, earth) and should be terminated at an appropriate power outlet receptacle that is within reach of the power cord. -
Page 12: Installing, Starting And Stopping The Qnw Tc 1 Temperature Controller
QNW TC 1 temperature controller and the T-App application. 3. Connect the TC 1 to the computer to be used with the USB cable provided with the TC 1 (or any USB cable with the correct plug ends). Turn on the TC 1 power. Installation of the drivers for the USB connection should begin immediately and proceed automatically. - Page 13 Connect the TC 1 to your computer using the USB or RS 232 cable provided. The New Hardware installation process will begin automatically and take a few moments to finish.
-
Page 14: Starting The Qnw Tc 1 Temperature Controller
Series 500 thermistor probe (not provided) into the ¼ - inch phone jack labeled “probe” in the back panel of the TC 1. Place the end of the probe in a region of the sample in the cuvette where it will not occlude the spectrometer light beam. -
Page 15: Stopping The Qnw Tc 1 Temperature Controller
2. After measurements are completed, turn off power on the back of the TC 1 controller. This action should power off both the TC 1 and the BATH 10 pump, if used. If you are using a circulator pump other than the BATH 10, power it off at this time. -
Page 16: Step-By-Step Instructions For Using The Qnw Tc 1 Temperature Controller
Using the Menu Button control arrows Figure 4. TC 1 Menu Button control arrows Refer to Fig. 7 for the appearance of the TC 1 Menu button. Use the right and left arrows to cycle through four pages: – Display – Set Target Temperature – Set Stirring – Set Ramping –... - Page 17 QNW TC 1 User’s Guide Figure 5. Example TC 1 Display page for a single cuvette holder and external probe, with temperature Display: This main page shows the actual cuvette Holder temperature, the Target temperature and a Probe temperature (if a probe is present). The page also shows whether the Ramp and Stir functions are on or off.
-
Page 18: External Computer Control
3.3. External Computer Control All functions may be accessed either through a Serial (RS 232) or a USB located on the back of TC 1 Temperature Controller. You may write your own program or purchase the QNW application program T- App. -
Page 19: Troubleshooting
If the TC 1 display indicates that there is inadequate coolant, it may be that the circulating water is too warm. Add ice to the water to cool it down. - Page 20 QNW TC 1 User’s Guide 8 – inadequate coolant warnings: inadequate coolant, water temperature The sensor on the heat exchanger is reading a temperature above 60 °C. Temperature control has been shut down to prevent damage to the Peltier element. Either the water was too warm or the rate of flow was inadequate to draw sufficient heat from the heat exchanger.
-
Page 21: Maintenance And Spare Parts
4.1. Maintenance The TC 1 Temperature Controller requires very little routine maintenance on the part of the user. For routine cleaning of exposed surfaces, use only a cloth dampened with water or diluted detergent. Do not use organic or abrasive solvents. -
Page 22: Serial Communications For The Tc 1 Temperature Controller
TC 1 family of controllers. TC 1/Single – for single cuvette holders such as the t2 Sport, Versa 20, Luma 40, CD 250 and Flash 300; TC 1/Dual – for dual independent control for sample and reference cuvettes of the t2x2 Sport and Versa Dual;... -
Page 23: Sample Holder Id Number
QNW TC 1 User’s Guide For many of the commands listed below, the controller returns information in response to the command. All commands and responses are delineated by left and right square brackets ( [ ] ). Any text sent to the controller not enclosed within brackets will be ignored. -
Page 24: Temperature Control
[F1 TT S 23.10] Set the Target Temperature to 23.10 ºC. Note: The TC 1 does not turn temperature control on when TT is received (as it does when the front panel controls are used to set the TT). [F1 TT ?] What is the current target temperature? ...[F1 TT 71.32]... -
Page 25: Instrument Status
QNW TC 1 User’s Guide 5.6. Instrument Status [F1 IS ?] What is the current Instrument Status? ...[F1 IS 0-+S] Response is four parameters (or five, see below): number of unreported errors is 0 (0 or 1); stirrer is off (+ is on, - is off);... -
Page 26: Probe Status And Temperature
Change probe temperature returned to a precision of 0.1 °C. Note: Since probe temperatures are always reported to 0.01 °C by the TC 1 controller, these commands have no effect. They are included to maintain compatibility with customer software / firmware based... -
Page 27: Temperature Ramping
The following seven commands, are accepted by and work with the TC 1. They are provided mainly to maintain compatibility with control software/firmware developed for use with the older TC 125/225/425 family of temperature controllers. -
Page 28: Heat Exchanger Temperature
QNW TC 1 User’s Guide There are no corresponding reference commands (see command class 13) for the TL commands. [F1 TL +] Ramp the sample and reference identically. [F1 TL -] or. [F1 TL 0] Ramp the sample and reference independently (the power on default). -
Page 29: Cell Changing
QNW TC 1 User’s Guide [F1 HT -] Stop periodic heat exchanger temperature reports. [F1 HL ?] What is the high temperature limit for the heat exchanger? ...[F1 HL 60] The heat exchanger high temperature limit is 60 ºC. In operation with temperature control on, if the HT parameter exceeds HL, the TC 1 will turn temperature control off. -
Page 30: Front Panel Controls
5.14. Front Panel Controls Note: The TC 1 can be controlled manually using the buttons and the display on the front. Once a control program has connected to the TC 1, the controller will automatically send reports to the program whenever a manual change has been made. The commands in this section allow the program to control access to front panel (FP) settings and determine if and how such front panel changes are reported. -
Page 31: Elements Of The T-App Software Help File
QNW TC 1 User’s Guide 6. Elements of the T-App Software Help File The program T-App comes with a complete Help File. Below are elements useful for getting started with T- App. 6.1. Application Startup Window This Startup Window is displayed while the program searches for a Temperature Controller by checking each active COM port on the computer, beginning with the highest. -
Page 32: Application Control Window
Temperature Plot or the Status Panel. The image above shows the T-App Application window as it would appear using a TC 1 Temperature Controller with a Series 400 thermistor probe attached (with the thermistor tip in the stirred sample). For other configurations (dual sample holders;... -
Page 33: Application Menus
QNW TC 1 User’s Guide 6.3. Application Menus Click on the individual menu bar items (where the pointer changes to a hand) for further information on that menu. 6.4. File Menu Click on the individual menu item (where the pointer changes to a hand) for further information on that menu item. -
Page 34: Temperature Ramping
QNW TC 1 User’s Guide 6.7. Temperature Ramping Single sample holder system. 6.8. Stirrer Control Single sample holder system. 6.9. Show Script Panel See also the Hide Script Panel menu item. When this menu item is clicked, the right side of the Application Control Window will open to show a vertical panel containing a text display with button controls and other information near the bottom. - Page 35 QNW TC 1 User’s Guide When the Show Script Panel opens, the initial text display will be empty and the bottom controls appear as shown below left. Below right show the same area while a script is running (identical to that in the snapshot of the full window above).
-
Page 36: Command Text Box
QNW TC 1 User’s Guide 6.10. Command Text Box This edit box may be used to send commands to the Temperature Controller. The command format is illustrated by the default entry, [F1 CC P1 P2]. Replace "CC" by the command code. -
Page 37: Data Shown
QNW TC 1 User’s Guide 6.12. Data Shown Dual with external probe Single (or multi-sample) with external probe 6.13. Single Sample Status Panel Click on the individual controls where the pointer changes to a hand for further information on that control. -
Page 38: Temperature Control Status
QNW TC 1 User’s Guide 6.14. Temperature Control Status When temperature control is off, the circle will be a steady gray and the label will read "off". When temperature control is on but the sample holder temperature is not stable, the small circle will alternate slowly between green and gray and the label to it's right will read "seeking". -
Page 39: Target Temperature
QNW TC 1 User’s Guide 6.16. Target Temperature The Target Temperature is the Sample Holder Temperature that you want to use. If Temperature Control is On, the Controller will either be driving the holder temperature to the target or maintaining the holder temperature at the target. -
Page 40: Plot Axis Label Manipulation
QNW TC 1 User’s Guide If 20 temperatures are not yet available, the mean and average deviation are replaced by dashes (image on the right). 6.19. Plot Axis Label Manipulation The label on the vertical axis can be changed by clicking on the small black rectangle near the upper-left corner of the plot;... -
Page 41: Scripts: Program Script Commands
QNW TC 1 User’s Guide black blue - temperature of the sample holder. - temperature of the heat exchanger. dotted black - temperature of the external probe (with the thermistor tip in the liquid sample). Individual time/temperature points are shown for the external probe data to illustrate special methods of reporting probe temperatures used in the Example Script. - Page 42 QNW TC 1 User’s Guide The current temperature is the temperature of the metal body of the sample cuvette holder. [*WPT>=#] - Wait until the probe temperature exceeds or equals a particular value (# as an integer). [*WPT<=#] - Wait until the probe temperature decreases to or below a particular value (# as an integer).
- Page 43 QNW TC 1 User’s Guide Listing Control commands [*LIS +] or [*LIS -] - Enable (+) or Disable (-) listing of Instrument Status replies during running of a script. [*LER +] or [*LER -] - Enable (+) or Disable (-) listing of Error Message replies during running of a script.
- Page 44 QNW TC 1 User’s Guide are sent to the Temperature Controller, it automatically sends the reply [F2 DL #] when the positioning process is completed. The [*WPL] command waits for this reply before continuing to the next command in the script.
