Zen Habitats Deluxe Stacking Spacer Assembly Instructions

Hide thumbs

Parts list:

Part A (2) – 46" Aluminum Frame (2 channels at 90-degree angle)

Part B – A (4) – 22" Aluminum Frame (2 channels at 90-degree angle)

Part B – B (2) – 10" Aluminum Frame (2 channels at 90-degree angle)

Part C (2) – 10" Aluminum Side Door Frame (1 channel)

Part D (1) – 46" Aluminum Top Door Frame (1 channel and 1 double 3/4" top door rail)

Part E (1) – 46" Aluminum Bottom Door Frame (1 channel and 1 double 1/4" bottom door rail)

Table of Contents

Need help?

Do you have a question about the Deluxe Stacking Spacer and is the answer not in the manual?

Questions and answers

Summary of Contents for Zen Habitats Deluxe Stacking Spacer

Page 1 Zen Habitats Deluxe Stacking Spacer Assembly Instructions Parts list: Part A (2) – 46” Aluminum Frame (2 channels at 90-degree angle) Part B – A (4) – 22” Aluminum Frame (2 channels at 90-degree angle) Part B – B (2) – 10” Aluminum Frame (2 channels at 90-degree angle) Part C (2) –...
Page 2 Part F (8) – Pressure corners (with 3 prongs) Part K (2) – 22”x10” Bamboo Lined Wood Side Panels Part L (2) – Bamboo Lined Wood Doors Part M (2) – Doorknobs and Screws Assembly Video instructions also available at https://www.zenhabitats.com/pages/deluxe-stacking-spacer-assembly Step 1 –...
Page 3 • Attach the other side frame, with the two pressure corners already connected, to the assembled frame. You should now have a rectangle shaped floor with four fingers facing up. Step 2 – Assemble Back and Sides • Attach the side door frame (Part C) to the pressure corners that align with the bottom door track. SPECIAL NOTE: Make sure the front side door frame’s channel is facing the back of the enclosure.
Page 4 • Insert the two side panels (Part K) on the left and right-side channels. Step 3 – Assemble Top • Attach the pressure corners (Part F) to each end of two 22” aluminum frames (Part B-A). Make sure that the fingers from the corners align with the channels of the frame.
Page 5 Step 5 – Support Bars (Optional) • If you plan on using substrate over 100 lbs., but less than 250 lbs, use the support bars provided. Simply place on top of the deluxe stacking spacer.
